WD BLACK

SN750 NVMe

SSD

Level Up to NVMe SSD Performance

The WD BLACK™ SN750 NVMe™ SSD delivers top-tier performance for gaming and

hardware enthusiasts who are looking to build or upgrade their PC. Available in capacities

up to 2TB

, the WD BLACK SN750 NVMe SSD rivals some of the best performing drives on

the market to help give gamers that competitive edge.

Performance Matters

Live life in the fast lane, whether you’re looking to boost your system’s overall

responsiveness or load games and levels quickly, the WD BLACK drive cuts down on your

wait time to get back into action and gets you ahead of the game.

Our fastest computing NVMe SSD (1TB heatsink model) can deliver speeds more than six

times faster than our fastest SATA SSD (up to 3,470MB/s

vs. 560MB/s²) to give hardcore

gamers the competitive edge they need.

Sleek Heatsink Design

Every system is not created equal. From different graphics cards and CPUs to DRAM and

storage, PCs all differ in performance and appearance. The WD BLACK SSD’s sleek and

modern heatsink model goes well with desktop PC builds that support the M.2 form

factor and is the perfect component to complement systems with RGB lighting and other

cooling technologies, such as water cooling

The EKWB heatsink is designed to help keep the WD BLACK NVMe SSD running at peak

performance for longer sustained periods. It’s sleek and non-intrusive design not only

gives your system a boost in appearance, but also helps your drive maintain optimal

levels of performance with its passive cooling features.

The WD BLACK SSD Dashboard

The WD BLACK SSD Dashboard gives you the ability to optimize performance by enabling

the gaming mode feature. This disables the low power mode function on the SSD, which

keeps your drive ﬁring on all cylinders during intense gaming sessions.

1 As used for storage capacity, one gigabyte (GB) = one billion bytes and one terabyte (TB) = one trillion bytes. Total accessible capacity

varies depending on operating environment.

2 Megabyte per second (MB/s) = one million bytes per second. Based on internal testing; performance may vary depending upon host

device, usage conditions, drive capacity, and other factors.

3 Heatsink option not available for the 250GB version of WD BLACK™ SN750 NVMe™ SSD. Heatsink model recommended for desktop PC

only.

4 Available for download at www.westerndigital.com.

Product Highlights

• Read speeds up to 3,470MB/s² (1TB heatsink

model only) for improved load times.

• Available in capacities ranging from 250GB to

2TB¹.

• Sleek heatsink design to customize and intensify

your gaming rig while helping to maintain peak

performance

• An exclusive WD BLACK™ SSD dashboard⁴ with

gaming mode improves game performance.

Space To Play

The WD BLACK SN750 NVMe SSD is available in

capacities ranging from 250GB – 2TB¹. At the core

of the WD BLACK drive is its revolutionary NAND

technology. By doubling the storage density from

its previous generation, our 3D NAND pushes the

limitations of storage and showcases the amazing

feat of NAND innovation. This means extended

capacity up to 2TB¹ on a single-sided drive that’s

roughly the size of a gumstick, enough to store your

large ﬁles and video games.

PRODUCT BRIEF

WD BLACK SN750 NVMe SSD (Without Heatsink)

Speciﬁcation

Interface M.2 2280



PCIe Gen3 8 Gb/s, up to 4 Lanes

Formatted Capacity

250GB, 500GB, 1TB, 2TB

Performance 250GB 500GB 1TB 2TB

Sequential Read up to (MB/s) (Queues=32, Threads=1) 3,100 3,430 3,430 3,400

Sequential Write up to (MB/s) (Queues=32, Threads=1) 1,600 2,600 3,000 2,900

Random Read 4KB IOPS up to (Queues=32, Threads=8) 220K 420K 515K 480K

Random Write 4KB IOPS up to (Queues=32, Threads=8) 180K 380K 560K 550K

Endurance

(TBW) 200 300 600 1,200

Power

Peak Power (10us) 2.8A 2.8A 2.8A 2.8A

PS3 (low power)

70mW 70mW 100mW 100mW

Sleep (PS4) (low power) 2.5mW 2.5mW 2.5mW 2.5mW

Reliability

MTTF

1,750,000 hours (Telcordia SR-332, GB, 40°C)

Product Safety/Regulatory

Operating Temperatures

32°F to 158°F (0°C to 70°C)

Non-operating Temperatures

-67°F to 185°F (-55°C to 85°C)

Certiﬁcations UL, TUV, CE, BSMI, FCC, KCC, RCM, Morocco, VCCI

Limited Warranty (years)

5 years

Physical Dimensions M.2 2280

Form Factor M.2 2280-S3-M

Length 80 ± 0.15mm

Width 22 ± 0.15mm

Height 2.38mm

Weight 7.5g ± 1g

Ordering Information 250GB 500GB 1TB 2TB

Model Numbers Without Heatsink WDS250G3X0C WDS500G3X0C WDS100T3X0C WDS200T3X0C

1 Backward compatible with PCIe Gen3 x2, PCIe Gen3 x1, PCIe Gen2 x4, PCIe Gen2 x2, and PCIe Gen2 x1.

2 As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, megabit per second (Mb/s) = one million bits per second, and gigabit per second (Gb/s) = one billion bits per second. IOPS =

input/output operations per second. Performance will vary depending on your hardware and software components and conﬁgurations.

3 Not all products may be available in all regions of the world. As used for storage capacity, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on

operating environment.

4 TBW (terabytes written) values calculated using JEDEC client workload (JESD219) and vary by product capacity.

5 Measured using MobileMark™ 2014 on HP EliteBook X360 1030 G2 with i7–7600U, 8GB RAM. Windows 10 Pro 64-bit RS3 using Microsoft StorNVMe driver, Primary drive.

6 MTTF = Mean Time To Failure based on internal testing using Telcordia stress part testing (Telcordia SR-332, GB, 25°C). MTTF is based on a sample population and is estimated by statistical measurements and acceleration

algorithms. MTTF does not predict an individual drive’s reliability and does not constitute a warranty.

7 Operational temperature as reported by device (composite temperature).

8 Non-operational storage temperature does not guarantee data retention.

9 5 years or Max Endurance (TBW) limit, whichever occurs ﬁrst. See support.wdc.com for regional speciﬁc warranty details.

PRODUCT BRIEF

Produkspesifikasjoner

Merke:	Western Digital
Kategori:	Harddisk
Modell:	Black SN750
Vekt:	7.5 g
Bredde:	22 mm
Dybde:	80 mm
Høyde:	2.38 mm
Sertifisering:	FCC, UL, TUV, KCC, BSMI, VCCI, C-Tick
SSD-kapasitet:	2000 GB
SSD-formfaktor:	M.2
Komponent for:	PC /Laptop
NVMe:	Ja
Dataoverføringshastighet:	8 Gbit/s
Driftstemperatur (T-T):	0 - 70 °C
Oppbevaringstemperaturomåde (Celsius):	-55 - 85 °C
Strømforbruk (hvilemodus):	0.0025 W
Videoopptaksgrensesnitt:	PCI Express 3.0
Gjennomsnittstid mellom feil (MTBF):	1750000 timer
Lesehastighet, medier:	3400 MB/s
Skrivehastighet/brennehastighet:	2900 MB/s
Tilfeldig lese (4KB):	480000 IOPS
Tilfeldig skrive (4kB):	550000 IOPS
TBW-gradering:	1200
PCI Express-grensesnitt datafelt:	x4
