Installation Guide
AR-5 Ranger Cre
w
5 Speaker Audio Roof with Lighting
OFF
SYSTEM
POWER
ON
The AR-5 Ranger Crew is designed as a quick plug and play install.
To ensure proper installation and your safety, please follow the tips
mentioned below and the installation instructions provided.
H4 (4mm) Allen
T35 Torx
Ratchet
Installation prep:
Take a few minutes to review the AR-5 installation guide
Tools needed on hand:
$ODUJHÁDWRSHQZRUNDUHDLVUHFRPPHQGHGGXULQJLQVWDOODWLRQ
Make sure the vehicle is parked and secured in place.
Disconnect the battery before working on the vehicle.
Have a minimum of 4-6 people to help lift the roof.
AR-5 Ranger Crew
Before you drop in the
17mm Socket
1
For safety reasons, we
recommend disconnecting
the battery before starting
the installation.
2
Remove any existing roof or
roof rail accessories from
the vehicle.
3
Lift the AR-5 Ranger Crew out of the
box using four to six people.
Carry the roof carefully to the vehicle and
place it on the RANGER
®
roof rails.
4
5
Be careful not to bump the speaker grilles while
lifting the roof over the rails.
Included Hardware:
(4) Roof Clamps
(8) M5 Button Head Screw
(6) Short M6 Torx Screw
(4) Zip Ties
(2) M6 Flange Locknut
6
Fasten the back of the roof with the (4) M6 torx
screws provided.
7
Use (2) M6 torx screws and (2) M6 flange
locknuts to fasten the front of the roof. Do not
overtighten the screws.
8
Attach the (4) center clamps with the (8) M5 screws
provided to secure the roof to the center roof rail.
9
Secure the wiring harness to the post by using
(2) zip ties near the locations marked above.
10
Wire the harness towards the battery and
secure it to avoid it touching hot or moving
parts. Extra (2) zip ties are included if needed.
11
Connect the red wire to the
positive battery terminal.
Followed by the black wire to the
negative terminal.
12
Fully reconnect the battery after
the roof harness has been
connected.
OFF
SYSTEM
POWER
ON
13
Flip the system power on and enjoy
Wet Sounds high performance audio.
Thank you for choosing this Wet Sounds™ product!
If you have any questions or concerns, please contact a certified Wet Sounds dealer. You may also contact Wet Sounds technical
support by dialing 1-877-WET-SPKR (1-877-938-7757).
