Side 1/12
SUPER DENTON
Important Safety Information
Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.
Before making any connections, switch all the units in your system off at the mains.
Set the volume control at minimum when you switch on your system or change sources, and turn the level
up gradually.
DO NOT use your amplifier at full volume.
Ensure that all loudspeakers in the system are correctly wired.
DO NOT subject your loudspeakers to excessive cold, heat, humidity or sunlight.
Loudspeakers should not be placed directly facing other hi-fi units, or share the same shelf or cabinet.
DO NOT place heavy objects on top of loudspeakers.
Some manufacturers forbid the placing of objects on top of their TV sets. Check your TV handbook before
installing the speaker directly on your TV set. Consult your TV dealer if you are in any doubt.
DO NOT connect speaker terminals to the mains supply.
DO NOT dismantle the loudspeaker. There are no user-serviceable parts inside it and you will void the
warranty by doing so.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, the apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
Changes or modifications not expressly approved by the manufacturer will void any warranty.
Before installing this product read all these instructions!
This symbol indicates that there are important operating and maintenance
instructions in the literature accompanying this unit.
Wharfedale’s new SUPER DENTON is part of Wharfedale’s Heritage series, based on classic designs from
Wharfedale’s past but brought right up to date with modern drive unit, cabinet and crossover technology.
When the Denton 3 was introduced, in 1971, its brochure claimed that it “succeeds in combining 3 speakers … in a very
small cabinet. The resulting sound will surprise anyone who believes that high fidelity is only obtainable with larger
cabinets”.
Today, Wharfedale’s engineers have replicated that concept with exactly the same aim in mind. We call it ‘SUPER
DENTON’.
SUPER DENTON is formulated from three advanced drive units – a 6.5 inch (165mm) woven Kevlar cone bass unit, a
2 inch (50mm) dome midrange unit and a 1 inch (25mm) soft-dome treble unit.
The bass unit and cabinet are tuned to achieve a remarkable bass extension down to 40Hz, below the fundamental
E1 tuning of a standard bass guitar, with the woven Kevlar diaphragm providing realistic performance from
instruments and vocals in the lower midrange.
Upper midrange and lower treble output comes from a midrange unit based on the technology of the
award-winning EVO 4 loudspeakers. Here the 2 inch fabric dome driver provides the ideal transition from the
fundamental tones carried by the bass unit to the harmonic overtones higher in frequency. The wide dispersion of
this dome diaphragm is responsible for the clarity and finesse that brings the musical performance alive into your
living room.
Perfectly matched to this advanced midrange dome unit is the new 1 inch soft dome treble unit, inheriting the
ceramic magnet motor system and rear chamber used in the Dovedale Heritage, to better match the detailed
performance of its companion drivers.
Naturally, the advanced performance of these three drive units requires an equally highly researched crossover.
Developed over hundreds of hours of listening tests, the SUPER DENTON crossover matches the acoustic
performance of the drive units to achieve a seamless transition between them. Utilising air core coils and
high-specification polypropylene capacitors for midrange and treble circuits, the crossover enhances the clear and
realistic detailing that emerges effortlessly from this advanced bookshelf loudspeaker.
Even the grille incorporates internal shaping to maximize the power performance of the drive units and avoid
interference from reflections from the edges of the cabinet. The result is a musical output that suits all genres of
music and sources, whether analogue or digital. You can rest assured that SUPER DENTON will delight you and
satisfy you with musical entertainment for years to come.
In 1979, Peter Comeau co-founded Heybrook Hi-Fi to design and manufacture the
multi-award-winning HB1 and classic HB2 loudspeakers. In 2009, after leading IAG
speaker development since the acquisition of Mission, Peter assumed overall
acoustic design responsibility for all of the brands within the Group, including
Wharfedale. With a deep respect for the history of these brands and the necessity to
maintain each individual brand’s design integrity, Peter continues to design
award-winning speakers at IAG’s research centres in Huntingdon, England, and
Shenzhen, China.
