Side 1/204
EN
Owner's Manual
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . register10 . eu
PLEASE SCAN THE QR CODE ON
YOUR APPLIANCE IN ORDER TO
REACH MORE INFORMATION
Before using the appliance carefully read the
Safety Instruction.
PRODUCT DESCRIPTION
1. Control panel
2. Extractable drawer
3. Fan
4. Circular heating element
(not visible)
5. Shelf guides
6. Door
7. Lamp
8. Grill
9. Food probe insert point
10. Identification plate
(do not remove)
11. Lower heating element
(not visible)
CONTROL PANEL DESCRIPTION
1
2 3 4 5
76 8 9
1. ON / OFF
For switching the oven on and off
2. HOME
For quick access to the main menu.
3. TOOLS
To choose from several options and also change the
oven settings and preferences.
4. FAVORITES
For retrieving up the list of your favorite functions.
5. DISPLAY
6. TIMER
This function can be activated either when using a
cooking function or alone for keeping time.
7. LO CK
Enables you to lock the buttons on the touch
pad so they cannot be pressed accidently.
8. LIGHT
To switch on or off the oven lamp and save energy.
9. START
For starting a function.
1
3
2
4
5
6
7
8
9
10
11
ACCESSORIES
Before purchasing other accessories that are available
on the market, make sure that they are heat-resistant
and suitable for steaming.
Make sure that there is a gap of at least 30 mm
between the top of any container and the walls of the
cooking compartment in order to allow steam to ow
suciently.
WIRE SHELF
The wire shelf is suitable for
all cooking modes.
You can place food directly
on the wire shelf or use it to
support baking trays and tins
or other oven-ware resistant
to heat.
BAKING TRAY
The baking tray is suitable
for all cooking modes and
functions. Can be used to
cook all kind of foods without
container. Use it to collects
the cooking juices, placing it
below the wire shelf.
STEAM TRAY
This special perforated tray
makes it easier for steam to
circulate, which helps cook the
food evenly.
Place the drip tray on the level
below to collect the cooking
juices with the stopping
features towards the back of
the product.
FOOD PROBE
To accurately measure the
core temperature of food
during cooking.
It can be used for meat and
fish.
The number of accessories may vary depending on which
model is purchased.
*Other accessories can be purchased separately from the
After-sales Service.
INSERTING THE WIRE SHELF AND OTHER
ACCESSORIES
Insert the wire shelf onto the level you require by
holding it tilted slightly upwards and resting the
raised rear side (pointing upwards) down first.
Then slide it horizontally along the runners as far as
possible. Other accessories, like the baking tray, are
to be inserted horizontally, letting them slide on the
runners
INSERTING THE STEAM TRAY
The steam tray must be inserted with the reference
lateral embosses towards the back of the cavity as
illustrated in the picture:
REMOVING AND REFITTING THE LADDER RACKS
There is a ladder rack on both sides of the oven
cavity, anchored on two button-shaped supports. The
ladder racks are removable to make cleaning more
convenient.
1. To remove the ladder racks, firmly grip the external
part of the guide, and pull it upwards to extract it
from the frontal support while rotating on the rear
support, then slide out the whole part from the
cavity.
2. To reposition the ladder racks, slide the back part
on the back support. Then, once slipped, by pivoting
the rear support, pull the assy down until the ladder
rack hooks on the frontal support.
