Side 1/80

Owner's Manual

CONTROL PANEL DESCRIPTION

2 3 4 5 76 8 9

1. ON / OFF

For switching the oven on and off

2. HOME

For quick access to the main menu.

3. TOOLS

To choose from several options and also change the

oven settings and preferences.

4. FAVORITES

For retrieving up the list of your favorite functions.

5. DISPLAY

6. TIMER

This function can be activated either when using a

cooking function or alone for keeping time.

7. LO CK

Enables you to lock the buttons on the touch

pad so they cannot be pressed accidently.

8. LIGHT

To switch on or off the oven lamp and save energy.

9. START

For starting a function.

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

PLEASE SCAN THE QR CODE ON

YOUR APPLIANCE IN ORDER TO

REACH MORE INFORMATION

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

1. Control panel

2. Extractable drawer

3. Fan

4. Circular heating element

(not visible)

5. Shelf guides

6. Door

7. Lamp

8. Grill

9. Food probe insert point

10. Identification plate

(do not remove)

11. Lower heating element

(not visible)

ACCESSORIES

Before purchasing other accessories that are available

on the market, make sure that they are heat-resistant

and suitable for steaming.

Make sure that there is a gap of at least 30 mm

between the top of any container and the walls of the

cooking compartment in order to allow steam to ow

suciently.

Accessories during microwave function may raise in

temperature. It is recommended to use protection to

handle accessories at the end of the cycle.

WIRE SHELF

The wire shelf is suitable for

all cooking modes, also in

Microwave cooking. When

using microwaves place the

wire shelf always on level 1

(the lower one). You can place

food directly on the wire shelf

or use it to support baking

trays and tins or other oven-

ware resistant to heat and

microwaves.

BAKING TRAY

The baking tray is suitable

for all cooking modes except

for “Microwave” functions.

Can be used to cook all kind

of foods without container.

Use it to collects the cooking

juices, placing it below the

wire shelf.

HANDLE FOR CRISP PLATE

Useful for removing the hot

Crisp plate from the oven.

STEAMER*

(ONLY IN SOME MODELS)

To steam foods such as fish

or vegetables, place these

in the basket (2) and pour

drinking water (100 ml) into

the bottom of the steamer (3)

to achieve the right amount

of steam.

To boil foods such as

potatoes, pasta, rice or

cereals, place these directly

on the bottom of the steamer

(the basket is not required)

and add an appropriate

amount of drinking water for

the amount you are cooking.

For best results, cover the

steamer with the lid (1)

provided.

Always place the steamer

on the wire shelf at level

1 and only use it with

the appropriate cooking

functions, or with microwave

function.

FOOD PROBE

To accurately measure the

core temperature of food

during cooking.

Thanks to its rigid support, it

can be used for meat and fish.

CRISP PLATE

Only for use with the

designated functions.

The Crisp plate must always

be placed in the center of

the wire shelf and can be

pre-heated when empty,

using the special function

for this purpose only. Place

the food directly on the Crisp

plate. Place the silicone feet

between the bars of the wire

shelf for added stability.

The number of accessories may vary depending on which

model is purchased.

*Other accessories can be purchased separately from the

After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf onto the level you require by

holding it tilted slightly upwards and resting the

raised rear side (pointing upwards) down first.

Then slide it horizontally along the runners as far as

possible. Other accessories, like the baking tray, are

to be inserted horizontally, letting them slide on the

runners

Push the accessories all the way in, making sure, that

it does not touch the appliance door.

FUNCTIONS

MANUAL MODES

MICROWAVE

For quickly cooking and reheating food or

drinks.

Required accessories: wire shelf, microwave-safe and

heatproof container.

POWER (W) RECOMMENED FOR

950

Quickly reheating drinks or other foods with a high

water content. If the food contains egg or cream

choose a lower power.

750 Cooking vegetables.

600 Cooking meat, sh and dishes that cannot be stirred.

500

Cooking meaty sauces, or sauces containing cheese

or egg. Finishing o meat pies or pasta bakes.

350

Slow, gently cooking. Perfect for melting butter or

chocolate.

160

Defrosting frozen foods or softening butter and

cheese.

90 Softening ice cream.

ACTION FOOD POWER (W) DURATION (min)

Reheat 2 cups 950 1 - 2

Cook Sponge cake 750 5 - 6

Cook Egg custard 750 10 - 12

Cook Meat loaf 600 15 - 25

CRISP

For perfectly browning a dish, both on the top

and bottom of the food. This function must only be

used with the special Crisp plate.

Required accessories: wire shelf at level 1, Crisp plate, handle

for the Crisp plate.

FOOD DURATION (min)

Leavened cake 10 - 12

Hamburgers* 9 - 15

*Turn food halfway through cooking

CRISP FRY: Fresh Foods and Frozen Foods

This healthy and exclusive function combines the

quality of crisp function with the properties of the

warm air circulation. It allows crunchy, tasty frying

results to be achieved, with a remarkable reduction

of oil needed compared to the traditional way of

cooking, even removing the need for oil in some

recipes.

To achieve best results with fresh foods brush or

season with a little quantity of oil. Cook frozen food

directly without any addition of oil.

Required accessories: wire shelf at level 1, Crisp plate, handle

for the Crisp plate.

FAST PREHEAT

For quickly preheating the oven before a

cooking cycle. Wait for the function to finish before

placing food inside the oven. Once preheating has

finished, the oven will select the “Forced Air” function

automatically.

Required accessories: wire shelf with pan or baking tray

GRILL

For browning, grilling and gratins. We

recommend turning the food during cooking.

Recommended accessories: wire shelf

FOOD GRILL LEVEL DURATION (min)

Toast High 5 - 6

GRILL + MW

For quickly cooking and gratinating dishes,

combining the microwave and grill functions.

Required accessories: wire shelf at level 1, microwave-safe

and heatproof container.

TURBO GRILL

For perfect results, combining the grill and

oven air convection. We recommend turning the food

during cooking.

Recommended accessories: wire shelf

TURBO GRILL + MW

For quickly cooking and browning your food,

combining the microwave, grill and the oven air

convection.

Required accessories: wire shelf at level 1, microwave-safe

and heatproof container.

REMOVING AND REFITTING THE LADDER RACKS

There are two ladder racks on both sides of the oven

cavity, anchored on two button-shaped supports. The

ladder racks are removable to make cleaning more

convenient.

1. To remove the ladder racks, firmly grip the

external part of the guide, and pull it upwards to

extract it from the frontal support while rotating on

the rear support, then slide out the whole part from

the cavity.

2. To reposition the ladder racks, slide the back part

onto the rear support. Then, once anchored, push the

assy down until the ladder rack is inserted into the

frontal support.
