Owner’s Manual

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

PLEASE SCAN THE QR CODE ON

YOUR APPLIANCE IN ORDER TO

REACH MORE INFORMATION

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

1. Control panel

2. Ladder racks

(the level is indicated on the front

of the oven)

3. Door

4. Upper heating element/grill

5. Lamp

6. Meat probe insert point

(if present)

7. Identification plate

(do not remove)

8. Lower heating element

(not visible)

CONTROL PANEL DESCRIPTION

5 7

1. SELECTION KNOB

For switching the oven on by 0

selecting a function. Turn to the

position to switch the oven off.

2. BACK

For returning to the previous

screen.

3. STOP

To pause a cooking cycle.

4. DISPLAY

5. START

For starting a function using the

specified or basic settings.

6. CONFIRM

For confirming a selected function

or a set value.

7. KNOB

ACCESSORIES

Before purchasing other accessories that are available

on the market, make sure that they are heat-resistant

and suitable for steaming.

Make sure that there is a gap of at least 30 mm

between the top of any container and the walls of the

cooking compartment in order to allow steam to ow

suciently.

Accessories during microwave function may raise in

temperature. It is recommended to use protection to

handle accessories at the end of the cycle.

WIRE SHELF BAKING TRAY CRISP PLATE

HANDLE FOR CRISP

PLATE

The wire shelf is suitable

for all cooking modes, also

in Microwave cooking.

When using microwaves

place the wire shelf always

on level 1 (the lower one).

You can place food directly

on the wire shelf or use it

to support baking trays

and tins or other oven-

ware resistant to heat and

microwaves.

The baking tray is suitable

for all cooking modes

except for “Microwave”

functions. Can be used

to cook all kind of foods

without container. Use it

to collects the cooking

juices, placing it below the

wire shelf.

Only for use with the

designated functions.

The Crisp plate must

always be placed in the

center of the wire shelf and

can be pre-heated when

empty, using the special

function for this purpose

only. Place the food directly

on the Crisp plate. Place

the silicone feet between

the bars of the wire shelf

for added stability.

Useful for removing the

hot Crisp plate from the

oven.

The number of accessories may vary depending on which model is purchased.

*Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf onto the level you require by

holding it tilted slightly upwards and resting the

raised rear side (pointing upwards) down first.

Then slide it horizontally along the runners as far as

possible. Other accessories, like the baking tray, are

to be inserted horizontally, letting them slide on the

runners.

Push the accessory all the way in, making sure that it

does not touch the appliance door.

REMOVING AND REFITTING THE LADDER RACKS

There are two ladder racks on both sides of the oven

cavity, anchored on two button-shaped supports. The

ladder racks are removable to make cleaning more

convenient.

1. To remove the ladder racks, firmly grip the

external part of the guide, and pull it upwards to

extract it from the frontal support while rotating on

the rear support, then slide out the whole part from

the cavity.

2. To reposition the ladder racks, slide the back part

onto the rear support. Then, once anchored, push the

assy down until the ladder rack is inserted into the

frontal support.

FUNCTIONS

MICROWAVE

Use microwave function only with food or beverages

inside to preserve the correct functionality of the

product.

Required accessories: wire shelf, microwave-safe and

heatproof container.

POWER (W) RECOMMENED FOR

950

Quickly reheating drinks or other foods with a high

water content. If the food contains egg or cream choose

a lower power.

750 Cooking vegetables.

600 Cooking meat, sh and dishes that cannot be stirred.

500

Cooking meaty sauces, or sauces containing cheese or

egg. Finishing o meat pies or pasta bakes.

350 Slow, gently cooking. Perfect for melting butter or chocolate.

160 Defrosting frozen foods or softening butter and cheese.

90 Softening ice cream.

ACTION FOOD POWER (W) DURATION (min)

Reheat 2 cups 950 1 - 2

Cook Sponge cake 750 5 - 6

Cook Egg custard 500 10 - 12

Cook Meat loaf 600 15 - 25

CRISP

For perfectly browning a dish, both on the top and

bottom of the food. This function must only be used

with the special Crisp plate.

Required accessories: wire shelf at level 1, Crisp plate, handle

for the Crisp plate

FOOD GRILL LEVEL DURATION (min)

Toast Hight 5 - 6

GRILL

For browning, grilling and gratins. We recommend

turning the food during cooking.

Recommended accessories: wire shelf

GRILL + MW

For quickly cooking and gratinating dishes, combining

the microwave and grill functions.

Required accessories: wire shelf at level 1, microwave-safe

and heatproof container.

CONVENTIONAL

For perfectly cooking and browning both on the top

and bottom any kind of dish on one shelf only. To

achieve best results this function have the preheating

phase: wait the end of preheat to insert the food.

Required accessories: baking tray or wire shelf and heatproof

container.

FOOD TEMP. (°C) DURATION (min)

Cupcake / Smallcakes 160 20 - 25

Cookies 165 15 - 20

CONVENTIONAL + MW

For preparing baked dishes more quickly by

combining the conventional oven and the microwave.

Required accessories: wire shelf at level 1, microwave-safe

and heatproof container.

SENSE FUNCTIONS

With the 6th Sense functions, simply select the type

and weight or the quantity of the food items to obtain

the best results.The oven will automatically calculate

the optimum settings and continue to change them

as cooking progresses. To use at best this function,

follow the indications on the relative cooking table.

Due to food variability, the cooking duration is set on

an average grade. We always recommend to check

the internal doneness of food and in case prolong

the cooking time to achieve proper doneness. Some

automatic cycles give the possibility of previously

setting a cooking level lower or higher than the default

(see the Doneness paragraph in the Daily Use section).

SENSE DEFROST

For quickly defrosting various different types of food.

Always place the food in a container directly on the

wire shelf for best results, except for Crisp Bread

Defrost. At the end let the food stand for 5 minutes.

CRISP BREAD DEFROST

This exclusive Whirlpool function allows you to

defrost frozen bread. Combining both Defrost and

Crisp technologies, your bread will taste and feel as

if it were freshly baked. Use this function to quickly

defrost and heat frozen rolls, baguettes & croissants.

The Crisp Plate must be used in combination with this

function, directly placed on wire shelf.

FOOD WEIGHT

Timed Defrost -

Meat 100 g - 2.0 kg

Poultry 100 g - 3.0 kg

Fish 100 g - 2.0 kg

Crisp Bread

Defrost

50 - 800 g

SENSE REHEAT

For reheating ready-made food that is either frozen

or at room temperature. The oven automatically

calculates the settings required to achieve the best

results in the shortest amount of time. Place food on

a microwave- safe and heatproof dinner plate or dish

directly on wire shelf at level 1.

Food

Weight/

portions/

pieces

Note

Plated Meal 250 - 800 g

Take out from packaging being careful to

remove any aluminium foil. At the end of

reheating process 1-2 minutes standing

time always improves the result.

Lasagna

[frozen]

400 g - 1.5 kg

Take out from packaging being careful to

remove any aluminium foil.

Soup 100 - 800 g Heat uncovered in a single container.

Water 100 - 500 g Heat uncovered in a single container.
