Side 1/3

60" DUAL FUEL RANGE - 6 BURNERS AND FRENCH TOP

DF60650F/S/P

FEATURES

Wolf’s patented gas dual-stacked, sealed burner design provides precise

high-to-low temperature control and a spark ignition system that reignites

the burner automatically

Wolf’s Dual VertiFlow™ convection system provides reliably even heat,

reduces hot and cold spots, and enables consistent multi-rack cooking

Gourmet Mode features nearly 50 presets that automatically control the

oven to ensure delicious results

Ten cooking modes, including Bake, Broil, Convection, Convection Roast,

Dehydrate, Gourmet, Proof, Roast, Stone, and Warm, were developed by

Wolf chefs to maximize the performance of your oven

Easily slide pots across the French top for a graduated cooking surface

with the highest temperature under the center plate and the lowest closer

to the outer edges

Six dual-stacked burners produce up to 20,000 Btu for fast boils and

intense sears and 300 Btu for true simmers and worry-free melts

For improved temperature control and safety, the spark ignition system

reignites burners automatically

The full-color touch screen is intuitive and easy to read, discreetly hiding

away when not in use

LED backlit control knobs illuminate when in use, indicating which

burners are active

The oven offers self-clean, delayed start, timed cook, and Sabbath

features

The temperature probe alerts you when your dish has reached the

desired temperature.

The oven’s Wi-Fi enabled feature lets you remotely preheat, select

modes, and adjust oven temperature from your mobile device

Create a cohesive look in your kitchen with the range’s stainless steel

construction, pro style handles, and choice of iconic red, black, or

brushed stainless knobs

ACCESSORIES

2-Burner Wok Grate

30" Broiler Pan

30" Dehydration Rack Set

30" Full-Extension Ball-Bearing Oven Rack

30" Premier Baking Sheet

30" Standard Oven Rack

Bake Stone Kit

Filler Trim

Temperature Probe

Signature red, black or stainless steel control knobs

Rear Caster Covers

Front Leg Extension Covers

Stainless Steel Kickplates

5" and 10" stainless steel risers, and 20" riser with shelf

KNOB OPTIONS

TOP CONFIGURATION

RANGETOP SPECIFICATIONS

• 1 - 9,200 Btu burner

• 2 - 15,000 Btu burners

• 2 - 18,000 Btu burners

• 1 - 20,000 Btu burner

• 1 - 15,000 Btu French top

• Stainless-steel french top cover

• Stainless-steel island trim riser included

Accessories available through an authorized dealer.

For local dealer information, visit subzero-wolf.com/locator.

Specifications are subject to change without notice. This information was generated on September 20, 2022. Verify specifications prior to finalizing your cabinetry/enclosures.

60" DUAL FUEL RANGE - 6 BURNERS AND FRENCH TOP

PRODUCT SPECIFICATIONS

Model DF60650F/S/P

Dimensions 59 7/8"W x 36 1/2"H x 29 1/2"D

Oven 1 Interior

Dimensions

25 1/4"W x 17 1/2"H x 20"D

Oven 2 Interior

Dimensions

25 1/4"W x 17 1/2"H x 20"D

Oven 1 Usable Capacity 3.2 cu. ft.

Oven 1 Overall Capacity 5.1 cu. ft.

Oven 2 Usable Capacity 3.2 cu. ft.

Oven 2 Overall Capacity 5.1 cu. ft.

Door Clearance 20 3/8"

Electrical Supply 240/208 VAC, 60 Hz

Electrical Service 50 amp dedicated circuit

Gas Supply 3/4" ID line

Gas Inlet 1/2" NPT female

ELECTRICAL GAS

NOTE: Dimensions in parenthesis are in millimeters unless otherwise

specified

DIMENSIONS

STANDARD INSTALLATION

Specifications are subject to change without notice. This information was generated on September 20, 2022. Verify specifications prior to finalizing your cabinetry/enclosures.
