36" PROFESSIONAL INDUCTION RANGE

IR36550/S/P

FEATURES

The scratch-resistant, ceramic glass induction cooking surface provides

consistent, precise temperature control and nearly instantaneous

temperature adjustment response

Wolf’s Dual VertiFlow™ convection system provides reliably even heat,

reduces hot and cold spots, and enables consistent multi-rack cooking

Gourmet Mode features nearly 50 presets that automatically control the

oven to ensure delicious results

Take the guesswork out of cooking with 10 chef-created cooking modes,

including Bake, Broil, Convection, Convection Roast, Dehydrate,

Gourmet, Proof, Roast, Stone, and Warm

The sleek rangetop features a striking interactive display. The full-color

touchscreen is intuitive, easy to read, and locks for safety and cleaning

Boost Mode delivers rapid heat for lightning-fast boil times

The Bridge function joins two induction zones into one large area,

enabling use of an induction-capable griddle, open roaster, or fish poacher

Because the cooktop stays relatively cool, spills don't stick to the

surface—making cleanup a breeze

The oven offers self-clean, delayed start, timed cook, and Sabbath

features

The temperature probe alerts you when your dish has reached the

desired temperature

The oven’s Wi-Fi enabled feature lets you remotely preheat, select

modes, and adjust oven temperature from your mobile device

The range’s stainless-steel construction and heavy-duty handles

coordinate with a full suite of PRO-style Sub-Zero, Wolf, and Cove

appliances

ACCESSORIES

30" Broiler Pan

30" Premier Baking Sheet

36" Dehydration Rack Set

36" Full-extension ball-bearing oven rack

Bake Stone Kit

Temperature Probe

Rear Caster Covers

Front Leg Extension Covers

Stainless Steel Kickplates

Accessories available through an authorized dealer.

For local dealer information, visit subzero-wolf.com/locator.

TOP CONFIGURATION

COOKTOP SPECIFICATIONS

• Five induction zones

• 4 - 8" 2,100 Watt element with 3,700 W boost

• 1 - 11" 2,600 W Zone with 3,700 W Boost

Specifications are subject to change without notice. This information was generated on June 17, 2023. Verify specifications prior to finalizing your cabinetry/enclosures.

36" PROFESSIONAL INDUCTION RANGE

PRODUCT SPECIFICATIONS

Model IR36550/S/P

Dimensions 35 7/8"W x 35 1/2"H x 29 1/2"D

Oven 1 Interior

Dimensions

31 1/4"W x 17 1/2"H x 20"D

Oven 1 Usable Capacity 4.1 cu. ft.

Oven 1 Overall Capacity 6.3 cu. ft.

Door Clearance 21"

Weight 445 lbs

Electrical Supply 240/208 VAC, 60 Hz

Electrical Service 50 amp dedicated service

ELECTRICAL

NOTE: Dimensions in parenthesis are in millimeters unless otherwise

specified

IMPORTANT NOTE: Adjacent countertops must be at least 35 7/8" for

flush installation to top of unit.

STANDARD INSTALLATION

Specifications are subject to change without notice. This information was generated on June 17, 2023. Verify specifications prior to finalizing your cabinetry/enclosures.
