Side 1/20
漏ITW Food Equipment Group, LLC
3600 North Point Blvd.
Baltimore, MD 21222
RETAIN THIS MANUAL FOR FUTURE USE
FORM F-36951 (9-15)
INSTALLATION & OPERATION MANUAL FOR
STOCKPOT RANGE
MODELS
VSP100
WSPR1
VSP200F
WSPR2F
For additional information on Vulcan or to locate an authorized parts and
service provider in your area, visit our website at www.vulcanequipment.com
- 2 -
IMPORTANT FOR YOUR SAFETY
THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO
INSTALL GAS EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD
START-UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS
MANUAL.
POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN
THE EVENT THE SMELL OF GAS IS DETECTED. THIS INFORMATION CAN BE
OBTAINED FROM THE LOCAL GAS SUPPLIER.
IMPORTANT
IN THE EVENT A GAS ODOR IS DETECTED, SHUT
DOWN UNITS AT MAIN SHUTOFF VALVE AND
CONTACT THE LOCAL GAS COMPANY OR GAS
SUPPLIER FOR SERVICE.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
IN THE EVENT OF A POWER FAILURE, DO NOT
ATTEMPT TO OPERATE THIS DEVICE.
Improper installation,
adjustment, alteration, service or maintenance
can cause property damage, injury, or death.
Read the installation, operating and maintenance
instructions thoroughly before installing or
servicing this equipment.
- 3 -
INSTALLATION, OPERATION AND CARE OF
STOCKPOT RANGE
GENERAL
Stockpot ranges are designed for commercial use only and feature fast, efficient gas
heat. Each burner is controlled by an adjustable gas valve. Heavy-duty, cast iron top
grate(s) are easily removed for cleaning when cool. A grease drawer is provided to collect
fat run-off; it opens to the front for inspection or drain-off.
Model
# of
Burners
Natural Gas BTU/hr
Input Rating
Propane Gas BTU/hr
Input Rating
VSP100,WSPR1
2
110,000
90,000
VSP200F,WSPR2F
4
220,000
180,000
INSTALLATION
UNPACKING
This stockpot was inspected before leaving the factory. The carrier assumes full responsibility for the
safe delivery upon acceptance of the shipment. Check for possible shipping damage immediately after
receipt.
If the stockpot is found to be damaged, complete the following steps:
1. Carrier must be notified within 5 business days of receipt.
2. Carrier鈥檚 local terminal must be notified immediately upon discovery (note time, date, and
who was spoken to), and follow up and confirm with written or electronic communication.
3. All original packing materials must be kept for inspection purposes.
4. The stockpot cannot have been moved, installed, or modified.
5. Notify Vulcan Customer Service immediately at 800-814-2028.
Remove all packing material and protective plastic from the surfaces of the unit.
Before installing, verify that the type of gas (natural or propane) and the clearance
dimensions agree with the specifications on the rating plate which is located at the back
of the stockpot.
