Xiaomi Mi 65W Fast Charger with GaN Tech Bruksanvisning

Xiaomi Batterilader Mi 65W Fast Charger with GaN Tech

Les nedenfor 📖 manual på norsk for Xiaomi Mi 65W Fast Charger with GaN Tech (37 sider) i kategorien Batterilader. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/37

User Manual Version: V1.0

Mi 65W Fast Charger with GaN Tech User Manual 1

Manual de usuario de Mi 65W Fast Charger with GaN

Tech 4

Manuale utente Mi 65W Fast Charger with GaN Tech 7

Manuel d'utilisation de Mi 65W Fast Charger with GaN

Tech 10

Mi 65-W-Schnellladegerät mit GaN Tech

Benutzerhandbuch 13

Руководство пользователя Быстрого зарядного

устройства Mi GaN, 65 Вт 16

Manual do utilizador do Carregador rápido Mi 65 W com

tecnologia GaN 19

Посібник користувача Швидкого зарядного пристрою

Mi GaN, 65 Вт 22

Mi 65 W Hızlı Şarj Cihazı (GaN Teknolojisi) Kullanım

Kılavuzu 25

Szybka ładowarka Mi 65 W z technologią GaN Instrukcja

obsługi 28

Mi 65 W Snellader met GaN-technologie

Gebruikershandleiding 34

Mi ﻦﻣ طاو 65 ةﻮﻘﺑ GaN Tech ﻊﻳﺮﺴﻟا ﻦﺣﺎﺸﻟا مﺪﺨﺘﺴﻤﻟا ﻞﻴﻟد 31

Read this manual carefully before use, and retain it for future reference.

Thank you for choosing Mi 65W Fast Charger

with GaN Tech. Adopting the material of GaN

(gallium nitride), this charger is compact and

portable with the maximum output power of

65W. It is compatible with most of the devices

on the market.

Illustrations of product, accessories, and user interface in the user manual

are for reference purposes only. Actual product and functions may vary

due to product enhancements.

Product Overview

Safety: Multiple protective functions including short circuit protection,

overcurrent protection, overvoltage protection, overheating protection,

Product Features

Name: Mi 65W Fast Charger with GaN Tech Model: AD65GEU

Input: 100–240 V ~ 50/60 Hz 1.7 A

Output: 5.0 V=3.0 A 15.0 W 9.0 V=3.0 A 27.0 W 10.0 V=5.0 A 50.0 W

12.0 V=3.0 A 36.0 W 15.0 V=3.0 A 45.0 W 20.0 V=3.25 A 65.0 W Max.

Operating Temperature: 0°C to 40°C

Item Dimensions: 31.2 × 30.8 × 74.4 mm (excl. prongs)

Average Active Eﬃciency: 84.0 %

Eﬃciency at 10% Load: 70.0 %

No-load Power Consumption: 0.06 W

Speciﬁcations

USB-C

and undervoltage protection. Equipped with a high-precision current-limit

chip in the USB-C port, the charger is always guaranteed to work within

the normal current range. Its shell is made of V0 grade material featuring

in ﬁreproof and high-temperature resistant, the charger is safe and reliable.

Compatibility: With the built-in intelligent identiﬁcation chip, the charger

is compatible with most electronic devices on the market, such as phones

and laptops.

Port: USB-C design that supports the fast charging up to 65 W.

Appearance: Ultra-small with 2-prong plug, compact and portable.

Applicability: Operating altitude ranges up to 5000 meters.

Do not disassemble this charger.

Do not expose this charger to heat sources, ﬁre, or environments with

ambient temperatures over 60°C (140°F). Do not leave this charger in

direct sunlight.

Do not short circuit this charger.

Do not subject this charger to excessive force.

Children must be supervised by an adult when using this charger.

Warnings

The manufacturer hereby, declares that this equipment is

in compliance with the applicable Directives and European

Norms, and amendments. The full text of the EU declaration

of conformity is available at the following internet address:

hp://www.mi.com/global/service/support/declaration.html

Produkspesifikasjoner

Merke:	Xiaomi
Kategori:	Batterilader
Modell:	Mi 65W Fast Charger with GaN Tech
Bredde:	30.8 mm
Dybde:	30.8 mm
Høyde:	56.3 mm
Strømkildetype:	AC
Antall per pakke:	1 stykker
Inngangsspenning:	100 - 240 V
Utgangsspenning (maks.):	20 V
Antall USB Type-C-porter:	1
Produktfarge:	Hvit
AD-adapter utgangsstrøm:	3.25 A
Kabler inkludert:	USB
Driftstemperatur (T-T):	0 - 40 °C
Harmonisert system (HS)-kode:	85044095
Inngangsfrekvens:	50/60 Hz
Strømbeskyttelsesfunksjoner:	Over current, Over voltage, Overheating, Short circuit
Laderype:	Innendørs
Laderkompabilitet:	Universell
Innput-strøm:	1.7 A
AC-adapter energitap:	65 W
Utgangsspenning (min.):	5 V
