Xiaomi Mi Power Bank 20000mAh Bruksanvisning

Xiaomi Batterilader Mi Power Bank 20000mAh

Les nedenfor 📖 manual på norsk for Xiaomi Mi Power Bank 20000mAh (2 sider) i kategorien Batterilader. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/2

Mi Powerbank 20000

1. Features

Read the manual before use the device!

Safety: Portable Mi battery has a di󰀨erent degrees of

protection; whether charged or discharged, it is in standby

mode. The battery can easily pass a charge, over-discharge

the batteries, high temperature, circuit, and many other

unusual circumstances, and provides reliable protection for

your digital portable equipment.

High performance: Extremely fast charging, high current

output 5.1V / 2 1A, ultra-high conversion rate (5.1V / 1A

conversion factor of more than 93%).

Compatibility: Built-in Smart USB compatible battery provides

compatibility with many di󰀨erent devices, especially with

Samsung and BlackBerry, which are not compatible with many

portable power supplies.

Quality: The battery of the best international companies

supplying the rst class batteries.

Model: YDDYP01

Battery Type: Li-ion Battery

Battery Power: 3.6V / 20,000 mAh (TYP)

Operating temperature range: 0C - 45C

Size: 141.9 x 73x 21.8mm

Input voltage: DC 5.0V / 2.0A, 9.0V / 2.0A, 12V / 1.5A

Output voltage: 2 x DC 5.1V / 2.1A (MAX 3.6a)

Charging time: about 7 hours (* 18W charger, standard

cable), about 11 hours (* 10W charger, standard cable)

Note:

* 18W charger maintains the output voltage of DC 5.0V / 2.0A,

9.0V / 2.0A, 12V / 1.5A

* 10W charger maintains the output voltage of DC 5.0V / 2.0A

Note: the «battery check» button are not intended to turn

on / o󰀨 the device. This battery has the function of automatic

detection of charging and discharging, so there is no need

to constantly press the charge check button. In two minutes

before the discharge, the amount of power LEDs are switched

o󰀨.

Micro USB (in)

USB port (out)

Indicator

Battery check button

Thank you for choosing our products. This device - a portable

battery with a high capacity. The device use the best

international company supplying batteries with a rst class

chip. It has special performance metrics: safety, e󰀩ciency,

compatibility and other aspects.

2. About device

3. Basic parameters

4. Battery

Connect Mi adapter to the power adapter to charge it.

During charging, the status indicators show the level of charge

as follows:

5. Charging of other devices

Use a USB cable to connect other digital devices to charge

them.

When discharge, the status lights indicate remaining battery

level as follows:

6. Warranty

Warranty service is carried out in accordance with the law on

«the rights of consumers of China» and «The PRC Law of the

products quality.» The warranty service includes:

During the warranty period you have the right to repair,

exchange or return an item. For repair, replacement or return of

goods you need to present an invoice.

1. Within 7 days from the date of purchase, in case of a

problem of «faults list» Xiaomi service center determines the

cause of the problem, then you can choose a free replacement,

returning or repair.ing of a product.

2. Within 8-15 days from the date of purchase, in case of

a problem of «faults list» Xiaomi service center denes a

problem, and then you choose a free replacement or repairing

of goods.

3. Within 12 months from the date of purchase, in case of

a problem of «faults list» Xiaomi service center denes the

problem, then you are get a free repairing.

7. List of Faults

8. Warranty rejection terms

- The completion of maintenance, fall, neglect, abuse, liquid

ingress, accident, breaking, or if the label and marking of

device is spoiled;

- The warranty period has expired;

- Damage caused by force majeure;

- Damage that do not meet «faults list» of Xiaomi service

center;

- Failure of the device or its components from the «List of

faults», which arose in connection with the human factor, and

which prevent to a normal operation.

(It`s necessary to keep the packaging unit, it may need to

service center consultant in case you have to contact them)

XIAOMI-MI.COM

http://xiaomi-mi.com

Security sticker

Each genuine portable battery 20 000mAh has a safety label

on the outside of the package. Please delete the special

coating, enter your code on the o󰀩cial website, indicating the

authenticity of the goods.

http://www.chaxun.mi.com

Production company: «ZMI Technology» Ltd.

Address: g.Jiang Yin, ul. Dengjiangzhong, 159, A913

Presence of toxic and hazardous substances

9. Notice

This device is equipped with a lithium-ion battery, than it`s

strictly prohibited to disassemble the enclosure to prevent

damage to the battery or other damage.

It is strictly forbidden any dismantling, squeezing, pricking

device; also not allowed to put it into water or re, or expose it

to temperatures above 60 ° C.

10. Warning!

1. Before the rst use of the battery, charge it fully.

2. When using the battery needed to display digital device

caught re, it will point to the correct operation of the device.

3. To charge this battery, or to charge other devices via the

battery, you can choose its own cable.

4. If, during charging of the digital device ceased to burn all

LED indicators, which means that in a portable battery charge

is not enough. Please charge it more quickly.

5. When you connect a digital device to the battery, it directly

uses the charge of the battery.

6. After a full charge the battery, immediately disconnect it from

the electricity supply.

7. Due to the short circuit of the battery or for other reasons at

the time of the introduction of protection mode (after pressing

the «stop work», LED display does not appear), you must use

an external charger to continue charging and the battery life will

be restored.

0: toxic and harmful substances in all components of the device

contained in an amount below the limit value according to SJ /

T11363-2006 «requirements limiting the presence of toxic and

hazardous substances in products.»

X: indicates the presence of toxic and hazardous substances

at least one of the components in this product in excess of

the limit value, according to SJ / T11363-2006 «requirements

limiting the presence of toxic and hazardous substances in

products.»

This product conforms to the European RoHS requirements

and regulations for the protection of the environment;

international countries still can not replace or reduce the

aluminum content in copper alloy. In terms of environmentally

sound management stated that under normal operating

conditions is not possible leaks of hazardous substances or

elements.

XIAOMI-MI.COM

Produkspesifikasjoner

Merke:	Xiaomi
Kategori:	Batterilader
Modell:	Mi Power Bank 20000mAh
Vekt:	338 g
Bredde:	73 mm
Dybde:	141.9 mm
Høyde:	21.8 mm
LED-indikatorer:	Ja
Batterikapasitet:	20000 mAh
Ladekilde:	USB
Kompatible produkter:	Mi, Apple, Samsung, HTC, Google, BlackBerry
Utgangsstrøm:	5.1 V
Antall samtidig tilkoblede enheter (maks.):	2
USB ladekontakt:	Ja
Batteriteknologi:	Lithium-Ion (Li-Ion)
Kabellengde:	0.318 m
Produktfarge:	Hvit
Kabler inkludert:	USB
Strømbeskyttelsesfunksjoner:	Over current, Over voltage, Overcharge, Overdischarge, Short circuit
Laderkompabilitet:	Mobile phone/Smartphone, Tablet, MP3/MP4, GPS, E-book reader
Inngangsgrensesnitt:	Micro-USB
Antall mikro-USB kontakter:	1
USB A utgang:	2
