Xiaomi Mi Home Security Camera 360 Bruksanvisning

Xiaomi Sikkerhetskamera Mi Home Security Camera 360

Les nedenfor 📖 manual på norsk for Xiaomi Mi Home Security Camera 360 (10 sider) i kategorien Sikkerhetskamera. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/10

This version is for private use only and should not be distributed.

Mi Home Security Camera

360° 1080p User Manual

This version is for private use only and should not be distributed.

Read this manual carefully before use, and retain it for future reference

Product Overview

reset

Status Indicator

Loudspeaker

Micro-USB

Charging Port

Reset

Button

Front View Rear View

Lens

MIC

MicroSD Slot

(Can be

revealed by

pushing the

lens upward)

Package Contents: Mi Home Security Camera 360° 1080p, power cable, wall mounting

accessories pack, user manual

Installation

The Mi Home Security Camera 360° 1080p can be placed on a number of horizontal surfaces,

such as a writing desk, dining table, and coﬀee table. It can also be mounted on the wall.

Mounting the Security Camera on a Wall

1. Drill two holes on the wall by using the base of the security camera as a template. It is

recommended that you mark the locations of the holes with a pencil before drilling. The

diameter of each hole is approximately 6 mm and the depth is approximately 30 mm.

This version is for private use only and should not be distributed.

2. Insert the two plastic anchors into the holes on the wall.

3. Place the side of the base with arrows

facing forward, and then align the holes.

Insert the screws and then tighten them

into the wall plugs with a Phillips head

screwdriver.

4. Match the grooves on the boom of

the camera unit with the raised area on

the base unit. Press down until the two

surfaces are ﬂush, then turn the camera

unit in either direction to lock it in position.

Warning:

To avoid any damages or injuries, the device must be securely fastened to the ﬂoor/wall as

speciﬁed in the installation instructions.

When mounting the security camera on a wall: please note that the wall must be able to

support at least triple the product’s total weight.

Produkspesifikasjoner

Merke:	Xiaomi
Kategori:	Sikkerhetskamera
Modell:	Mi Home Security Camera 360
Vekt:	239 g
Høyde:	118 mm
Støttede mobile operativsystemer:	Android, iOS
Bruksanvisning:	Ja
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Tilkoblingsteknologi:	Trådløs
Maksimal oppløsning:	- piksler
Videokomprimeringsformater:	H.265
Diameter:	78 mm
Strømkildetype:	DC
Antall kameraer:	1
LED-type:	IR
Infrarød bølgelengde:	940 nm
HTTPS-kryptering:	Ja
Synsfelt:	110 °
Produktfarge:	Hvit
Vippevinkelområde:	0 - 115 °
Monteringssett:	Ja
Minnekortenhet:	MicroSD (TransFlash)
Kabler inkludert:	DC
Støttede videofunksjoner:	1080p
Driftstemperatur (T-T):	-10 - 50 °C
Innebygd kortleser:	Ja
nattsyn:	Ja
Formfaktor:	Tårn
Modell/Type:	IP-sikkerhetskamera
DC utgangsstrøm:	1 A
Innebygd harddisk:	Nei
Panoreringsomfang:	0 - 360 °
Lydsystem:	2-veis
Minimumsbelysning:	- lx
Ethernet/bredbåndsforbindelse:	Nei
Støttede plasseringer/plasseringer som kan benyttes:	Innendørs
Montasjetype:	Tak/vegg/skrivebord
Totale megapiksler:	- MP
Maksimal størrelse på hukommelseskort:	64 GB
Frekvensbånd og driftskanaler:	2.4 GHz
DC-ut, volt:	5
Fast fokalobjektiv:	3.9 mm
Videobasert bevegelsesdeteksjon:	Ja
