Side 1/5
Mi TV Bar
user`s manual
Accessories
Remote control
AV Cabel-adaptor
Batteries (№7) х2 Remote control strap*
Power cable MI PORT cabel
Components marked with * are optional accessories, that you can purchase separately
Installation
Connect Mi Bar to Mi TV
One end of the cable connect to Mi PORT socket of
Mi Bar, and the second - to HDMI socket of TV.
For maximum productivity of Mi Bar, do not put it on
the oor or on metal surface.
Connect to power
a: Connect Mi stereo subwoofer * to Power
b: Plug Mi Bar to Power. Connect the power cable
to the adapter and insert the adapter into the DC IN
19V Mi Bar port.
Switch on
Press the Power button. In a rst start you must
follow instructions to complete all settings of Mi
Bar.
First, turn on the TV.
XIAOMI-MI.COM
Computer Console
Blu-ray DVD
Internet
Computer
AV cable
Blu-ray
DVD
TV box
Antenna
adapter
TV-antenna port
When you need to connect a wired / wireless port, or install a device in the port F, for connecting a coaxial line, you can choose
an antenna adapter.
Volume up
Previous
Volume down
Switching of
music channels
Indicator
Power button
Start/Stop
Next
Download Smart Speakers APP to your smartphone and edit music channels.
The Main Unit is the processing center of the TV content as well as Smart Speakers is connecting to the network. Use this application to
edit and add music channels.
subwoofer port
HD player TV screen
The Main Unit sockets
XIAOMI-MI.COM
Remote control
Power
Home
Menu
Back
Wheel of
options
Set
Volume
Notices:
The remote, that supports the audio control mode, can be used together with a gamepad, TV set to become the
gaming device!
Pairing a remote control with TV set
In the lower right corner of the TV has a special Bluetooth system, which operates in the range of 20 meters.
Simultaneously press the button and , you will hear the sound, then you can release buttons (please adhere to
the specied distance). Then you will hear two beeps from the panel that will indicate successful pairing.
Voice operated console marked with this
symbols…
Bluetooth console marked only with this
symbol…
Batteries
Using the strap for the remote control
1. Thread the strap through the hole at the bottom of the battery compartment;
2. Once you have inserted a loop of the strap through the hole at the bottom of
the battery compartment, slide it through the latch between the two batteries;
3. Insert the batteries, and close the back cover of the battery compartment.
Power: press Power button to turn off the TV; press and hold the button to turn off, restart or set the time off.
Home: press the button to quick return to the homepage. Press and hold for 2 seconds to view a list of recently used
applications.
Menu: demonstrates the interface and options.
At the interface of online video, go to a search; playable les in the interface displays the parameters of the video; You
can also nd more video categories list, etc.
Wheel of options: control of choice (up, down, left, right). While watching the video using these buttons, you can
rewind the video fast forward, backward.
Set: conrms your current selection. During video playback, you can stop it on pause / play the current video.
Back: Back one step.
XIAOMI-MI.COM
