Xiaomi Router AX9000 Bruksanvisning

Xiaomi Ruter Router AX9000

Les nedenfor 📖 manual på norsk for Xiaomi Router AX9000 (84 sider) i kategorien Ruter. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/84

Router AX9000 User Manual 01

Manuale utente Router AX9000 10

Manuel utilisateur Router AX9000 19

Manual de usuario de Router AX9000 28

RouterAX9000– Benutzerhandbuch 37

Руководство пользователя роутера

Router AX9000

Посібник користувача роутера AX9000 55

Manual do usuário do Router AX9000 64

Router AX9000 Kullanım Kılavuzu 73

2.5 G network port

(WAN/LAN 1)

1 G network port

(WAN/LAN 1)

LAN2、LAN3、LAN4

Optical modem/

broadband modem

As per your

broadband provider

Network socket

LAN Port

Download the Mi Home/Xiaomi Home app

Step 1: Connect the cables

Power buon

RESET

Connect the power

Connect to a power socket

* If your Internet network is connected via an Ethernet cable at the wall, connect the Ethernet cable

directly to the Internet (WAN) port on the router

Power on the router, then connect the Internet (WAN) port to the DSL/

Cable/satellite modem

* The power is on when the power buon is pressed down. The power is oﬀ when the power buon is

raised.

* When the 2.5 G network port is used as the WAN port, the 1 G network port is used as the LAN port.

When the 1G network port is used as the WAN port, the 2.5 G network port is used as the LAN port

Scan the QR code to download and install the app. You will be directed to

the connection setup page if the app is installed already. Or search "Mi

Home/Xiaomi Home" in the app store to download and install it.

* If you have already installed the Mi Home/Xiaomi Home

app on your smartphone, please make sure that you are

using the latest version available online

Download the Mi Home/

Xiaomi Home App

Produkspesifikasjoner

Merke:	Xiaomi
Kategori:	Ruter
Modell:	Router AX9000
Produkttype:	Frittstående router
Bredde:	270 mm
Dybde:	270 mm
Høyde:	174 mm
LED-indikatorer:	Activity, LAN, System, WLAN
Prosessorfrekvens:	2200 MHz
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Strømkildetype:	DC
Internminne:	1000 MB
SIM-kortspor:	Nei
Nettverksstandard:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
3G:	Nei
4G:	Nei
Ethernet WAN:	Ja
Utgangsstrøm:	12 V
Auto MDI/MDI-X:	Ja
5G:	Nei
Intelligent Mesh-teknologi:	Ja
Produktfarge:	Sort
Prosessorkjerner:	4
Beste Wi-Fi-standard:	Wi-Fi 6 (802.11ax)
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	5
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 70 °C
Harmonisert system (HS)-kode:	85176990
tilbakestillingsknapp:	Ja
prosessorprodusent:	Qualcomm
Innebygd prosessor:	Ja
DC-inngangskontakt:	Ja
Ethernet LAN dataoverføringshastigheter:	10,100,1000,2500 Mbit/s
Sikkerhetsalgoritmer:	WPA-PSK, WPA2-PSK, WPA3-SAE
Ethernet/bredbåndsforbindelse:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	1
Webbasert administrasjon:	Ja
Wi-Fi-bånd:	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
WLAN dataoverføringshastighet (første band):	2402 Mbit/s
WLAN dataoverføringshastighet (andre band):	4804 Mbit/s
Ethernet LAN-grensesnittype:	Gigabit Ethernet
Antall antenner:	12
WLAN data overførings rate (max):	4804 Mbit/s
Antennedesign:	Utvendig
Access Control List (ACL)/tilgangskontrolliste:	Ja
WLAN dataoverføringshastighet (tredje band):	1148 Mbit/s
