ZOTAC ZBOX

User’s Manual

No part of this manual, including the products and software described in it,

may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language in any form or by any means,except

documentation kept by the purchaser for backup purposes, without the

express written permission of ZOTAC.

Products and corporate names mentioned in this manual may be registered

trademarks or copyrights of their respective companies, and are used for

identication purposes only. All trademarks are the property of their respective

owners.

Every effort has been made to ensure that the contents of this manual are

correct and up to date. However, the manufacturer makes no guarantee

regarding the accuracy of its contents, and reserves the right to make

changes without prior notice.

CAUTION:

There is a re risk if the battery is replaced with the incorrect type. Batteries

should be recycled where possible. Disposal of used batteries must be in

accordance with local environmental regulations.

ZOTAC ZBOX

Table of Contents

Product specications -------------------------------------------------------------------------- 3

Safety information -------------------------------------------------------------------------------- 4

Setting up your system ----------------------------------------------------------------------- 4

Care during use -------------------------------------------------------------------------------- 4

Welcome --------------------------------------------------------------------------------------------- 5

Package contents ------------------------------------------------------------------------------ 5

Getting to know your ZOTAC ZBOX -------------------------------------------------------- 6

Front view ---------------------------------------------------------------------------------------- 6

Rear view----------------------------------------------------------------------------------------- 7

BIOS settings of specic functions --------------------------------------------------------- 8

How to disable the ring LED indicator ---------------------------------------------------- 8

How to disable the integrated IR receiver ------------------------------------------------ 9

Installing hardware inside the ZOTAC ZBOX -------------------------------------------- 10

Installing a memory module ----------------------------------------------------------------- 10

Removing a memory module --------------------------------------------------------------- 11

Installing a hard disk -------------------------------------------------------------------------- 12

Installing mSATA SSD module -------------------------------------------------------------- 14

Setting up your ZOTAC ZBOX ---------------------------------------------------------------- 15

Positioning your ZOTAC ZBOX --------------------------------------------------------------- 17

Installing the stand ----------------------------------------------------------------------------- 17

Attaching your ZOTAC ZBOX to a monitor ---------------------------------------------- 17

Installing drivers and software --------------------------------------------------------------- 18

Installing an operating system -------------------------------------------------------------- 18

Installing system drivers ---------------------------------------------------------------------- 18

Using your ZOTAC ZBOX ----------------------------------------------------------------------- 19

Conguring a wireless connection --------------------------------------------------------- 19

Conguring a wired connection ------------------------------------------------------------- 19

Using a static IP ---------------------------------------------------------------------------- 19

Using a dynamic IP (PPPoE connection) -------------------------------------------- 20

Conguring audio output --------------------------------------------------------------------- 20

Intel Rapid Storage Technology -------------------------------------------------------------- 21

Introduction ------------------------------------------------------------------------------------- 21

Setting up Intel Rapid Storage Technology --------------------------------------------- 21

Produkspesifikasjoner

Merke:	ZOTAC
Kategori:	stasjonær
Modell:	ZBOX EN760
Produkttype:	Mini PC
Vekt:	- g
Bredde:	188 mm
Dybde:	51 mm
Høyde:	188 mm
Bluetooth:	Ja
Prosessorfrekvens:	1.6 GHz
Prosessorfamilie:	Intel® Core™ i5
Wi-Fi:	Ja
Wi-Fi-standarder:	Wi-Fi 5 (802.11ac)
Bluetooth-versjon:	4.0
Antall HDMI-porter:	1
DVI-port:	Ja
Hodetelefonutganger:	1
Internminne:	0 GB
Busstype:	DMI2
PCI Express-konfigurasjoner:	1x4, 2x4
Kodenavn prosessor:	Haswell
Maksimalt internminne:	16 GB
Total lagringskapasitet:	0 GB
Støttede instruksjonssett:	AVX 2.0
Intel® Insider™:	Ja
Intel® Enhanced Halt State:	Ja
Intel® Small Business Advantage (Intel® SBA):	Nei
Intel® 64:	Ja
Prosessorpakkestørrelse:	40 x 24 x 1.5 mm
Konfliktfri prosessor:	Ja
Intel® Identity Protection Technology (Intel® IPT):	Ja
Intel® Trusted Execution Technology:	Nei
Intel® TSX-NI:	Nei
Intel® Anti-Theft Technology (Intel® AT):	Ja
Prosessorkode:	SR170
Diskret grafikkadaptermodell:	NVIDIA® GeForce® GTX 860M
Maksimalt internminne støttet av prosessor:	16 GB
Minnespor:	2x SO-DIMM
Antall installerte prosessorer:	1
Antall diskrete grafikkadaptere:	1
FSB-paritet:	Nei
Intel® Demand Based Switching:	Nei
Intel® Rapid Storage Technology:	Ja
HDD-størrelse:	2.5 "
Intel® High Definition Audio (Intel® HD Audio):	Ja
Intel® Matrix Storage Technology (Intel® MST):	Nei
Prosessorgenerering:	4th gen Intel® Core™ i5
Totalt antall SATA-kontakter:	4
Produktfarge:	Sort
Pakkedybde:	74 mm
Pakkehøyde:	245 mm
Pakkebredde:	337 mm
Prosessorkjerner:	2
Internminnetype:	DDR3L-SDRAM
Beste Wi-Fi-standard:	Wi-Fi 5 (802.11ac)
Operativsystemprogramvare 04:	Nei
Kabler inkludert:	AC
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Innebygd kortleser:	Ja
prosessorprodusent:	Intel
Minnebåndbredde støttet av prosessor (maks.):	25.6 GB/s
DC-inngangskontakt:	Ja
Skjerm inkludert:	Nei
Mus inkludert:	Nei
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Minnekanaler:	Tokanals
Prosessorstøpsel:	BGA 1168
Ikke EEC:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Antall SATA III-tilkoblinger:	4
Grafikkadaptermodell om bord:	Intel® HD Graphics 4400
Chassis-type:	USFF
Optisk stasjonstype:	Nei
Prosessor forsidebuss:	- MHz
Prosessormodell:	i5-4200U
On-board grafikkort:	Ja
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	4
Systembussrate:	- GT/s
PCI Express sporversjon:	2.0
Minneklokke-hastighet:	1600 MHz
Tastatur medfølger:	Nei
Intel® Wireless Display (Intel® WiDi):	Ja
Intel® Turbo Boost Technology:	2.0
Intel® Hyper Threading Technology (Intel® HT Technology):	Ja
Intel® My WiFi Technology (Intel® MWT):	Ja
Intel® Rapid Start Technology:	Nei
Intel® Smart Response Technology:	Nei
Intel® Smart Connect Technology:	Ja
Enhanced Intel SpeedStep Technology:	Ja
Boostfrekvens prosessor:	2.6 GHz
Processor cache:	3 MB
Cachetype prosessor:	Smart Cache
Prosessortråder:	4
Minnefordeling:	- GB
On-board grafikkadapter familie:	Intel® HD Graphics
Diskret grafisk adapter hukommelse:	2048 GB
Diskret grafikk, hukommelsestype:	GDDR5
Prosessorlitografi:	22 nm
Prosessorens driftmoduser:	64-bit
Stigning:	C0
Minnetyper som støttes av prosessor:	DDR3-SDRAM
Minneklokkehastighet støttet av prosessor:	1333,1600 MHz
EEC støttet av prosessor:	Nei
Thermal Design Power (TDP):	15 W
Prosessorserier:	Intel Core i5-4200 Mobile series
Maksimalt antall PCI Express-spor:	12
Tjunction:	100 °C
Intel® Virtualization Technology (Intel® VT):	VT-x
Basisfrekvens on-board skjermkort:	200 MHz
Dymanisk frekvens (maks.) on-board skjermkort:	1000 MHz
Maksimalt minne on-board grafikkadapter:	1.74 GB
On-board skjermkort DirectX-versjon:	12
Antall skjermer som støttes (on-board skjermkort):	3
ID for on-board grafikkadapter:	0xA16
Vannkjølingssystem:	Nei
Intel® Quick Sync Video Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® InTru™ 3D Technology:	Ja
Intel® Virtualization Technology (VT-x):	Ja
Integrerte alternativer tilgjengelige:	Nei
Intel klar video teknologi:	Nei
Intel® VT-x with Extended Page Tables (EPT):	Ja
Inaktive tilstander:	Ja
Thermal Monitoring Technologies:	Ja
Intel® AES New Instructions (Intel® AES-NI):	Ja
Intel Sikkerhets Nøkkel:	Ja
Execute Disable Bit:	Ja
Intel® FDI Technology:	Nei
Intel® Flex Memory Access:	Nei
Intel® Fast Memory Access:	Nei
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID):	Nei
Prosessorkonfigurasjon (maks.):	1
Intel Virtualisering Technology for Directed I/O (VT-d):	Nei
Intel® Smart Connect Technology version:	1.00
Intel® Identity Protection Technology version:	1.00
Intel Secure Key Technology versjon:	1.00
Intel TSX-NI verson:	0.00
Intel® Dual Display Capable Technology:	Nei
Processor ARK ID:	75459
Intel ME Firmamerke Versjon:	9.5
