Adam Hall GmbH · Daimlerstr. 9 · 61267 Neu-Anspach · Germany

Tel.: (+49) 60 81 / 94 19 0 · Fax: (+49) 60 81 / 94 19 1000 · eMail: mail@adamhall.com

SKDB039

Speaker stand

SAFTY INFORMATION

1. Please read these instructions carefully before you start installation and assembly.

2. Keep all information and instructions in a safe place.

3. Follow the instructions.

4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.

5. Be attentive when setting up the product and protect yourself from injury.

6. This product is intended for indoor use only. Using it outdoors could lead to product failure and personal injury.

7. Do not modify this equipment.

8. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate

plastic and paper/cardboard.

9. Plastic bags must be kept out of reach of children.

10. If you have any questions refering to this instruction or any warnings, please contact your local distributor.

MANUFACTURER’S WARRANTY & LIMITATION OF LIABILITY

You can find our current warranty conditions and limitation of liability at: http://www.adamhall.com/media/shop/

downloads/documents/manufacturersdeclarations.pdf

To request warranty service for a product, please contact Adam Hall GmbH, Daimler Straße 9, 61267 Neu Ans

pach / Email Info@adamhall.com / 49 (0) 6081 / 9419-0

PROPER DISPOSAL OF THIS PRODUCT

(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)

(Valid in the European Union and other European countries with waste separation)

This symbol on the product, or the documents accompanying the product, indicates that this appliance may not

be treated as household waste. This is to avoid environmental damage or personal injury due to uncontrolled

waste disposal. Please dispose of this product separately from other waste and have it recycled to promote

sustainable economic activity.

FEATURES

Multi-purpose loudspeaker stand

23 x 23 cm support with nonslip surface

35 kg load capacity

Set screw plus safety pin height adjustment from 91.5 – 150 cm

45 x 39 cm footprint

Plastic feet or steel spikes selectable

Durable black powder coating

Doubles as 35 mm speaker stand w/o support

OPERATION

Place the tube into the desired height and then gently ﬁx the clamp by locking knob

Insert the locking pin

, slightly loosen the clamp and lower the pipe until it rests on the locking pin - Caution:

Always insert the safety pin to secure the height adjustment!

Tighten the clamp again by hand - not too tight – then place the speaker on the secured tripod.

SPECIFICATIONS

Model number: SKDB039

Product type speaker stand

Tube material steel

Tube colour black

Tube surface powder coated

Min. Height 915 mm

Max. Height 1500 mm

Joint material plastic

Tube Ø 41/35 mm

Max. load 35 kg

4.4 kg

Produkspesifikasjoner

Merke:	Adam Hall
Kategori:	høyttalerstøtte
Modell:	SKDB039
Vekt:	4184 g
Høyde:	1500 mm
Høyde (min):	915 mm
Plassering:	Gulv
Materiale:	Stål
Antall skjermer som støttes:	1
Maksimal skjermstørrelse:	- "
Minimum skjermstørrelse:	- "
Høydejusteringsområde:	915 - 1500 mm
Høydejustering:	Ja
Produktfarge:	Sort
Modell/Type:	Bærbart gulvstativ for flatskjerms-TV
Kroppsmateriale:	Plastic, Steel
Montasjetype:	Gulv
Maksimalvekt (kapasitet):	35 kg
Høyde (max):	1500 mm
Monteringsgrensesnitt, kompatibilitet (min):	- mm
Monteringsgrensesnitt, kompatibilitet (maks):	- mm
Kan justeres i høyden:	Manuell
