Side 1/36

Rev. 10/14

User Instructions

3 SIXTY 2R

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building,

and electrical damages, injuries to any persons, and direct or

indirect economic loss associated with the use or reliance of

any information contained within this document, and/or as a

result of the improper, unsafe, unsucient and negligent as-

sembly, installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you!

N o t for R e s ide ntia l U s e.

N O T F O R H OU S E H O L D U S E

IM P R O P R E A L 'U S A G E D O ME S T IQ UE

D R Y L OC A T I O NS E MP L A C E ME N T S S E C S

6.3

C O N F O R MS T O U L S T D. 1 57 3

C E R T IF IE D T O C S A S T D . C 2 2. 2 N O : 1 6 6

MO DE L :3 S IX T Y 2 R

100-240VA C ,50/60H z; 400W MAX ;

T Y P E : P L AT IN U M 2 R 1 35 W M A X

Ma de in P R C

MA N U FA C T UR I N G D AT E :

Inte rte k

Unpacking: Thank you for purchasing the 3 Sixty 2R by ADJ Prod-

ucts, LLC. Every 3 Sixty 2R has been thoroughly tested and has been

shipped in perfect operating condition. Carefully check the shipping

carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all equipment necessary to operate the unit has

arrived intact. In the event damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Please do not return this unit to your dealer without con-

tacting customer support rst.

Introduction: The 3 Sixty 2R is a DMX intelligent, moving head fix-

ture. The 3 Sixty 2R can be a 21 channel, 24 channel, or 32 Channel

DMX unit. The fixture can operate in three different operating modes;

show mode, sound-active, or under DMX control. The 3 Sixty 2R can

be used as a stand alone unit or in a master/slave configuration. For

best results use fog or special effects smoke to enhance the beams

projections.

During the initial start-up or use of this product a light smoke or

smell may arise from the unit. This is a normal process and is

cause by the heat associated with the lamp.

Customer Support: ADJ Products, LLC provides a toll free cus-

tomer support line, to provide help and to answer any question should

you encounter problems during your set up or initial operation. You

may also visit us on the web at www.adj.com for any comments or

suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Warning! This may cause severe eye damage. Avoid looking directly

into the light source at all times!

3 Sixty 2R General Information

ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 3ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 2

Table of Contents

Unpacking......................................................................3

Introduction....................................................................3

Customer Support......................................................................3

Safety Precautions......................................................................4

Features.........................................................................5

Handling Precautions..................................................................6

Registration......................................................................6

Important Discharge Lamp Warnings.........................................7

Mounting.........................................................................8

Controls and Functions.............................................................10

DMX Set-Up..............................................................................13

System Menu............................................................................16

Error Codes...............................................................................38

Operation...............................................................................40

DMX Traits.................................................................................43

Photometric Chart.....................................................................63

Lamp Replacement...................................................................64

Fuse Replacement....................................................................64

Cleaning..................................................................................65

Trouble Shooting.......................................................................65

Warranty.........................................................................66

Specifications....................................................................69

Please see page 7 for important lamp instructions!

For Your Own Personal Safety, Please Read and Understand This

Manual Completely Before You Attempt To Install Or Operate

This Unit!

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Be sure that the local power outlet match that of the required volt-

age for your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken.

• Do not attempt to remove or break o the ground prong from

the electrical cord. This prong is used to reduce the risk of electrical

shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out-

doors voids all warranties.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to cords at plugs, convenience recep-

tacles, and the point where they exit from the appliance.

• Cleaning -The fixture should be cleaned only as recommended by

the manufacturer. See page 66 for cleaning details.

• Heat -This fixture should be situated away from heat sources such

as radiators, heat registers, stoves, or other appliances (including

amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. Objects have fallen, or liquid has been spilled into the appliance.

B. The appliance has been exposed to rain or water.

C. The appliance does not appear to operate normally or exhibits a

marked change in performance.

3 Sixty 2R Safety Precautions

ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 4

• Micro-Stepping Motors for Smooth Color and Gobo Transitions

• 3 Modes of DMX-512 Protocol Compatible (21 DMX Channel

Mode, 24 DMX Channel Mode, and 32 DMX Channel Mode)

• Independent Gobo and Color Wheels

• 14 Gobos + Spot

• 13 Colors + White

• RDMX - Lets you set the DMX address from any DMX Controller

• 3 Operating Modes - Auto Run, Sound Active, & DMX Controlled

• Stand Alone Setup or Master-Slave Configuration

• Internal Microphone

• Philips® MSD Platinum 2R Discharge

• Edit and Save Scenes into the Memory

• 360˚ Pan & Tilt Rotation

• Digital Display for Address and Function Setting

3 Sixty 2R Features

ADJ Products, LLC - www.adj.com - 3 Sixty 2R Instruction Manual Page 5
