Side 1/18

User Instructions

Rev. 8/15

WIFLY BAR RGBA

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building, and

electrical damages, injuries to any persons, and direct or indi-

rect economic loss associated with the use or reliance of any

information contained within this document, and/or as a result

of the improper, unsafe, unsucient and negligent assembly,

installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you!

ADJ Products, LLC - www.adj.com - WiFly Bar RGBA User Manual Page 3

• Rechargeable Lithium Battery

• Multi-Colors

• Five Operating Modes

• Electronic Dimming 0-100%

• Built in Microphone

• DMX-512 protocol

• 3-Pin & 5-Pin DMX Connection

• 8 DMX Modes: 4 Channel Mode, 6 Channel Mode, 7 Channel

Mode, 8 Channel mode, 9 Channel Mode, 10 Channel Mode, 18

Channel Mode, and 34 Channel Mode.

• Built-In ADJ’s WiFly TransCeiver Wireless DMX

• ADJ RFC compatiable (Not Included)

• Power Cord Daisy Chain (See page 14)

WiFly Bar RGBA Warranty Registration

WiFly Bar RGBA Features

The WiFly Bar RGBA carries a 2 year limited warranty. Please fill out

the enclosed warranty card to validate your purchase. All returned

service items whether under warranty or not, must be freight pre-paid

and accompany a return authorization (R.A.) number. The R.A. number

must be clearly written on the outside of the return package. A brief

description of the problem as well as the R.A. number must also be

written down on a piece of paper included in the shipping carton. If

the unit is under warranty, you must provide a copy of your proof of

purchase invoice. You may obtain a R.A. number by contacting our

customer support team on our customer support number. All pack-

ages returned to the service department not displaying a R.A. number

on the outside of the package will be returned to the shipper.

The unit should be mounted using a mounting clamp (not provided),

axing it to the mounting bracket that is provided with the unit.

Always ensure that the unit is rmly xed to avoid vibration and slip-

ping while operating. Always ensure that the structure to which you

are attaching the unit is secure and is able to support a weight of 10

times the unit’s weight. Also, always use a safety cable that can hold

12 times the weight of the unit when installing the xture.

The equipment must be installed by a professional, and it must be

installed in a place where it is out of the reach of people’s grasp.

WiFly Bar RGBA Installation

WiFly Bar RGBA Introduction

ADJ Products, LLC - www.adj.com - WiFly Bar RGBA User Manual Page 2

Unpacking: Thank you for purchasing the WiFly Bar RGBA by ADJ

Products, LLC. Every WiFly Bar RGBA has been thoroughly tested and

has been shipped in perfect operating condition. Carefully check the

shipping carton for damage that may have occurred during shipping.

If the carton appears to be damaged, carefully inspect your xture for

any damage and be sure all accessories necessary to operate the unit

has arrived intact. In the case damage has been found or parts are

missing, please contact our toll free customer support number for fur-

ther instructions. Do not return this unit to your dealer without rst con-

tacting customer support.

Introduction:

The ADJ WiFly Bar RGBA is a rechargeable lithium bat-

tery powered, DMX intelligent, LED bar fixture with ADJ’s WiFly Trans-

Ceiver with wireless DMX built-in. This unit give you the freedom to set

up your fixture where ever you wish without the restrictions of power or

DMX cabling. The built-in battery will keep charge for up to 10 hours (full

on) from a full, single charge. This xture can be used in a stand alone

mode or connected in a Master/Slave conguration. This wash has

six operating modes: Sound Active mode, Auto mode, RGBA dimmer

mode, Static Color mode, Program Mode and DMX control mode.

Customer Support: ADJ Products, LLC provides a customer support

line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.adj.com for any comments or sugges-

tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.

Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@AmericanDJ.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

ADJ Products, LLC.

PLEASE recycle the shipping carton when ever possible.

WiFly Bar RGBA Safety Precautions

ADJ Products, LLC - www.adj.com - WiFly Bar RGBA User Manual Page 4

ADJ Products, LLC - www.adj.com - WiFly Bar RGBA User Manual Page 5

• To reduce the risk of electrical shock or re, do not expose this unit

rain or moisture

• Do not spill water or other liquids into or on to your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Do not attempt to remove or break o the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• This unit is intended for indoor use only, use of this product out`

doors voids all warranties.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by

t he manufacturer. See page 31 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu-

d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits a

marked change in performance.

CAUTION: This unit like any wireless device is highly susceptible

to static electricity. Static electricity can severly damage the unit.

Before touching the antenna, please ground/discharge yourself.

1. Handling of Batteries

1.1 Do Not Short Circuit the Battery

Try to never short circuit the battery. It generates a very high

current which could cause the battery to overheat which may

result in electrolyte gel leakage, harmful fumes, or explosion.

The LIR tabs may easily short-circuit by placing them on con-

ductive surface. A short circuit may lead to heat build up and

damage of the battery. An appropriate circuitry with PCM is

employed to protect accidental short circuit of the battery pack.

1.2 Mechanical shock

Droping the unit, impact hit, bending, etc. may cause failure or

shortend life of the LIR battery.

3. Other

3.1 Battery connection

1). Direct soldering of wire leads or devices to the battery is

strictly prohibited.

2). Lead tabs with pre-soldered wiring shall be spot welded to

the batteries. Direct soldering may cause damage of compo-

nents, such as separator and insulator, by heat build up.

3.2 Prevention of short circuit within a battery pack

There is enough insulation layers between wiring and the bat-

teries to provide extra safety protection. The battery pack is

constructed in a way that no short circuit will occur which may

cause smoke or re.

3.3 Do No Disassemble the Batteries

1). Never disassemble the batteries.

Doing this may cause a internal short circuit in the battery,

which may lead to harmful fumes, re, explosion, or other prob-

lems.

2). Electrolyte Gel is harmful

Electrolyte Gel should not leak from the LIR battery. Should the

electrolyte gel come into contact with the skin or eyes, ush the

WiFly Bar RGBA Battery Precautions
