Side 1/12
User Guide
Mega Hailer S680 / SW680 / SW685
Battery Powered PA System with
Thank you for choosing one of the Mega Hailer Series PA
Systems with from AmpliVox Portable Sound
Systems.
We are excited in introducing this truly unique system. Our
system combines flexibility with functionality. Please refer to
this user guide as you enjoy the unique capabilities of another
quality product from AmpliVox Portable Sound Systems.
We encourage you to visit our website www.ampli.com to
register your product for its warranty coverage, sign up to re-
ceive our newsletter, download our catalog, and learn more
about the complete line of AmpliVox audio visual products,
AmpliVox • 650 Anthony Trail Suite D, Northbrook, IL 60062 • Phone: (800)267-5486 • Fax: (800)267-5489 www.ampli.com
TABLE OF CONTENTS
SAFETY INSTRUCTIONS …………..................................... 2
WHAT’S IN THE BOX ………………..................................... 3
SPECIFICATIONS …………................................................ 3
BACK PANEL / AUDIO CONTROLS .................................... 4
WIRELESS RECEIVER ………….……….............................. 5
WIRELESS HANDHELD MICROPHONE ………………….… 5
BLUETOOTH ………..…….................................................... 6
BATTERY COMPARTMENT …………….............................. 9
SPEAKER STAND MOUNT …………………………………… 8
WIRELESS SPEAKER TRANSMITTER ………………….…. 9
TROUBLESHOOTING / SERVICING.................................... 10
WARRANTY…….................................................................... 11
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by AmpliVox Portable
Sound Systems is under license.
READ FIRST ABOUT BATTERY OPERATION!
BY OBSERVING A FEW SIMPLE RULES, YOU CAN EXTEND THE
LIFESPAN OF THE SEALED LEAD ACID (SLA) BATTERIES THAT
OPERATE YOUR AMPLIVOX BATTERY POWERED PORTABLE
PA SYSTEM OR ACCESSORY:
• ALWAYS KEEP YOUR AMPLIVOX PORTABLE PA SYSTEM
PLUGGED IN AND CHARGING WHEN NOT IN USE.
• FOR LONG TERM STORAGE (OVER 1 MONTH) WE
RECOMMEND DISCONNECTING THE SLA BATTERIES TO
AVOID GRADUAL, CONTINUOUS DISCHARGE.
• ALWAYS STORE SLA BATTERIES IN A CHARGED
CONDITION WHEN REMOVED FROM SERVICE.
• FOR SLA BATTERIES IN STORAGE, APPLY A TOPPING
CHARGE EVERY SIX MONTHS.
• AVOID REPEATED DEEP DISCHARGES. THIS PRACTICE
WILL CUT THE LIFE OF THE BATTERY SIGNIFICANTLY.
• AVOID OPERATING SLA BATTERIES AT ELEVATED
AMBIENT TEMPERATURES.
• BATTERY STATUS INDICATOR - RED = NO BATTERY POW-
ER, YELLOW / ORANGE= ABOUT 4 HOURS LEFT. CHARGE
BATTERY OVERNIGHT FOR BEST RESULTS.
2
IMPORTANT SAFETY INSTRUCTIONS
Before using this product, read the instruction manual for important safety information. Please retain this manual
for future reference and warranty information.
Cleaning
When cleaning the device, please use a soft, dry cloth. Never use benzene, paint-thinner, or other chemicals on
the device.
Location
Place the device in stable location, so it will not fall causing damage to the device or bodily harm.
Intended use
The product may only be used with the original parts intended for it. The intended use includes adherence to the
specified installation instructions. The manufacturer accepts no liability for damage arising due to improper use.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
IMPORTANT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. The unit’s circuitry may cause interference to nearby
radios. To prevent interference, either switch the unit off or move away from the affected radio.
NOTE: This equipment complies within the limits for a class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
NOTE: Shielded cables may be required to be used with this unit to ensure compliance with the Class B FCC
limits.
3
WHAT’S IN THE BOX
S680 / SW680 / SW685 SPECIFICATIONS
Rated Power Output: 50 W RMS
Speaker: 6" X 10" Horn
Frequency Response: 200 Hz to 15 kHz
Sensitivity: 124 dB SPL @ 1 W / 1 M
PA Battery: Two 12 volt rechargeable Sealed Lead
Acid Batteries (SLA), 2.9 AH,
User accessible and replaceable
USB Charger: 5V / 500mA
Wireless PA
Frequency: 16 preset channels.
Wireless Range: Up to 300 Feet (91 meters)
Range: Up to 30 Feet
AC Power: 100-240 V Auto sensing, 50/60 Hz
Microphone Input: 1/4" (6.3mm)
Weight: 15 lbs. (with battery) 6.8 kgs
Dimensions : 14" H x 12 1/2" W x 10" D
SW680
• Mega Hailer PA
• 16 Channel Wireless
Receiver
• Headset / Lavalier Mi-
crophone & Wireless
Bodypack Transmitter
• Universal Power Supply
with North America IEC
Power Cord
• Shoulder Strap
• Two Rechargeable SLA
Batteries (Installed)
• Flex Antenna
S680
• Mega Hailer PA
• Wired Handheld Micro-
phone (not shown)
• Universal Power Sup-
ply with North America
IEC Power Cord
• Shoulder Strap
• Two Rechargeable
SLA Batteries
(Installed)
• Flex Antenna
SW680 Model Shown
SW685
• Mega Hailer PA
• 16 Channel Wireless
Receiver
• Wireless Handheld
Microphone Transmitter
(not shown)
• Universal Power Supply
with North America IEC
Power Cord
• Shoulder Strap
• Two Rechargeable SLA
Batteries (Installed)
• Flex Antenna
