Side 1/6

Basic Rack PDU AP6031A

Overview

The APC by Schneider Electric Basic Rack Power

Distribution Unit (PDU) distributes power to

devices in the rack.

Outlets. The Rack PDU has four (4) C19 outlets.

Power cord. The 3.65 m (12.00 ft) power cord

terminates with a NEMA L6-30P plug.

Customer support and warranty information is available

at www.apc.com.

Schneider Electric Industries S.A.S.

990-3561A

10/2015

Specifications

Electrical

Input connection NEMA L6-30P cord included

Acceptable input voltage 200–240 VAC +6% to -10%

Maximum input current

(phase)

30 A (24 A UL/C-UL derated)

Input frequency 50/60 Hz

Output voltage 200–240 VAC +6% to -10%

Output connections (4) C19

Maximum output

current (outlet)

C19; 16 A (UL/C-UL derated)

C19; 20 A (PSE)

Maximum output

current (phase)

30 A (24 A UL/C-UL derated)

Maximum output

current (bank)

16 A UL/C-UL derated)

20 A (PSE)

Overcurrent protection

(internal)

(2) 20 A, 2-pole breakers

Cord length 3.65 m (12.00 ft)

Physical

Dimensions

(H x W x D)

43.81 x 4.36 x 12.57 cm

(17.25 x 1.72 x 4.95 in)

Shipping dimensions

(H x W x D)

47.29 x 28.09 x 18.00 cm

(18.62 x 11.06 x 7.09 in)

Weight 3.80 kg (8.36 lb)

Shipping weight 4.60 kg (10.12 lb)

Environmental

Maximum elevation

(above MSL)

Operating

Storage

0 to 3048 m (0 to 10,000 ft)

0 to 15240 m (0 to 50,000 ft)

Temperature

Operating

Storage

0 to 50°C (32 to 122°F)

–15 to 60°C (5 to 140°F)

Humidity

Operating

Storage

5 to 95%, non-condensing

Compliance

Safety approvals UL/C-UL

ROHS 2011/65/EU – latest revision

Produkspesifikasjoner

Merke:	Apc
Kategori:	grenuttak
Modell:	AP6120A
Vekt:	1560 g
Sertifisering:	UL/C-UL, VDE, CE
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Driftstemperatur (T-T):	0 - 50 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 60 °C
Lagringsrelativ fuktighet:	5 - 95
Bærekraftsertifikater:	RoHS
Modell/Type:	Enkelfaset
Montering:	Horisontal/vertikal
Rack-kapasitet:	0U/1U
Relativ luftfuktighet under drift (H-H):	5 - 95
Maksimal styrke:	3680 W
Antall AC outlets:	7 AC-utganger
Strøm (maks.):	20 A
AC-utgangstyper:	C13 coupler, C19 coupler
Strømuttak:	C20 kopling
Nominell innputspenning:	100-240 V
PDU types:	Grunnleggende
Nominell outputspenning:	100-240 V
Belastningskapasitet:	3680 VA
Maksimal innputstrøm per fase:	16 A
