Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

February 2010

MT1000A-85-R4

BL A C K B OX

15-Amp Metered Horizontal PDU, 14-Outlet (5-15R)

This 15-amp, rackmounted power distribution unit uses 1U of rack space

and features a current meter, and 6 front and 8 rear outlets.

PDUMH14-S15-120V

Overview

The metered PDU LCD display shows the current power draw

in amps. The metered PDU only has one function button,

MUTE, located next to the display. The metered PDU’s alarm

sounds when the current draw reaches 90% of capacity (13.5

amps). The alarm can be turned off by pressing the MUTE

button. When the current draw excedes 90% the maximum

current rating, the alarm cannot be muted, and the PDU alarms

until the current draw is reduced.

Environmental: Operating Temperature: 32 to 104° F

(0 to 40° C);

Storage Temperature: 32 to 149° F (0 to 65° C);

Operating and Storage Humidity: 0 to 90%,

noncondensing relative

cUL Listed: Yes

RoHS: Yes

Specifications

Circuit Breaker: 15 A

Cord Connector: L5-15P

Cord Length: 6 ft. (1.8 m)

Cord Type: SJT 14/3C

Current Alarm: Yes

Current Rating: 15 amps (12A derated)

Input Voltage: 120 VAC

Metered: Yes, 3-digit LED

Mounting: Horizontal

Number of Outlets: 14

Outlet Location: (6) front, (8) rear

Outlet Max. Current: 15A

Outlet Type: 5-15R

Indicator: Power LED

BL A C K BOX

FREE, live, 24/7 Tech Support is just 20 seconds away.

724-746-5500 | blackbox.com

Safety Instructions

1. The PDU is designed for indoor use only in a controlled environment away from excess moisture, temperature extremes,

conductive contaminants, dust, or direct sunlight.

2. Do not connect the PDU to an ungrounded outlet or extension cords or adapters that eliminate the connection to ground.

3. The power requirement for each piece of equipment connected to the PDU must not exceed the individual outlet’s load rating.

4. The total power requirements for equipment connected to the PDU must not exceed the maximum load rating.

5. Do not drill into or attempt to open any part of the PDU. There are no user-serviceable parts inside.

6. Do not attempt to modify the PDU, including input plugs and power cables.

7. To reduce the risk of fire, connect only to a branch circuit with overcurrent protection in accordance with the National Electric

Code, ANSI/NFPA 70(3KVA).

What’s included

• 14-outlet horizontal PDU

• (2) mounting brackets

• (4) mounting screws

• Specification sheet

and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Double Diamond

™

is a trademark of BB Technologies, Inc. Any third-party trademarks appearing in this publication are acknowledged to be the property of their respective owners.

PDUMH14-S15-120V, rev. 1

Produkspesifikasjoner

Merke:	Black Box
Kategori:	grenuttak
Modell:	PDUMH14-S20-120V
LED-indikatorer:	Ja
Pakkevekt:	2593 g
AC-inngangsfrekvens:	50 - 60 Hz
Kabellengde:	1.8 m
Produktfarge:	Sort
Driftstemperatur (T-T):	0 - 50 °C
Bærekraftsertifikater:	RoHS
Montering:	Horisontal
Rack-kapasitet:	1U
Display:	LCD
Antall AC outlets:	14 AC-utganger
Strøm (maks.):	20 A
AC-utgangstyper:	NEMA 5–20R
Nominell innputspenning:	125 V
PDU types:	Målte
Nominell outputspenning:	- V
