Technical Specification

SD-FS-H

General Features

Display Compatibility:

This product supports up to 6 Flat Panel Displays with a physical

dimensions of up to 635mm (25”) wide and 450mm (17.72”)

high and VESA mounting hole configurations of 75mm x 75mm

or 100mm x 100mm.

Dimension

Spacedec Freestanding Hex

Display Weight Compatibility:

Each Mounting Head supports a maximum weight of 8kg (17 / lbs)

Cable Management:

Cable Slot and Cable Clips (included in package)

Colour:

Colour is: Charcoal Grey

Warranty:

10 years limited

Vertical height adjustment

Horizontal adjustment

360°Portrait/Landscape adjustment

±20° Pan/Tilt adjustment

1418mm

(55.81”)

873mm

(34.3”)

340mm

(13.39”)

8mm

(.31”)

915mm

(36.01”)

370mm

(14.57”)

170mm

(6.68”)

51mm

(2.00”)

421mm

(16.5”)

Note: This product supports

displays with a total maximum

height (from edge to edge) of

up to 450 (17.72”).

Note: This product supports

displays with a total maximum

width (from edge to edge) of

up to 635mm (25”).

Mounting Options:

A. Freestanding

B. Freestanding with optional bolt down

C. Bolt Through

Spacedec

112mm (4.4”)

Spacedec

75mm

100mm

75mm

100mm

Bolt Through Mounting Options:

Vertical Adjustment on Post:

VESA Mounting Options:

No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd.

Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. Published 07.09.15 ©

55mm (2.17”)

Desk Max.

Thickness

63mm (2.48”)

Desk Max.

Thickness

Vertical adjustment

available in 17mm

increments

119mm

(Max. adjustment

range)

Produkspesifikasjoner

Merke:	Atdec
Kategori:	Ikke kategorisert
Modell:	SD-FS-H
Produktfarge:	Sort
Skjermstørrelsekompabilitet:	12/24 "
Svingvinkel:	40 °
Montering:	VESA 3"x3" & VESA 4"x4"
Maksimalvekt (kapasitet):	69 kg
