Securing the iPad to the MultiGrip™

Install selected Mounting Option before securing the iPad

Place iPad above the

MultiGrip™ (1). Gently

press the iPad in place.

If power cable is needed

insert it before placing

iPad in place!

Place the SafeGuard

Frame (2), from top.

Align the holes for the

tamper proof screws (5).

Using the tool (6),

secure the SafeGuard

Frame with tamper proof

screws (5), in four points.

The iPad is now secured

and ready to be used.

iPad SafeGuard Frames

Installation Instructions

snoitpO gnitnuoM tnetnoC xoB

(5)

M4/6 tamper-proof screws (x 4)

(6)

2,5mm Allen key with hole for pin (x 1)

(4)

M4/4 machine screws with cross recess (x 4)

(3)

M4/5 counter-sink screws with hex recess (x 2)

(1)

MultiGrip™ plate for iPad, multiple

mounting options

DuraTilt

mounting

Uses two screws (3) to attach the

MultiGrip™ (1) to a DuraTilt™

connection.

Tool (6) is included for use.

VESA mounting

Uses four screws (4) to

attach the MultiGrip™ (1) to a

VESA 75 monitor plate. Tool is

not included. Use a Phillips head

screw-driver. VESA 100

mounting also possible.

Wall mounting

Uses four self-tapper screws to

attach the MultiGrip™ (1) to a

wall/desk. Tool/screws are not

included.

Maximum diameter for the

screws: Ø5mm.

SafeGuard Frame

(2)

Produkspesifikasjoner

Merke:	Atdec
Kategori:	Ikke kategorisert
Modell:	SpacePole
Strømkildetype:	Støttes ikke
Innebygde høyttalere:	Nei
Materiale:	Aluminium, Steel
Kompatibilitet:	Apple iPad 2, iPad 3
Produktfarge:	Sort
Modell/Type:	Passiv holder
Korrekt bruk:	Universell
Mobilenhetstype:	Plate / UMPC
