Audac AXIR/O Bruksanvisning

Audac Høyttaler AXIR/O

Les nedenfor 📖 manual på norsk for Audac AXIR/O (12 sider) i kategorien Høyttaler. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/12

AXIR/O

User Manual

www.audac.eu

Index

Introduction 3

Precautions 4

Safety requirements 4

       Caution 5

       Caution servicing 5

      EC Declaration of Conformity 5

Waste of Electrical and Electronic Equipment (WEEE) 5



Chapter 1: Installation 6

Chapter 2: Connecting the AXIR/O 10

Additional information 11

Technical specifications 11

Polar paterns 12

Introduction

AXIR/O Outdoor Design Column Speaker

TheAXIR/Oaredesigncolumnspeakerswhichareespeciallydesignedforprovidingan

extraordinarysoundwithsurprisinglyhighpowerinoutdoororhumidenvironmentswhere

ahighaudibilityandclearreproductionofmusicandspeecharedesired.

TheyareequippedwithaspeciallydesignedwaterproofAWX-5connector,providingselection

outof4differentpowertaps.Threepowertapsfor40Watt,20Wattand10Wattforuse

in100Voltconstantvoltagepublicaddresssystemsandonepowertapfor6Ohmlow

impedanceapplicationsareprovided.

AseparateUVresistantclothinfrontofeverydriverkeepstheelementsofnatureata

safedistance,whileaspecialconetreatmentforthespeakersprotectsagainstpenetrating

humidity.Furtheraddedreliabilityisachievedbyusinganaluminiumfrontgrillandan

electroplatedstainlesssteelmountingbracket.

Thestylishandelegantaluminumhousingincombinationwiththelightweightdesignand

thespeciallydesignedwallbracket,whichallowsfocussingofthespeakerinanydirection,

ensurethebestpossibleappearancecombinedwithagreatsoundandhighaudibility.

Allthespecialmeasuresoftheloudspeakermakesitweatherandhumidityresistantaccording

totheIP55regulation.

Produkspesifikasjoner

Merke:	Audac
Kategori:	Høyttaler
Modell:	AXIR/O
Vekt:	4500 g
Bredde:	70 mm
Dybde:	105 mm
Høyde:	1005 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Anbefalt bruk:	Universell
Impedans:	6 Ω
Høyttalerplassering:	Vegg.monterbar
Peak Music Power Output (PMPO):	240 W
AirPlay:	Nei
Produktfarge:	Hvit
Kroppsmateriale:	Aluminium
Lyd-utgang kanaler:	1.0 kanaler
RMS-rangert strøm/utgangseffekt:	120 W
Antall drivere:	12
Frekvensrekkevidde:	80 - 19000 Hz
Sensitivitet/følsomhet:	92 dB
Diameter på mellomtone-driver (imperisk):	2 "
