Audac MERO2D Bruksanvisning

Audac Høyttaler MERO2D

Les nedenfor 📖 manual på norsk for Audac MERO2D (8 sider) i kategorien Høyttaler. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/8

MERO2

User & Installation

Manual

www.audac.eu

Introduction

2” High-end in-wall speaker

The MERO speakers will blend beautifully into any interior, making only their extraordinary

sound draw your attention with their nearly invisible design. Their slim grill with very

thin border of only 1 mm and limited grill depth extrudes the surface by only 3.2 mm

when installed.

Their grilles are retained by neodymium magnets which enables assembly in seconds,

while powerful enough to keep it fixed, even when subject to vibrations or if touched. Their

applications range from residential Hi-Fi and home cinema installations to Multi-Zone

systems, unobtrusive installations in lounges, bars, boutiques and offices.

The selection of high-grade materials in combination with accurate acoustics

craftmanship makes the MERO speakers superior in their class. The Ultra-compact

size enables the MERO2 smoothly integrate into any interior like no other loudspeaker.

The outer dimensions only measure only 146 x 98 mm and the built-in depth which

doesn’t exceed 70 mm allows installation in any surface while being unobtrusive.

The 2” full range aluminum cone driver is protected against overload through an integrated

self-resetting protection circuit. All these details share their part to the quality of the

Mero 2, resulting in an highly reliable loudspeaker producing a pure sound with an RMS

power of 10 Watt.

An elegant look with minimal visual impact is created by the slim grill with a very thin

border, while great ease and installers convenience is guaranteed using the quick-fix

mechanism with Gold-CON connectors. The grill is held in place using neodymium

magnets, providing a quick and stable assembly. Installation can be done both vertically

and horizontally.

Produkspesifikasjoner

Merke:	Audac
Kategori:	Høyttaler
Modell:	MERO2D
Vekt:	355 g
Bredde:	146 mm
Dybde:	70 mm
Høyde:	98 mm
Tilkobling:	Gold-Con
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Impedans:	16 Ω
Høyttalerplassering:	Ceiling-mountable, Wall-mountable
Basshøyttaler:	Nei
Diskanthøyttaler:	Nei
Produktfarge:	Black, White
Pakketype:	Boks
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Lyd-utgang kanaler:	1.0 kanaler
RMS-rangert strøm/utgangseffekt:	10 W
Antall drivere:	1
Høyttaler type:	Full rekkevidde
Frekvensrekkevidde:	100 - 20000 Hz
Sensitivitet/følsomhet:	83 dB
Driversylinder, materiale:	Aluminium
Driverdiameter:	50.8 mm
