Audison Thesis TH due Bruksanvisning
Les nedenfor 📖 manual på norsk for Audison Thesis TH due (76 sider) i kategorien Mottaker. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/76
www.audison.eu
ADVANCED
TH due
MANUAL
CAR AUDIO STEREO AMPLIFIER
Revisione 1.3
2
ADVANCED MANUAL / TH due
General
THESIS - The project 4
Packaging Contents 5
Installation 6
Fixing template 7
Rear Panel 11
Functions Description 11
How to remove the panel / the protection knob 11
How to connect the power supply 12
How to replace the fuse 13
How to connect the speakers in stereo mode 14
How to connect the speakers in mono mode MIX L+R 15
How to connect the speakers in mono mode IN R 16
Input controls 17
Functions Description 17
How to move from one sensitivity range to another 17
Front Panel 18
Functions Description 18
How to connect the remote 19
How to connect the source through the preamplified analog input (Stereo mode) 20
How to connect the source through the preamplified analog input (Mono MIX L+R mode) 21
How to connect the source through the preamplified analog input (Mono IN R mode) 22
Electronic Crossover 23
TH in Stereo mode 24
TH in Mono mode (Setup X-Over Slope 12 dB) 25
TH in Mono mode (Setup Lo-Pass X-Over Slope 24 dB) 26
How to insert 27
Examples 28
Two Way, mono configuration, TH amplifier, Analog Input 28
Two Way + bi-amplified Sub, Th amplifier, Analog Input 29
Three Way + multi-amplified Sub, TH amplifier, Analog Input 30
Two Way + bi-amplified Sub, with and without Th amplifiers, Analog Input 31
Three Way + multi-amplified Sub, with and without Th amplifiers, Analog Input 32
THESIS 33
ASC (AMPLIFIER STATUS CONTROLLER) 33
INPUTS AND PRE-AMPLIFIER 33
ASC - Amplifier Status Controller 34
Functions Description 34
Setup Amplifier: Main Input 35
How to change: main Input (Stereo or Mono mode) 35
Digital Inputs 36
How to adjust the volume control and input selector using a digital source 36
Front Panel 37
How to achieve same output volume level using an analog source
(with its own volume control) and a digital source 37
How to connect a source through the optical digital input
in a system featuring more then one TH amplifier (Stereo mode) 38
How to connect a source through the optical digital input
in a system featuring other non-TH amplifiers (Stereo mode) 39
How to connect a source through the optical digital input
in a system featuring more then one TH amplifier (Mono MIX L+R mode) 40
How to connect a source through the optical digital input
in a system featuring other non-TH amplifiers (Mono MIX L+R mode) 41
How to connect an analog and a digital source in a system
featuring more than one amplifier (Stereo mode) 42
INDEX
3
ADVANCED MANUAL / TH due
General
How to connect an analog and a digital source in a system
featuring other non-TH amplifiers (Stereo mode) 43
How to connect an analog and a digital source in a system
featuring more than one amplifier (Mono MIX L+R mode) 44
How to connect an analog and a digital source in a system
featuring other non-TH amplifiers (Mono MIX L+R mode) 45
ASC - Amplifier Status Controller 46
Setup Amplifier: Amp ID (TH in Stereo mode) 46
Setup Amplifier: Amp ID-Preout (TH in Stereo mode) 47
Setup Amplifier: Amp ID and ID-Preout (TH in Mono MIX L+R) 48
Setup Amplifier: Amp ID and ID-Preout (TH in Mono IN R) 49
Front Panel 50
How to adjust the PRE OUT analog output 50
ASC - Amplifier Status Controller 51
Setup Amplifier: X-Over Slope with TH in Mono mode 51
DUAL POWER & BIAS CONTROL 52
Setup Amplifier: DUAL POWER Settings 52
DUAL POWER Values 53
How to change presets oin the Memory 54
Examples 55
Three Way + multi-amplified Sub, TH amplifiers, Digital Input 55
Three Way + multi-amplified Sub, Th amplifiers, Analog + Digital Input 56
Three Way + multi-amplified Sub, with both TH and non-TH amplifiers, Analog + Digital Input 57
ASC - Amplifier Status Controller 58
Status Monitor 58
Runtime Monitor 59
Info and Alert sentences 60
DRC - Digital Remote Control 61
nfo and Alert sentences 62
How to connect 63
How to install 63
ACNet - Audison Control Network 64
Function Description 65
System Display 66
Amplifier Setting: Identification 67
Amplifier Setting: Inputs 68
Amplifier Setting: Sensitivity and Preout Level 69
Amplifier Setting: Dual Power Memory 70
System Audio Control 71
Amplifier Status 72
System Amplitude Setup 73
System Dual Power Setup 74
Technical Specifications 75
INDEX
Produkspesifikasjoner
| Merke: | Audison |
| Kategori: | Mottaker |
| Modell: | Thesis TH due |
