DM211

SINGLE MONITOR DESKTOP MOUNT WITH EXTENSION ARM

Item ref: 129.522UK

User Manual

This single monitor bracket is suitable for most 10" to 30" LED/LCD screens and features adjustable height, tilt and

swivel, allowing the screen to be easily positioned and free up valuable desk space making for a more comfortable

viewing experience.

• Suitable for LED/LCD screen sizes 10" - 30"

• VESA 75 and 100 hole patterns

• -85° to 15° tilt mechanism

• 180° pan from mounting plate

• 180° swivel from centre arm joint

• Desk fixing clamp with 100mm max. depth

adjustment

• Cable retainer

• Installation hardware included

Caution

Please read this manual thoroughly to avoid damage to property or personnel. If unsure of any part of this manual please

refer to professional installer for help:

• This product contains small components that could pose a choking hazard if swallowed, please keep out of reach of

children.

• This product is designed for mounting on wall studs or concrete wall. Always ensure the mounting surface will be

capable of withstanding the combined weight of the TV bracket and TV, reinforcement may be required for aged or

weak walls.

• Safety gear such as gloves and safety goggles must be worn during the installation. A minimum of two people are

required throughout the installation, failure to do so may result in injury or damage.

• This product is design for indoor use only. The bracket must be inspected at least every two months for loose joints or

aged parts.

Contents

Please check all contents listed below are included inside the box. If anything is missing please return to the retailer or

dealer.

For this installation you will also require a Philips (cross) screw driver.

4 x A 4 x B x C 3 2 x D

M4 x 12mm M5 x 12 M6 x 20mm M6 x 10mm mm

129.522UK User Manual

STEP 1 Assemble and fit the desk clamp –

STEP 2 Assemble and install the extension arm –

STEP 3 Attach mounting plate to the screen or monitor –

STEP 4 Adjust screen to preferred position –

Errors and omissions excepted.
