Side 1/23
PASTA COOKER
INSTALLATION,OPERATING
AND MAINTENANCE
INSTRUCTIONS
EN
MVP GROUP CORPORATION
5659 Royalmount Ave
Montreal, QC, Canada H4P 2P9
Telephone: (514) 737-9701
Toll Free Telephone: (888) 275-4538
Fax: (514) 342-3854
Toll Free Fax: (877) 453-8832
Email: sales@mvpgroupcorp.com
V2.2_2016
1
ENGLISH
EN
1. INDEX
1. INDEX ................................................................................................................................................. 1
2. ANALYTICAL INDEX .......................................................................................................................... 1
3. SAFETY .............................................................................................................................................. 2
4. REGULATIONS AND GENERAL INSTRUCTIONS ........................................................................... 3
4.1. General Information .................................................................................................................. 3
4.2. Warranty ................................................................................................................................... 3
4.3. Description of the Appliance .................................................................................................... 4
4.4. Safety Devices ......................................................................................................................... 4
4.5. Features Plate .......................................................................................................................... 4
4.6. Replacement of Parts ............................................................................................................... 5
5. USE AND FUNCTIONING .................................................................................................................. 5
5.1. Description of the Controls. ...................................................................................................... 5
5.2. Burner Ignition .......................................................................................................................... 6
5.3. Filling the Cooking Tank ........................................................................................................... 6
5.4. Draining the Cooking Tank ....................................................................................................... 6
5.5. Recommendations for Use ....................................................................................................... 7
6. CLEANING AND MAINTENANCE ..................................................................................................... 7
6.1. Recommendations for Cleaning and Maintenance .................................................................. 7
6.2. Routine Maintenance ............................................................................................................... 7
7. FAULTS .............................................................................................................................................. 8
8. INSTALLATION .................................................................................................................................. 8
8.1. Packaging and Unpacking ....................................................................................................... 8
8.2. Installation ................................................................................................................................ 9
8.3. Water Connection ................................................................................................................... 10
8.4. Gas Connection ...................................................................................................................... 10
8.5. Inspection ............................................................................................................................... 11
8.6. Power Supply Transformation ................................................................................................ 11
9. ADJUSTMENTS ............................................................................................................................... 12
9.1. Adjusting Burner Valve Minimum ........................................................................................... 13
9.2. Replacing Burner Nozzle ....................................................................................................... 14
9.3. Replacing Burner Pilot Light Nozzle ....................................................................................... 14
ATTACHMENTS ....................................................................................................................................... I
2. ANALYTICAL INDEX
A
Adjusting Burner Cock Minimum; 13
B
Burner Ignition; 6
D
Description of the Appliance; 4
Description of the Controls; 5
Draining the Cooking Tank; 6
F
FAULTS; 8
Features Plate; 4
Filling the Cooking Tank; 6
G
Gas Connection; 10
General Information; 3
I
Inspection; 11
Installation; 9
P
Packaging and Unpacking; 8
Power Supply Transformation; 11
R
Recommendations for Cleaning and Maintenance;
7
Recommendations for Use; 7
Replacement of Parts; 5
Replacing Burner Nozzle; 14
Replacing Burner Pilot Light Nozzle; 14
Routine Maintenance; 7
S
SAFETY; 2
Safety Devices; 4
W
Warranty; 3
Water Connection; 10
2
ENGLISH
EN
3. SAFETY
It is recommended to carefully
read the instructions and warnings
contained in this manual before using
the appliance. The information
contained in the manual is for the
safety of use and for machine
maintenance.
! Keep this manual carefully to be able to refer
to it in every case of need.
Keep appliance area clean and clear from
combustibles.
The place where the machine is to be installed
must be enough aerated, this is in order to supply
the necessary air for combustion, to prevent
reaching too high percentages of gas and to aid
evacuation of the products of combustion.
Installation must be conform with local codes, or
in absence of it, with the National Fuel Gas Code,
ANSI Z 223.1 or with the Natural Gas Installation
Code CAN/CGA-B149.1
The appliance and its individual shutoff valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at test pressures in excess of ½
psig (3.45 kPa).
The appliance must be isolated from the gas
supply piping system by closing its individual
manual shutoff valve during any pressure
testing of that system at test pressures equal
to or less than ½ psig (3.45 kPa).
Make certain that the air intake openings in the
bottom of the appliance are not obstructed. They
are essential for proper combustion and operation
of appliance.
Maintain adequate clearance in front of unit for
servicing and proper operation. NOTE: All
servicing can be done through front door.
! This equipment is to be installed to comply
with the appliance Federal State or local plumbing
codes having jurisdiction.
THIS APPLIANCE IS EQUIPPED FOR
NATURAL GAS, with orifices sized for operation
with natural gas.
Leave in front view the labels containing the
following warnings:
! WARNING: improper installation,
adjustment, alteration, service or
maintenance can cause property
damage, injury or death.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
FOR YOUR SAFETY: do not store
or use gasoline or other flammable
vapours or liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS.
Do not try to light appliance.
Do not touch any electric switch
Do not use any phone in the
building.
Immediately call your gas supplier
from a neighbours’ phone.
Follow the gas supplier’s
instructions.
If you cannot reach your gas
supplier call the fire department.
In the design and construction phase, the
manufacturer has paid particular attention to the
aspects that can cause risks to safety and health
of persons that interact with the appliance.
Carefully read the instructions stated in the
manual and those applied directly to the machine,
and particularly respect those regarding safety.
Do not tamper with, evade, eliminate or by-pass
the installed safety devices. Failure to comply with
this requisite can lead to serious risks for personal
health and safety.
After having been appropriately documented, on
commissioning, if necessary, simulate some test
manoeuvres to identify the controls, in particular
those relative to switch-on and switch-off and their
main functions.
The appliance is only destined for the use for
which it has been designed; any other use must
