Side 1/16

B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

FEATURES

BT7517

FLAT SCREEN WALL MOUNT

WITH SINGLE ARM EXTENSION

, TILT & SWIVEL

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Mount

Drill

10mm (7/16") masonry bit

or 6mm (1/4") wood bit

Pencil

Stud finder

(optional)

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Installation Instructions........................................................................................................................6

Additional Mounting Options..................................................................................................................13

Product Dimensions..........................................................................................................................14

B-Tech Contact Details.....................................................................................................................16

PLEASE KEEP THIS FOR FUTURE REFERENCE

13mm (1/2") spanner

or socket

● Designed for medium flat screens up to 42" (107cm) / 25kg (55lbs)

● Fits screens with VESA mounting patterns:

75 x 75mm, 100 x 100mm, 200 x 100mm and 200 x 200mm

● Featuring on wall levelling at wall plate

and screen mount

● Easy tilt adjustment +/- 40° tilt

● Features two swivel points: 180° at wall and 240° at interface

● Security locking screws and Allen key provided for a secure installation

● Simple ‘hook-on’ installation with all mounting hardware included

COMPATIBLE

Community Design Nos.

001713280-0012

001713280-0017

Produkspesifikasjoner

Merke:	B-tech
Kategori:	Flatpanelstøtte
Modell:	BT7517
Antall skjermer som støttes:	1
Maksimal skjermstørrelse:	42 "
Minimum skjermstørrelse:	- "
Produktfarge:	Sort
Vippevinkelområde:	-40 - 40 °
Panelmonterbart grensesnitt:	75 x 75,100 x 100,200 x 100,200 x 200 mm
Montasjetype:	Vegg
Maksimalvekt (kapasitet):	25 kg
Monteringsgrensesnitt, kompatibilitet (min):	75 x 75 mm
Monteringsgrensesnitt, kompatibilitet (maks):	200 x 200 mm
