Side 1/43

19" Widescreen Rack-Mount Console

with Built-In PRO3 KVM Switch

User Manual

8820-00768 Rev. A00 F1DC108H/F1DC116H

19” Widescreen Rack-Mount Console with Built-In PRO3 KVM Switch

SECTIONS 1 2 3 654 87Table of Contents

TABLE OF CONTENTS

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents ............................................ 2

2 Overview. ...............................................3

Feature Overview............................................. 3

Equipment Requirements ...................................... 4

System Requirements ......................................... 5

Unit Display Diagrams......................................... 6

Specifications................................................ 7

3 Installation...............................................8

Pre-Configuration ............................................. 8

Connecting Servers to the Rack-Mount Console.................... 9

Connecting the Rack-Mount Console with Multiple

PRO3 KVM Switches (Daisy-Chaining) .......................... 13

Powering Up the Systems ................................... 17

4 Using your Rack-Mount Console ......................... 18

Selecting a Server or BANK Using Hot-Key Commands........ 18

AutoScan Mode ............................................ 21

On-Screen Display (OSD) ................................... 21

Keyboard Hot-Key-Command Shortcuts ......................27

Sun Combo and Mac Key Mapping...........................28

Updating Firmware ......................................... 29

5 Frequently Asked Questions. ............................30

6 Troubleshooting........................................32

7 Glossary ..............................................35

8 Information ............................................ 37

19” Widescreen Rack-Mount Console with Built-In PRO3 KVM Switch

SECTIONSTable of Contents 2 3 654 871

INTRODUCTION

Congratulations on your purchase of the Belkin 19-inch Widescreen

Rack-Mount Console with Built-In PRO3 KVM Switch (the Rack-Mount

Console). Our diverse line of KVM solutions exemplifies the Belkin

commitment to delivering high-quality, durable products at an

affordable price.

Designed to give you control over multiple servers, the Rack-Mount

Console provides an excellent solution for the server administrator.

It outperforms any other rack console with KVM switch on the market.

Engineered to work with the most advanced server room and laboratory

environments, this Rack-Mount Console offers:

• Single-railsystemwith1Ucompactdesign

• Videoresolutionsupportofupto1440x900

• PS/2andUSBsupportforinputdevices

• On-ScreenDisplay(OSD)

• Daisy-chaincapabilitywithotherBelkinPROswitches

(up to 256 servers)

• Security

• Flash-upgradeablefirmware

• Dual-portmicro-cabling(cablekitssoldseparately)

• Belkin2-YearWarranty

• Freetechnicalsupport

• 19-inchWidescreenLCD

Produkspesifikasjoner

Merke:	Belkin
Kategori:	Server
Modell:	F1DC101H
Vekt:	10800 g
Bredde:	482.6 mm
Dybde:	736.6 mm
Høyde:	44.5 mm
AC-adapter inngangsspenning:	100 - 240 V
Synsvinkel, horisontal:	178 °
Skjermoppløsning:	1440 x 900 piksler
Produktfarge:	Sort
Skjermdiagonal:	19 "
Strømforbruk (vanlig bruk):	48 W
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Synsvinkel, vertikal:	170 °
Relativ luftfuktighet under drift (H-H):	0 - 80
Videoopptaksgrensesnitt:	VGA, USB, PS/2
Pikselbredde:	0.2835 x 0.2835 mm
Display antall farger:	16.78 million farger
Størrelseforhold:	16:10
Display:	LCD
Innebygget touchpad:	Ja
AC-adapter frekvens:	50/60 Hz
Innebygd KVM-bryter:	Nei
Høyde (i stabelenheter):	1
Tastenes levetid:	8 millioner tegn
