877-877-2269 | blackbox.com877-877-2269 | blackbox.com 877-877-2269 | blackbox.com

Page 5 Page 6

Black Box and the Double Diamond logo are registered trademarks of

BB Technologies, Inc. Any other trademarks mentioned in this manual

are acknowledged to be the property of the trademark owners

ICI207A, version 2

Quick Start Guide

Isolated and non-isolated models available.

Industrial Grade 7-Port USB Hubs

ICI207A

ICI208A

Black Box Tech

Support: FREE! Live.

24 / 7. Tech support

the way it should be.

Great tech support is just 60 seconds

away at 877-877-2269 or BlackBox.com.

Order toll-free in the U.S. or for

FREE 24/7 technical support:

Call 877-877-BBOX

(outside U.S. call 1-724-746-5500)

www.blackbox.com

info@blackbox.com

Contact

Information

Industrial Grade 7-Port USB Hub

Table 1. LED indicators.

LED Type State Description

External Power

External power is applied, and an active

host connection exists. The hub will

provide 500 mA per downstream port.

OFF No power is present.

Port LEDs 1–7

ON Port is active and ready for use.

OFF

Port has a fault. Power may need to be

cycled.

Troubleshooting

Problem: Do I need drivers for the hub?

Solution: No, the operating system will detect it and

install it automatically.

Problem: How can I be sure it has been installed?

Solution: The new hub will be listed in the Device

Manager.

Problem: Can I use USB 1.1 and USB 2.0 devices

together?

Solution: Yes. USB 2.0 is backwards-compatible with

USB 1.0 and 1.1.

SUITABLE FOR USE IN CLASS I, DIVISION 2,

GROUPS A, B, C AND D HAZARDOUS

LOCATIONS, OR NONHAZARDOUS LOCATIONS

ONLY.

WARNING - EXPLOSION HAZARD -

SUBSTITUTION OF ANY COMPONENT MAY

IMPAIR SUITABILITY FOR CLASS I, DIVISION 2.

WARNING - EXPLOSION HAZARD - DO NOT

DISCONNECT EQUIPMENT WHILE THE CIRCUIT IS

LIVE OR UNLESS THE AREA IS KNOW TO BE FREE

OF IGNITABLE CONCENTRATIONS.

INSTALL IN ACCORDANCE WITH CONTROL

DRAWING NUMBER 260-10135-00

Produkspesifikasjoner

Merke:	Black Box
Kategori:	datatilbehør
Modell:	ICI207A
Vekt:	600 g
Bredde:	203 mm
Dybde:	120.7 mm
Høyde:	34.9 mm
LED-indikatorer:	Ja
Pakkevekt:	881.7 g
Antall USB 2.0-porter:	8
Utgangsstrøm:	5 V
Antall porter:	7
Produktfarge:	Sort
Pakkedybde:	254 mm
Pakkehøyde:	63.5 mm
Pakkebredde:	165.1 mm
Driftstemperatur (T-T):	-40 - 80 °C
Innebygd kortleser:	Nei
Kroppsmateriale:	Metall
USB-strøm:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 95
Grensesnitt (hub):	USB 1.1, USB 2.0
Overføringshastighet (Mbps):	480 Mbit/s
