4K Audio Integrated
All-in-One ePTZ Camera User Manual
1
Camera Interface
3
Remote Control Specification
2
Packing Box
IR Remote Control × 1ePTZ Camera × 1
USB 3.0 Cable × 1 User Manual × 1
No. Description No. Description
1 Lens 4 Product Label
2 Array Microphone 5 USB 3.0 Interface
3 Brackets with Damper 6 HDMI 2.0 Interface
②
③
④
⑤ ⑥
①
Camera
Video
System
Sony 1/2.5” CMOS
Min
Illumination
0.02Lux @ F1.8,
AGC ON
Pixel
4K@3820*2160
Digital Noise
Reduce
2D, 3D
Zoom 4X Digital Zoom @1080P Shutter 1/30s ~ 1/10000s
Lens F=2.8mm FOV 130° Auto Focus Support
White
Balance
Auto / Indoor /Outdoor/ ONE PUSH, Manual
USB Function
Video
Output
4K@30,25fps; 1080p@30,25fps;
1080i@60,50,30,25fps; 720p@60,50fps
Encoding H.265 / H.264 / MJPEG
UVC
Protocol
Support
Video UVC1.0 - UVC1.5
Audio Function
Built-in YES
Audio USB 3.0
Voice
Pickup
Range
8Meters
HDMI Interface
Video
Output
4K@30,25fps; 1080p@30,25fps;
1080i@60,50,30,25fps; 720p@60,50fps
Encoding H.265 / H.264 / MJPEG
Audio
Output
N/A
ePTZ Support, 4X Digital Zoom @1080P
Interface
USB 3.0
Type B Female
Compatible with all interfaces below
USB3.0, support video, control, power
supply, audio input and output
HDMI 2.0
Compatible with HDMI 2.0, 1.4, 1.3A, 1.3
and other interfaces, only supports video
transmission
User
Manual
①
②
③
④
⑥
⑤
⑦
⑨
⑩
⑪
⑫
⑧
No. Key Function
1 Power Key
After pressing, the camera
enters standby mode
2 P/T RST Key
After pressing, the camera
enters self-check
3 Flip Key
4
Camera
Select Key
Select the camera to be
controlled
5 BLC Key
6 Menu Key Enter/Exist Menu
7
Camera
PTZ
Control Key
Press HOME button, the
camera returnto the middle
position
8
Preset
Setting Key
Press "Preset"+Number(1-9) to
save the corresponding Preset
9
Preset
Reset Key
Press "Reset"+Number(1-9) to
reset the corresponding Preset
10 Focus Key
[AUTO]:Automatic focus
[MANUAL]: Manual focus
[FAR]: Manual focus, make the
far object clearer
[NEAR]: Manual focus, make
the near object clearer
11 Zoom Key + increase, - decrease
12 Number Key
Cooperate with setting /
calling Preset
4
Dome Parameter
Input
Voltage
5V (USB 3.0)
Operation
Temperature
-10° - +50°（14）
Storage
Temperature
-40° ~ 60°
MTBF 50000 hours
Camera
Brackets
Brackets with Damper， Support ±30° adjustment
Dimensions
(L*W*H)
70*70*56mm (Bracket not included）
5
Precaution
6
FAQ
9
Mission Statement
8
Warranty
Electrical Safety
Confirm country and local electrical safety standard when using
or installing the product. The product itself has no power switch.
Please stop power supply or unplug from socket when it is not in
working well. Video wire and control wire should be insulated and
individually connected; cannot mix with other wires.
Transportation with Care
Product should be protected against extremes of stress, vibration
and moisture in transport, storage and installation. It is transported
by integrated packing style.
Power Supply
Product supplies USB3.0 power.
Installation with Care
Don't turn camera head manually. Doing so may result in mechanical
damage.
Product should be put on stable horizontal table, and should not
be installed at a tilt as it may cause a tilted image.
Don't focus the camera directly into the sun or other bright objects.
Don't apply corrosive liquid, gas or solid, to avoid damaging the
cover which is made up of plastic material.
Make sure there is no obstacle with the camera's rotational range
when installing.
Never power on before installation has been completed.
Prohibited Unauthorized Disassemble
Image aspect
No image displayed
The image breaks frequently
Check that the USB port and USB cable of the terminal device are connected
correctly.
Check the software video input settings to see if the camera video input is
set to 1920 * 1080.
Control aspect
Remote control doesn’t work
1) Check and replace the batteries.
2) Check if the camera working mode is correct.
BZBGEAR wants to assure you peace of mind. All BZBGEAR cameras
and camera-related products include our Stress-Free Three-Year
Warranty.
For complete warranty information, please visit
BZBGEAR.com/warranty.
For questions, please call 1.888.499.9906 or email
support@bzbgear.com.
BZBGEAR manifests from the competitive nature of the audiovisual
industry to innovate while keeping the customer in mind. AV
solutions can cost a pretty penny, and new technology only adds to
it. We believe everyone deserves to see, hear, and feel the
advancements made in today’s AV world without having to break
the bank. BZBGEAR is the solution for small to medium-sized
applications requiring the latest professional products in AV.
We live in a DIY era where resources are abundant on the internet.
With that in mind, our team oers system design consultation and
expert tech support seven days a week for the products in our
BZBGEAR catalog. You’ll notice comparably lower prices with
BZBGEAR solutions, but the quality of the products is on par with
the top brands in the industry. The unparalleled support from our
team is our way of showing we care for every one of our customers.
Whether you’re an integrator, home theater enthusiast, or a
do-it-yourselfer, BZBGEAR oers the solutions to allow you to focus
on your project and not your budget.
Don’t disassemble the camera voluntarily as this will void the
warranty. BZBGEAR is not responsible for any unauthorized
modification or dismantling.
1) Check the USB3.0 Cable to see if it is connected to your device
correctly. Check that the Power Indication light is green.
2) Check that the Video Format meets your TV/Monitor or Display
requirements.
3) Check that the USB Port and USB Cable of the terminal device are
connected correctly or whether this device is recognized.
