Your music + our passion

351R

azur

AV receiver

User's manual

ENGLISH

Contents

Make sure you register your purchase.

Visit: www.cambridge-audio.com/sts

By registering, you'll be the rst to

know about:

 Future product releases

 Software upgrades

 News, events and exclusive offers

plus competitions!

This guide is designed to make installing and using this product

as easy as possible. Information in this document has been

carefully checked for accuracy at the time of printing; however,

Cambridge Audio's policy is one of continuous improvement,

therefore design and specications are subject to change

without prior notice.

This document contains proprietary information protected by

reproduced by any mechanical, electronic or other means, in any

form, without prior written permission of the manufacturer. All

trademarks and registered trademarks are the property of their

respective owners.

Incognito and Incognito Ready are trademarks of Cambridge

Manufactured under license from Dolby Laboratories. "Dolby"

and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #'s: 5,451,942;

5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535;

7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S.

and worldwide patents issued & pending. DTS is a registered

trademark and the DTS logos, Symbol, DTS-HD and DTS-HD

"HDMI","HDMI logo" and "High-Denition Multimedia Interface"

are trademarks or registered trademarks of HDMI Licensing LLC.

Introduction .........................................................................................................3

Before connecting ...............................................................................................3

Important safety instructions .............................................................................4

Limited warranty ..................................................................................................5

Front panel connections .....................................................................................6

Rear panel connections ......................................................................................7

Remote control ....................................................................................................8

Front panel display ..............................................................................................9

Aerial connections ...............................................................................................9

Loudspeaker connections ..................................................................................9

Analogue audio connections ........................................................................... 10

Digital audio connections ................................................................................ 10

HDMI input connections .................................................................................. 11

Video output connection (HDMI) ..................................................................... 11

351R setup ....................................................................................................... 12

1. Speaker conguration ............................................................................. 12

2. Speaker setup .......................................................................................... 13

Speaker Delay .............................................................................................. 13

Level calibration ........................................................................................... 13

CAMCAS Auto speaker setup for Distance/Level ....................................... 13

3. Source setup ............................................................................................ 15

Surround sound modes ................................................................................... 15

Operating instructions ......................................................................................16

Selecting the source .....................................................................................16

DSP modes ....................................................................................................16

Stereo/Stereo + Sub .....................................................................................16

Other modes ..................................................................................................16

Analogue Stereo Direct .................................................................................16

Multi Channel PCM .......................................................................................16

Decode modes ..............................................................................................17

Using the Tuner ............................................................................................ 18

Storing stations ............................................................................................ 18

Radio Data Systems (RDS) .......................................................................... 18

Lip sync ......................................................................................................... 18

Audio Return Channel .................................................................................. 18

Advanced setup ............................................................................................ 19

Sub crossovers and bass management ..................................................... 19

Tone/Sub conguration ............................................................................... 19

OSD setup ..................................................................................................... 20

Dolby/DTS adjustments ............................................................................... 20

1. Panorama mode ..................................................................................... 20

2. Centre Width ............................................................................................ 20

3. Dimension ................................................................................................ 20

4. Dynamic range control ............................................................................ 20

Custom installation (C.I.) use .......................................................................... 20

Reset/Back-up memory ................................................................................... 20

Troubleshooting .................................................................................................21

Technical specications ....................................................................................21

Produkspesifikasjoner

Merke:	Cambridge
Kategori:	Mottaker
Modell:	Azur 351R
Vekt:	8200 g
Bredde:	430 mm
Dybde:	330 mm
Høyde:	100 mm
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Garantikort:	Ja
Hodetelefonutganger:	1
HDMI-versjon:	1.4a
Audio Return Channel (ARC):	Ja
HDMI inn:	4
Antall HDMI-utganger:	1
FM-bånd:	87.5 - 108 MHz
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
AirPlay:	Nei
Strømforbruk (standby):	0.5 W
Produktfarge:	Sort
Hodetelefontilkobling:	6,3 mm
RS-232-port:	1
Strømforbruk (vanlig bruk):	500 W
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Nei
Optisk stasjon inkludert:	Nei
Ethernet/bredbåndsforbindelse:	Nei
Lyd-utgang kanaler:	5.1 kanaler
RS-232-tilkobling:	Ja
Display:	LED
Mottakertype:	Surround
Støttede radiobånd:	FM
Apple docking-kompabilitet:	Støttes ikke
Lyd D/A-konverterer (DAC):	24-bit/192kHz
Digital optisk lydinngang:	1
Effekt pr. kanal (20-20KHz@8 Ohm):	50 W
Digital koaksialinngang for lyd:	2
