azur 540P/640P

Phono pre-amplifer

User’s manual

The 640P uses more exotic amplification circuitry to provide even lower

distortion and noise plus the higher gain stage for MC cartridges. In

addition, the 640P employs multi-parallel capacitors to achieve

exceptional RIAA accuracy of only 0.3dB up to 50kHz and features a

defeatable subsonic filter.

Now we invite you to sit back, relax and enjoy!

Matthew Bramble

Technical Director

2 Azur phono pre-amplifier

Thank you for purchasing this Cambridge Audio azur series phono pre-

amplifier. It is the result of our ongoing research and development

program for over three decades of producing high quality audio

products. We hope that you will appreciate the results and enjoy many

years of listening pleasure.

About this phono pre-amplifier

The design of a high quality but cost-effective phono pre-amplifer

presents a major challenge. Providing first-class performance on an

unlimited budget is one matter; achieving the same performance within

tight price limits is quite another, and requires all the expertise and

experience that Cambridge Audio brings to its product design process.

We believe we have succeeded in our aim of creating a first-class

affordable product.

The 540P features a moving magnet stage whilst the 640P offers

moving magnet and moving coil stages. Both use discrete transistors for

the all-important input stages instead of the more common integrated

circuits.

Both are designed to produce high gain and linearity, without requiring

massive amounts of negative feedback to achieve low distortion. These

new models also employ a single-ended ‘Class A’ gain stage with

audiophile passive RIAA equalisation.

High quality components are used throughout such as 1% metal film

resistors and close tolerance polypropylene capacitors.

INTRODUCTION

540P/640P Phono pre-amplifer

Azur phono pre-amplifier 3

Introduction .................................................................................................2

Important safety Information......................................................................3

Rear panel connections..............................................................................4

Troubleshooting......................................................................................... 6

Specifications ............................................................................................6

Limited warranty....................................................................................... 7

CONTENTS

Please take a moment to read these notes before installing your Azur

phono pre-amplifier, they will enable you to get the best performance

and prolong the life of the product. We advise you follow all instructions,

heed all warnings and keep the instructions for future reference.

This unit must not be exposed to dripping or splashing water or other

liquids. No objects filled with liquid, such as vases, shall be placed on

the unit. In the event, switch off immediately, disconnect from the mains

supply and contact your dealer for advice.

Do not route the power cable so that it can be walked upon or damaged

by other items near it.

Electronic audio components have a running in period of around a week

(if used several hours per day). This will allow the new components to

settle down, the sonic properties will improve over this time.

If you do not intend to use this unit for a long period of time, unplug it

from the mains socket.

To clean the unit, wipe its case with a moist, lint-free cloth. Do not use

any cleaning fluids containing alcohol, ammonia or abrasives. Do not

spray an aerosol at or near the amplifier.

These units are not user serviceable, never attempt to repair,

disassemble or reconstruct the unit if there seems to be a problem. A

serious electric shock could result if this precautionary measure is

ignored. In the event of a problem or failure, please contact your dealer.

IMPORTANT SAFETY INSTRUCTIONS

Produkspesifikasjoner

Merke:	Cambridge
Kategori:	Mottaker
Modell:	Azur 540P
Vekt:	800 g
Bredde:	215 mm
Dybde:	133 mm
Høyde:	46 mm
LED-indikatorer:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Produktfarge:	Sølv
Signal-til-støy-forhold (SNR):	85 dB
Total Harmonic Distortion (THD):	0.009
Lyd-utgang kanaler:	2.0 kanaler
Formål:	Hjem
Frekvensrekkevidde:	20 - 20000 Hz
Tilkoblingstype høyttalere:	RCA
Forsterker, klasse:	A
Peak effekt per kanal:	5 W
Utgående nivå:	300 mV
Crosstalk/krysstale (1kHz):	76 dB
