Side 1/6

WWW.CAMBRIDGEAUDIO.COMWWW.CAMBRIDGEAUDIO.COMWWW.CAMBRIDGEAUDIO.COM

CX SERIES

CUTTING EDGE DIGITAL AUDIO

CXA80 / CXA60

INTEGRATED AMPLIFIERS

WWW.CAMBRIDGEAUDIO.COMWWW.CAMBRIDGEAUDIO.COM

CX SERIES

Designed from the ground up for the

new CX Series, the Cambridge CXA60

and CXA80 deliver stunning analogue

amplication, combined with high quality

digital to analogue conversion. The result

is two integrated ampliers that are perfect

for today’s digital sources as well as

traditional analogue ones.

We all love to play our music from a variety

of sources which have a range of analogue

and digital outputs – from streamers, TVs

and laptops, to CD players and turntables.

By catering for a wide variety of analogue

and digital audio input types, the CXA60

and CXA80 allow all of our different music

sources to receive the same high quality

amplication.

The CXA60 and CXA80 both use a

highly-efcient Class A/B amplier design,

an audiophile grade oversize toroidal

transformer and substantial extruded heat

sinks. This allows the CXA60 to deliver

60 Watts per channel of pure power.

The CXA80 goes even further with an

ingenious dual-mono amplier design,

outputting 80 Watts per channel.

With analogue RCA and 3.5mm inputs,

coaxial and optical digital inputs, and a

high quality Wolfson DAC, these ampliers

will handle your music sources for years

to come. Adding to the impressive

specication, the CXA80 also features

an asynchronous USB Audio input and a

balanced XLR input.

You can even bring the CXA’s stunning

amplication to all of your apps and

streaming services via your smartphone,

tablet or computer. Connect wirelessly

using the optional BT100 Bluetooth

receiver to listen to popular services

such as YouTube or Spotify played

back in stunning quality through the

CXA60 and CXA80.

TWO AMPLIFIERS FOR THE DIGITAL AGE

CXA60

STEREO AMPLIFIER

CXA80

STEREO AMPLIFIER

CXN

NETWO R K PL AY ER

CXR120

AV RECEIVER

CXR200

AV RECEIVER

CXC

DEDICATED CD TRANSPORT

CXA60/CXA80

CXA60 CXA80

INTEGRATED AMPLIFIERS

• 2 x 60 Watts of power

• Wolfson DAC

• Toroidal transformer

• Optional Bluetooth

• 2 x 80 Watts of power

• Balanced XLR input

•

Asynchronous USB Audio input

• Wolfson DAC

• Toroidal transformer

• Optional Bluetooth

WWW.CAMBRIDGEAUDIO.COMWWW.CAMBRIDGEAUDIO.COM

High performance USB (CXA80 only)

With more and more of us enjoying

music from our computers, the CXA80

features a high quality asynchronous

USB Audio input, allowing it to act as

a high quality external sound card for

your computer or laptop. Featuring

asynchronous USB audio clocking,

and supporting both USB Class 1 and

USB Class 2, the CXA80 can be used

to play everything from MP3s to the

highest quality 24-bit/192kHz studio

master recordings from your computer

or laptop, all free from unwanted noise,

jitter and distortion.

Maximise streaming services and Apps

Bring the amplier’s stunning, superior

audio quality to all your apps and

streaming services via your smartphone,

tablet or computer. Instantly and

easily listen to popular services such

as YouTube or Spotify played back in

stunning quality through the CXA60 and

CXA80’s Bluetooth connection.

HELPING US ACHEIVE THIS INCREDIBLE SOUND ARE SOME OTHER KEY FEATURES RARELY SEEN AT THIS PRICE POINT

Toroidal transformer

We use a highly efcient Class A/B

amplier design, a centrally mounted

audiophile grade oversize toroidal

transformer, and substantial extruded

heatsinks.

This allows the CXA80 to deliver 2 x 80

Watts RMS into 8 Ohms. Into 4 Ohms,

this increases to 2 x 120W.

The CXA60 delivers 2 x 60 Watts RMS

into 8 Ohms. Into 4 Ohms, this increases

to 2 x 90W.

Stunning stereo imaging

An ALPs lm type volume pot delivers

superb low level channel balance and

stereo imaging.

Superb separation

The internal PCB layout is optimised

for minimal left/right ‘crosstalk’ and to

maximise the quality of stereo separation.

By entirely separating the left and

right channel heat sinks, and using

symmetrical and separated circuit paths

for the two channels, we ensure that

the CXA60 and CXA80 deliver stunning

stereo separation and minimum cross-

channel interference.

Careful positioning

We mount the premium toroidal

transformer centrally, away from the

sensitive preamp circuitry to avoid any

heat disturbance.

Dual mono design (CXA80 only)

Separate transformer taps for left and

right channels, twin rectiers and separate

PSUs give dual mono operation of the left

and right power ampliers.

Produkspesifikasjoner

Merke:	Cambridge
Kategori:	Mottaker
Modell:	CXA80
Vekt:	8700 g
Bredde:	430 mm
Dybde:	341 mm
Høyde:	115 mm
Tilkoblingsteknologi:	Ledning & Trådløs
Antall USB 2.0-porter:	1
Hodetelefonutganger:	1
Strømforbruk (standby):	0.5 W
Produktfarge:	Sølv
Hodetelefontilkobling:	3,5 mm
Strømforbruk (vanlig bruk):	750 W
Signal-til-støy-forhold (SNR):	- dB
Lyd-utgang kanaler:	11.0 kanaler
Digital koaksialutgang for lyd:	1
XLR i:	Ja
Forsterker, klasse:	A/B
RMS utgangseffekt pr. kanal (4 Ohm):	120 W
Linje innganger (RCA):	4
Peak effekt per kanal:	120 W
RMS utgangseffekt pr. kanal (8 Ohm):	80 W
