Side 1/8

azur 540P/640P

Phono pre-amplifer

User’s manual

The 640P uses more exotic amplification circuitry to provide even lower

distortion and noise plus the higher gain stage for MC cartridges. In

addition, the 640P employs multi-parallel capacitors to achieve

exceptional RIAA accuracy of only 0.3dB up to 50kHz and features a

defeatable subsonic filter.

Now we invite you to sit back, relax and enjoy!

Matthew Bramble

Technical Director

2 Azur phono pre-amplifier

Thank you for purchasing this Cambridge Audio azur series phono pre-

amplifier. It is the result of our ongoing research and development

program for over three decades of producing high quality audio

products. We hope that you will appreciate the results and enjoy many

years of listening pleasure.

About this phono pre-amplifier

The design of a high quality but cost-effective phono pre-amplifer

presents a major challenge. Providing first-class performance on an

unlimited budget is one matter; achieving the same performance within

tight price limits is quite another, and requires all the expertise and

experience that Cambridge Audio brings to its product design process.

We believe we have succeeded in our aim of creating a first-class

affordable product.

The 540P features a moving magnet stage whilst the 640P offers

moving magnet and moving coil stages. Both use discrete transistors for

the all-important input stages instead of the more common integrated

circuits.

Both are designed to produce high gain and linearity, without requiring

massive amounts of negative feedback to achieve low distortion. These

new models also employ a single-ended ‘Class A’ gain stage with

audiophile passive RIAA equalisation.

High quality components are used throughout such as 1% metal film

resistors and close tolerance polypropylene capacitors.

INTRODUCTION

Produkspesifikasjoner

Merke:	Cambridge
Kategori:	Mottaker
Modell:	Azur 640P
Vekt:	900 g
Bredde:	215 mm
Dybde:	133 mm
Høyde:	46 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Produktfarge:	Sølv
Signal-til-støy-forhold (SNR):	86 dB
Total Harmonic Distortion (THD):	0.007
Lyd-utgang kanaler:	2.1 kanaler
Formål:	Hjem
Frekvensrekkevidde:	20 - 20000 Hz
Tilkoblingstype høyttalere:	RCA
Peak effekt per kanal:	5 W
Utgående nivå:	300 mV
Crosstalk/krysstale (1kHz):	76 dB
