Your music + our passion

AM1/AM5

ENGLISH

Integrated Amplifier

User’s manual

Thank you for purchasing this Cambridge Audio Topaz AM1 or AM5 Stereo

Amplifier. We are confident that you will enjoy many years of listening

pleasure from it. Like all Cambridge Audio products, the AM1 and AM5

adhere to our three core principles – stunning performance, ease of use

and incredible value.

The unit can support a wide range of sources with the Topaz AM5 having

a front panel MP3/Portable Media Player input that allows use with the

headphone or line-level outputs of most portable players.

Part of our new Topaz range this product also features a new casework

design with braced front panel, rigid wrap-over lid assembly and carefully

designed mechanicals for resonance control.

Your amplifier can only be as good as the system it is connected to.

Please do not compromise on the quality of your source equipment,

speakers or cabling. Naturally, we particularly recommend source and

speaker models from the Cambridge Audio range, which have been

designed to the same exacting standards as this product. Your dealer can

also supply excellent quality Cambridge Audio interconnects to ensure

your system realises its full potential.

Thank you for taking the time to read this manual; we recommend you

keep it for future reference.

Matthew Bramble

Cambridge Audio Technical Director

and the AM1/5 design team

Contents Introduction

Introduction .................................................................................................2

Important safety instructions .....................................................................3

Limited warranty..........................................................................................4

Rear panel connections..............................................................................5

Front panel controls....................................................................................5

Connections.................................................................................................6

Technical specifications..............................................................................7

Troubleshooting...........................................................................................7

Make sure you register your purchase.

Visit: www.cambridge-audio.com/sts

By registering, you’ll be the first to know about:

Future product releases

Software upgrades

News, events and exclusive offers plus

competitions!

This guide is designed to make installing and using this product as easy

as possible. Information in this document has been carefully checked

for accuracy at the time of printing; however, Cambridge Audio's policy

is one of continuous improvement, therefore design and specifications

are subject to change without prior notice.

This document contains proprietary information protected by copyright.

All rights are reserved. No part of this manual may be reproduced by any

mechanical, electronic or other means, in any form, without prior written

permission of the manufacturer. All trademarks and registered

trademarks are the property of their respective owners.

AM1

AM5

ENGLISH

For your own safety please read the following important safety instructions

carefully before attempting to connect this unit to the mains power supply.

They will also enable you to get the best performance from and prolong

the life of the unit:

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A

grounding-type plug has two blades and a third grounding prong. The

wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly

at plugs, convenience receptacles and the point where they exit from

the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use with only the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for

long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required

when the apparatus has been damaged in any way, such as the

power-supply cord or plug having been damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus has

been exposed to rain or moisture, does not operate normally, or has

been dropped.

WARNING

– To reduce the risk of fire or electric shock, do not expose this unit to

rain or moisture.

– Batteries (battery pack or batteries installed) shall not be exposed to

excessive heat such as sunshine, fire or the like.

The unit must be installed in a manner that makes disconnection of the

mains plug from the mains socket outlet (or appliance connector from the

rear of the unit) possible. Where the mains plug is used as the disconnect

device, the disconnect device shall remain readily operable. Only use the

mains cord supplied with this unit.

Please ensure there is ample ventilation (at least 10cm clearance all

round). Do not put any objects on top of this unit. Do not situate it on a rug

or other soft surface and do not obstruct any air inlets or outlet grilles. Do

not cover the ventilation grilles with items such as newspapers,

tablecloths, curtains, etc.

This unit must not be used near water or exposed to dripping or splashing

water or other liquids. No objects filled with liquid, such as vases, shall be

placed on the unit.

Important safety instructions

The lightning flash with the arrowhead symbol within an equilateral

triangle is intended to alert the user to the presence of un-insulated

‘dangerous voltage’ within the product’s enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance instructions

in the service literature relevant to this appliance.

The symbol on this product indicates that it is of CLASS II

(double insulated) construction.

WEEE symbol

The crossed-out wheeled bin is the European Union symbol for

indicating separate collection for electrical and electronic

equipment. This product contains electrical and electronic

equipment which should be reused, recycled or recovered and

should not be disposed of with unsorted regular waste. Please return the

unit or contact the authorised dealer from whom you purchased this

product for more information.

CE mark

This product complies with European Low Voltage

(2006/95/EC), Electromagnetic Compatibility (2004/108/EC) and

Environmentally-friendly design of Energy-using Products (2005/32/EC)

Directives when used and installed according to this instruction manual.

For continued compliance only Cambridge Audio accessories should be

used with this product and servicing must be referred to qualified service

personnel.

C-Tick mark

This product meets the Australian Communications Authority’s

Radio communications and EMC requirements.

Ross Test Stamp

This product meets Russian electronic safety approvals.

FCC regulations

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR

TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY

TO OPERATE THE EQUIPMENT.

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of

the following measures:

– Re-orient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.
