Side 1/12
OWNER’S
MANUAL
CAMBRO PRO CART ULTRA
®
www.cambro.com
This manual applies to all Pro Cart Ultra models.
CAUTION: Please read all instructions before using the cart.
Original Instructions verified by Cambro Mfg. Co.
Available in other languages.
Model # ___________________________________
Serial #
––––––––––––––––––––––––––––––––––
Date Installed
––––––––––––––––––––––––––––––
Scan to Download
Manual in Different
Languages.
Passive and/or
Hot Models
ISO 7000-0790ISO 7000-0434
2
Table of Contents
I. Introduction ............................................................................................................................................................................................ 2
II. Safety Instructions and Warnings ........................................................................................................................................................2-3
III. Rail Installation and Capacity Guide ....................................................................................................................................................... 4
IV. Operating Instructions for Electric Use ................................................................................................................................................5-6
V. Operating Instructions for Non-Electric Use ............................................................................................................................................ 6
VI. Care & Maintenance ............................................................................................................................................................................ 6-8
VII. Troubleshooting Guide .........................................................................................................................................................................8-9
VIII. Instructions for Security Package (S) Models .......................................................................................................................................... 9
IX. PCU/PCUL Hitch Installation ................................................................................................................................................................. 10
X. Replacement Parts ............................................................................................................................................................................... 11
XI. Warranty and Product Liability .............................................................................................................................................................. 12
Congratulations on the purchase of your new Cambro Pro Cart Ultra
®
! This Owners Manual provides you with a step-by-step guide to operating and maintaining your
new insulated transporter – versatile enough to hold hot or cold food. If you have any further questions, please contact your Cambro Sales Representative,
visit www.cambro.com or call our Customer Service Department at 800.833.3003 (International customers please call 1.714.848.1555).
I. Introduction
IMPORTANT: Read all instructions prior to use and save for future reference.
Follow all warnings marked on unit.
Use only type of power supply (voltage, phase, frequency) indicated on the heater unit label.
Do not use if power cord is frayed or damaged.
Connect unit to properly grounded power source.
Use only manufacturer authorized power cord and replacement parts.
Warning! Do not use this equipment in wet or damp conditions.
Warning! Unplug unit prior to cleaning or service.
Warning! Remove power cord prior to cleaning. Clean with damp cloth only.
Warning! Do not submerge in water and never spray water on or near it.
Warning! Do not get the thermometer wet in any way.
Warning! Unplug the power cord before removing the hot or cold module.
Warning! Only Cambro Authorized Service Agent or qualified foodservice equipment technician should open
the inner cover of any electrical items for servicing.
During normal operation, check the heater screws for tightness at least once a week.
Any operating problems not identified and corrected by instructions in this manual should be referred to
a qualified service personnel (electrician or foodservice equipment technician).
Caution: Maximum load for this cart is 560 pounds (254 kg). Empty weight 245.90 lbs. (111.5 kg) to 274.5 lbs. (124.5 kg) based on configuration.
Caution: Maximum load for each rail set is 40 pounds (18,14 kg).
Warning! Do not store explosive substances such as aerosol cans with flammable propellant inside the appliance.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
II. Safety Instructions and Warnings
Electrical Specifications
(Per Compartment)
HOT 110V HOT 220V COLD
REQUIRED VOLTAGE
100-125 VAC 200-230 VAC 100-230 VAC
MAXIMUM AMP
4.6a 2.3a 3.26a, 1.42a
WATTS / HEATER OR COOLER
529w 506w 326.6w
HERTZ
50/60 50/60 50/60
PHASE
Single Single Single
ALTERNATE PLUG TYPES
AVAILABLE FOR THESE COUNTRIES
US, Canada, Mexico, China,
Europe, UK, Ireland, Australia, South Africa, Japan
POWER CORD LENGTH
9 ft./ 2,7 m
* If country is not listed, please call Cambro Customer Service for details.
For all electric PCU cold module, plug into 100-120 VAC (110v models) or 200-230VAC (220v models) 50/60 HZ electrical
receptacle. Product label located on the unit clearly indicates power requirements.
Caution: Metal rails and
heater housing are hot
when cart is in use.
3
IMPORTANT!
The conductor having green/yellow insulation shall only be connected to a terminal marked or
If it is essential for the safety of the appliance, the tag shall be provided either with a wiring diagram showing
the connection of the other conductors or with the following text:
For the connection of the other conductors, see the enclosed instructions for installation.
