OWNER’S
MANUAL
CAMBRO
®
PRO CART ULTRA
www.cambro.com
This owner's manual applies to all electric and non-electric
models that begin with the prefix PCU.
2
Table of Contents
I. Introduction ............................................................................................................................................................................................ 2
II. Safety Instructions and Warnings ........................................................................................................................................................... 2
III. Rail Installation and Capacity Guide .................................................................................................................................................... 2-3
IV. Instructions for Security Package (S) Models .......................................................................................................................................... 4
V. Operating Instructions for Electric Use ................................................................................................................................................4-5
VI. Operating Instructions for Non-Electric Use ............................................................................................................................................ 5
VII. Care & Maintenance ............................................................................................................................................................................6-7
VIII. Troubleshooting Guide ............................................................................................................................................................................. 7
IX. Replacement Parts ................................................................................................................................................................................. 8
X. Warranty and Product Liability ................................................................................................................................................................ 8
Congratulations on the purchase of your new Cambro Pro Cart Ultra
! This Owners Manual provides you with a step-by-step guide to operating and maintaining your
new insulated transporter – versatile enough to hold hot or cold food. If you have any further questions, please contact your Cambro Sales Representative,
visit www.cambro.com or call our Customer Service Department at 800.833.3003 (International customers please call 1.714.848.1555).
I. Introduction
IMPORTANT: Read all instructions prior to use and save for future reference.
Follow all warnings marked on unit.
Use only type of power supply (voltage, phase, frequency) indicated on the heater unit label.
Do not use if power cord is frayed or damaged.
Connect unit to properly grounded power source.
Use only manufacturer authorized power cord and replacement parts.
Warning! Do not use this equipment in wet or damp conditions.
Warning! Unplug unit prior to cleaning or service.
Warning! Remove power cord prior to cleaning. Clean with damp cloth only.
Warning! Do not submerge in water and never spray water on or near it.
Warning! Do not get the thermometer wet in any way.
Warning! Unplug the power cord before removing the hot or cold module.
Warning! Only Cambro Authorized Service Agent or qualified foodservice equipment technician should open
the inner cover of any electrical items for servicing.
During normal operation, check the heater screws for tightness at least once a week.
Any operating problems not identified and corrected by instructions in this manual should be referred to
a qualified service personnel (electrician or foodservice equipment technician).
II. Safety Instructions and Warnings
TYPE of CONTAINER
TALL CART
STANDARD
CAPACITY
LOW CART
STANDARD
CAPACITY SET-UP AT NUMBERS
TALL CART
MAXIMUM
CAPACITY
LOW CART
MAXIMUM
CAPACITY
18" x 26" (45,7 x 66 cm) Full Size Sheet Pans 14 7
1, 3, 5, 7, 9, 11, 13
32* 16*
13" x 18" (33 x 45,7 cm) Half Size Sheet Pans 28 14 64* 32*
GN 1/1 Hotel Pans 2
1
/2" (6,5 cm) Deep 20 10
1, 4, 7, 10, 13
32* 16*
GN 1/1 Hotel Pans 4" (10 cm) Deep 20 10 20 10
40 x 60 cm (20
1
/2" x 23
1
/2") Trays 14 7
2, 4, 6, 8, 10, 12, 14
30* 15*
32 x 53 cm (12" x 20") Trays 28 14
1, 3, 5, 7, 9, 11, 13
64* 32*
Pizza Boxes 16" x 16" x 2" (40,6 x 40,6 x 5,1 cm) 14 7 16* 8*
*Additional rails required.
Each cart ships standard with 7 pairs of rails per compartment.
III. Rail Installation and Capacity Guide
3
II
II
TIP: It is easier to start rail installation from the bottom and move up.
1. Using the chart on page 2, select the type of holding you would like to achieve. Follow the
number guides etched into the columns of the cart to place your sheet pan, food pan, tray or
pizza box in the correct position. For example, to achieve standard capacity for full-sized sheet
pans, place the rails at positions 1, 3, 5, 7, 9, 11 and 13.
2. Insert the top tabs into the front and corresponding middle and rear slots of the column.
3. Slide the rails towards the back of the cart then rotate it down into a nested position.
4. Install the subsequent rails into position following the appropriate numbering guide. Once the
rails have been installed on one side of the cart, repeat instructions to congure the other side.
III. Rail Installation and Capacity Guide (continued)
18" x 26" (45,7 x 66 cm)
Full Size Sheet Pans
4" (10 cm) Deep
Full Size Food Pans
(Pans t 2 deep)
Large Pizza Boxes
16" x 16" x 2" (40,6 x 40,6 x 5,1 cm)
MAXIMUM
16 / compartment
16 / Low Cart
32 / Tall Cart
MAXIMUM
8 / compartment
8 / Low Cart
16 / Tall Cart
STANDARD
7 / compartment
7 / Low Cart
14 / Tall Cart
STANDARD and MAXIMUM
10 / compartment
10 / Low Cart
20 / Tall Cart
STANDARD
7 / compartment
7 / Low Cart
14 / Tall Cart
13" x 18" (45,7 x 66 cm)
Half Size Sheet Pans
(Trays t 2 deep)
40 x 60 cm (20
1
2" x 23
1
2") Trays
MAXIMUM
32 / compartment
32 / Low Cart
64 / Tall Cart
MAXIMUM
15 / compartment
15 / Low Cart
30 / Tall Cart
MAXIMUM
16 / compartment
16 / Low Cart
32 / Tall Cart
MAXIMUM
32 / compartment
32 / Low Cart
64 / Tall Cart
STANDARD
14 / compartment
14 / Low Cart
28 / Tall Cart
STANDARD
7 / compartment
7 / Low Cart
14 / Tall Cart
STANDARD
10 / compartment
10 / Low Cart
20 / Tall Cart
STANDARD
14 / compartment
14 / Low Cart
28 / Tall Cart
2
1
2" (6,5 cm) Deep
Full Size Food Pans
32 x 53 cm (12" x 20") Trays
(Trays t 2 deep)
