Side 1/1
FlashingFlashing
Daytime
HyperFlash 1
Daytime
HyperFlash 1
Group RideGroup Ride
Daytime
HyperFlash 2
Daytime
HyperFlash 2
HighHigh LowLow
*1
ON
OFF
4
1
2
3
Design Pat. Pending
Copyright© 2025 CATEYE Co., Ltd.
TLLD830-250318
1.1
WARNING!!!
(Risk of death; Prevention of accidents)
• To prevent accidents and to ensure safe riding, make sure the
light is securely attached to the bracket and it is functioning
properly without being unobstructed before the ride.
• Always pay attention to the remaining battery power by
checking the indicator periodically while using the light.
•
Do not disassemble or modify the light or any of the included items
.
• Do not use a damaged rubber band.
CAUTION!
(Prevention of injury, damage, or property damage)
• Stop your bicycle to operate the switch.
• Keep device out of the reach of children.
•
This device is rated IPX4 based on IEC 60529. Do not immerse
the device in water. Doing so may cause a malfunction. Wipe off
any moisture after using the device in rainy weather.
• Do not subject the light to strong vibrations, impacts, or
excessive force. Discontinue use if any abnormality occurs.
• Do not charge or use the battery at any voltage or polarity
other than that specified. Do not short-circuit the battery.
• Do not drop the light into a fire or heat the light.
• Due to the variability of LEDs, the color and brightness may
differ even between devices with the same model number.
• If the light unit or parts become dirty with mud, etc., clean
with a soft cloth which is moistened with mild soap. Never
apply paint thinner, benzine or alcohol; damage will result.
LITHIUM-ION BATTERIES
Recharge the battery for first time use or after long period
of storage :
The voltage of the battery may drop due to self-discharge
during long period of storage.
• Always fully charge the battery before use.
• If the device will not be used for a long period of time, store
it in a location that is not too hot or too humid.
• Charge the battery for about 30 minutes every 6 months.
Cautions for charging and usage :
•
Charging, discharging, and storing in high temperatures will cause
the rechargeable battery to deteriorate faster. Do not place the light
inside a vehicle or near a heater. Make sure to charge only when the
ambient temperature is between 5 and 40°C.
• Please be sure that no dust or other foreign objects are
attached to the plug of the USB cable before charging.
• Do not apply a load to the connector port by hanging the
light unit during charging.
• Do not subject the light to vibrations while charging.
• Once charging is completed, be sure to disconnect the USB
cable from the charging port.
•
After charging is complete, securely attach the charging port
cover to ensure waterproofing before riding.
• Charging and lighting times are approximate values, and will
vary by environmental and user conditions.
• If the illumination time is significantly reduced even after
proper charging, the rechargeable battery may be nearing the
end of its service life.
Cautions for dispose :
When disposing the light unit, please do so in accordance
with your local regulations.
Before using the product, be sure to read this manual thoroughly
and keep it available for future reference. If a child uses it, the
child’s guardian must read the manual and explain the precau-
tions for use to the child. This product is developed assuming
use by bicycle. Do not use the product in any way other than as
described in this manual.
RECHARGEABLE SAFETY LIGHT
MODEL : TL-LD830
Light unit Bracket
(
SP-14-RA
)
Bracket
rubber pad
Rubber band
Switch
Light source LED x 1
Battery Li-ion Polymer 3.7 V 320 mAh
Charge terminal USB Type-C
Operating time
*2
High : Approx. 3.5 hours
Low : Approx. 20 hours
Flashing : Approx. 60 hours
Group Ride : Approx. 25 hours
Daytime HyperFlash 1 : Approx. 15 hours
Daytime HyperFlash 2 : Approx. 20 hours
Charging time Approx. 3 hours (0.5 A)
Charge voltage 5 V
Temperature range Charging : 41°F – 104°F (5°C – 40°C)
Operating : 14˚F – 104˚F (-10˚C – 40˚C)
Waterproof IPX4
Recharge / discharge number of times
About 300 times (until the rated capacity drops to 70%)
Dimensions / Weight
1-3/16” x 1-17/64” x 1-3/16” (30 x 32 x 30 mm)
0.72 oz (20.5 g)
*2 Approximate average runtime at 68°F (20°C).
* The specifications and design are subject to change without notice.
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials
and workmanship for a period of 2 years from original purchase. If the
product fails to work during normal use, CatEye will repair or replace
the defect at no charge. Service must be performed by CatEye or an
authorized retailer. To return the product, pack it carefully and enclose
the warranty certificate (proof of purchase) with instruction for repair.
Please write or type your name and address clearly on the warranty
certificate. Insurance, handling and transportation charges to CatEye
shall be borne by person desiring service. For UK and REPUBLIC OF
IRELAND consumers, please return to the place of purchase. This does
not affect your statutory rights.
SPECIFICATIONS LIMITED WARRANTY
Approx.
Charging port cover
Indicator
Charging time
3h
(
0.5A
)
Charging
Charging is
completed
The USB cable is not included in the
package because CATEYE is
committed to making environmentally
friendly and resource-saving products.
CATEYE will continue to contribute to society by creating
new values in “Safety,” “Health,” and “Environment”.
CATEYE supports the Sustainable Development Goals
movement proposed by the United Nations.
ECO FRIENDLY
( www.cateye.com/intl/company/sdgs/ )
2-8-25, KUWAZU, HIGASHI SUMIYOSHI-KU, OSAKA, JAPAN 546-0041
For inquiries, please visit https://cateye.com/intl/contact
CO., LTD.
[For US Customers]
CATEYE AMERICA, INC.
Please visit https://www.cateyeamerica.com
Toll Free : 800.5.CATEYE
Before using the product, refer to the “LITHIUM-ION BATTERIES” section
and charge the battery.
*1
When turning the light on, it illuminates in the mode that was last used.
(Mode memory function)
Press
and
hold
Click
How to mount to a bicycle
Attach the light securely in the mounting position.
Φ 21.5 - 32 mm
The light can be mounted on aero seat posts with an outer circumference of
approx. 130 mm.
Use only genuine components to prevent accidents and malfunctions.
Standard accessories
5342451 Bracket
Optional accessories
(
Type-A
Type-C
)
(
SP-14-RA
)
5342550 USB cable
(
C-2
)
5342460 Clip
Please prepare a USB cable
(Type-C) that can be used for
charging (sold separately) before
using this product.
*
Automatic battery-saving function:
When the remaining battery power gets low, the indicator starts flashing and the lighting mode changes to
power-save flashing mode (the LED blinking slowly). Charge the product as soon as possible.
* Run time is approximately 1 hour in power-save flashing mode.
