Chapin International, Inc
P.O. Box 549 700 Ellicott St.
Batavia, NY 14021-0549 U.S.A.
1-800-950-4458 www.chapinmfg.com
Model 60175 • 4G/ 15L
017894R0921
Carefully Read These Instructions Before Use
WARNING
Use and Care Manual
DO NOT RETURN THIS
SPRAYER TO STORE
Call: 1-800-950-4458
www.chapinmfg.com
See website for warranty detail
BLEACH & DISINFECTANT
BACKPACK SPRAYER
PRE-USE CHECK: Before each use check tightness of hose nut to be sure hose is securely attached
to the shut-off assembly. Ensure hose is securely attached to the tank by tightening hose clamp if
necessary. Ensure that all nozzle and wand connections are tight. Insure the large pump clamp is
tight. Insure the 2 bolts used to attach the pump lever to the pump shaft are tight.
Do Not exceed a tank solution temperature of 120º F/ 49º C.
NOTE: The tank and hose may have residual water in it due to quality testing performed on the sprayer.
1E
Chapin Backpack Sprayer Operators Manual - English
WARNING
CAUTION
APPLICATIONS & USE FOR YOUR SPRAYER
Avoid using a sprayer for general cleaning purposes if plant protection or herbicide chemicals have already been used
in the sprayer. If a sprayer has been used for plant protection or as an herbicide, clean the sprayer completely (see
cleaning section) before using.
Plant Food: Use different spray patterns for optimum foliage feeding or for fungicide and pesticide application.
Herbicides: Reduce weeds and unwanted plants but avoid using the same sprayer for plant feeding or protection
without thoroughly cleaning (see cleaning section) the sprayer first.
General Household Use: Apply detergents, cleaning solutions, warm water (do not exceed 120°F/49°C) or nontoxic
household cleaning chemicals for carpets, floors, walls, glass, counter tops and ceilings. DO NOT use sprayer that has
been used with herbicides, pesticides or other toxic chemicals for household applications.
General Outdoor Use: Use the sprayer for cleaning windows or with a detergent for general purpose cleaning.
WARNING: IMPROPER USE OR FAILURE TO FOLLOW INSTRUCTIONS CAN RESULT IN
EXPLOSIVE FAILURE CAUSING SERIOUS EYE OR OTHER INJURY
.
For safe use of this product you must read and follow all instructions. Do not leave a pressurized
sprayer in the hot sun. Heat can cause pressure build-up resulting in possible explosion. Do not
store or leave solution in tank after use. Always wear goggles, gloves, long sleeve shirt, long
pants and full foot protection when spraying. Never use any tool to remove pump if there is
pressure in sprayer. Never stand with face or body over top of tank when pumping or loosening
pump to prevent ejectingpump assembly and/or solution from striking and injuring you. Never
pressurize sprayer by any means other than original pump. Do not attempt to modify this
sprayer. Replace parts only with manufacturer’s original parts.
This sprayer is designed for use with bleach solutions only. Never use or mix bleach or
solutions containing bleach with other household chemicals such as toilet bowl cleaners, rust
removers, acids or ammonia containing products. Never spray flammable, acidic, caustic or
other corrosive solutions or heat, pressure, or gas producing chemicals. Always read and
follow chemical manufacturer’s instructions before use with this sprayer as some chemicals
may be hazardous when used with this sprayer.
SK 1157-1
2E
O-ring
Wand
Retaining
Nut
Shut-off
Valve
INSTALLING THE PUMP HANDLE
The pump handle can be mounted on either side of the pump shaft
(A). To install the pump handle place the handle (C) over the shaft (A)
aligning the pump handle hole and shaft hole. Push the straight side of
the R-clip (B) through the aligned hole as shown in figure 1 thru 3.
Figure 2
Line up holes
Figure 3
Slide clip through holes
Figure 1
R Clip
WAND ASSEMBLY
1. Make sure the o-ring is installed on the end of the wand. Insert the wand into shut-off valve.
2. Turn and tighten the retaining nut clock-wise onto the shut-off valve.
1. Poly
Nozzle Cap
2. Retaining
Nut
3. Nozzle
Body
4. Nozzle
Gasket
5. Elbow
Figure 1
NOZZLE ASSEMBLY
Figure 1
Unscrew the nozzle cap (1) from the nozzle body
(3) with retaining nut (2) fastened tightly to the
elbow (5). Unscrew the retaining nut (2). Push
the nozzle body (3) with the nozzle gasket (4) out
of the retaining nut (2). To reinstall the nozzle,
reverse the above instructions.
Chapin Backpack Sprayer Operators Manual - English
SPRAYER COMPONENTS & USE INFORMATION
A. Pump
Shaft
B. R Clip
C. Pump Handle
