Side 1/40
Chapin International, Inc
P.O. Box 549 700 Ellicott St.
Batavia, NY 14021-0549 U.S.A.
1-800-950-4458 www.chapinmfg.com
24V RECHARGEABLE
BACKPACK SPRAYER
See website for warranty detail
Model 63924 • 4G/ 15L
017684 R0421
Carefully Read These Instructions Before Use
WARNING
Use and Care Manual
DO NOT RETURN THIS
SPRAYER TO STORE
Call: 1-800-950-4458
www.chapinmfg.com
1E
Chapin Backpack Sprayer Operators Manual - English
WARNING: IMPROPER USE OR FAILURE TO FOLLOW INSTRUCTIONS CAN RESULT
IN EXPLOSIVE FAILURE CAUSING SERIOUS EYE OR OTHER INJURY.
For safe use of this product you must read and follow all instructions. Do not leave
a pressurized sprayer in the hot sun. Heat can cause pressure build-up resulting in
possible explosion. Do not store or leave solution in tank after use. Always wear goggles,
gloves, long sleeve shirt, long pants and full foot protection when spraying. Do not
attempt to modify this sprayer. Replace parts only with manufacturer’s original parts.
Never spray flammable, caustic, acidic, chlorine, bleach or other corrosive solutions
or heat, pressure, or gas producing chemicals. Always read and follow chemical
manufacturer’s instructions before use with this sprayer as some chemicals may be
hazardous when used with this sprayer.
PRE-USE CHECK: Before each use check tightness of hose nut to be sure hose is securely
attached to the shut-off assembly. Ensure that all nozzle and wand connections are tight.
Do Not exceed a tank solution temperature of 120º F/ 49º C.
NOTE: The tank and hose may have residual water in it due to quality testing performed on
the sprayer.
WARNING
CAUTION
This sprayer is designed to operate with a Chapin 24V Lithium Ion battery ONLY. Any
other batteries could cause serious harm or injury to the operator and serious damage
to the sprayer.
WARNING: For safe operation, read this manual before using the charger.
The battery pack is not fully charged out of the carton. Before using the battery pack
and charger, read the safety instructions below. Then follow charging procedures
outlined.
NOTE: Remove battery and place in charger when not in use.
WARNING
STORAGE RECOMMENDATIONS
1. The best storage place is one that is cool and dry away from direct sunlight and excess heat or cold.
2. Long storage will not harm the battery pack or charger.
CHARGING PROCEDURE
Chapin chargers are designed to charge Chapin battery packs in
3.5-4 hours depending on the pack being charged.
1. Plug the charger into an appropriate outlet before inserting the
battery pack.
2. Insert the battery pack into the charger as shown in figure A.
3. The red light on the charger is continuously on when the battery
is charging.
4. The green light on the charger is continuously on when the battery is charged. The pack is fully charged and
may be used at this time or left on the charger.
5. Blinking red and green lights on the charger indicates a defective battery and should properly be disposed of.
2E
IMPORTANT SAFETY INSTRUCTION FOR BATTERY PACKS
READ ALL INSTRUCTIONS
A
Chapin Backpack Sprayer Operators Manual - English
Do not incinerate the battery pack even if it is severely damaged or is completely worn out. The
battery pack can explode in a fire. Toxic fumes and materials are created when battery packs are burned.
Do Not charge or use battery in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Inserting or removing the battery from the charger may ignite the dust or fumes.
If battery contents come into contact with the skin, immediately wash area with mild soap and
water. If battery liquid gets into the eye, rinse water over the open eye for 15 minutes or until irritation
ceases. If medical attention is needed, the battery electrolyte for Lithium-Ion batteries is composed of a
mixture of liquid organic carbonates and lithium salts.
Contents of opened battery cells may cause respiratory irritation. Provide fresh air. If symptoms
persist, seek medical attention.
WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark or flame.
Charge the battery packs only in Chapin chargers.
DO NOT splash or immerse in water or other liquids. This may cause premature cell failure.
Do not store or use the tool and battery pack in locations where the temperature may reach or
exceed 105ºF (40ºC) (such as outside sheds or metal buildings in summer).
WARNING: Never attempt to open the battery pack for any reason. If battery pack case is cracked or damaged, do not
insert into charger. Do not crush, drop or damage battery pack. Do not use a battery pack or charger that has received
a sharp blow, been dropped, run over or damaged in any way (i.e., pierced with a nail, hit with a hammer, stepped on).
Damaged battery packs should be returned to service center for recycling.
WARNING: Fire hazard. Do not store or carry battery so that metal objects can contact exposed battery terminals.
For example, do not place battery in aprons, pockets, tool boxes, product kit boxes, drawers, etc., with loose nails,
screws, keys, etc.
Transporting batteries can possibly cause fires if the battery terminals inadvertently come in contact with
conductive materials such as keys, coins, hand tools and the like. The US Department of transportation Hazardous
Material Regulations (HMR) actually prohibit transporting batteries in commerce or on airplanes (i.e., packed in
suitcases and carry-on luggage) UNLESS they are properly protected from short circuits. So when transporting
individual batteries, make sure that the battery terminals are protected and well insulated from materials that could
contact them and cause a short circuit. NOTE: Lithium-Ion batteries should not be put in checked baggage.
