Americas Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Hardware Installation Guide for Cisco UCS
E-Series Servers
First Published: October 19, 2012
Updated: October 19, 2012
This document provides information that you should know before and during installation of
Cisco UCS E-Series Servers in Cisco Integrated Services Routers (ISR G2), and contains the following
sections:
• Cisco UCS E-Series Servers Overview, page 1
• Recommended Practices for Cisco UCS E-Series Servers, page 11
• Installing E-Series Servers in Cisco ISR G2 Routers, page 15
• Where to Go Next, page 33
Cisco UCS E-Series Servers Overview
The Cisco UCS E-Series Servers (E-Series Servers) are the next generation of
Cisco UCS Express servers. E-Series Servers are a family of size, weight, and power efficient blade
servers that are housed within Generation 2 Cisco Integrated Services Routers (ISR G2). These servers
provide a general purpose compute platform for branch-office applications deployed either as bare-metal
on operating systems, such as Microsoft Windows or Linux; or as virtual machines on hypervisors, such
as VMware vSphere Hypervisor
TM
, Microsoft Hyper-V, or Citrix XenServer.
Hardware Installation Guide for Cisco UCS E-Series Servers
Hardware Requirements
2
Cisco UCS E-Series Server Modules Hardware Installation Guide
OL-26447-01
Hardware Requirements
E-Series Servers reside in the Cisco 2900 series or 3900 series ISR G2. The following E-Series Servers
are supported:
• UCS-E140S—Single-wide E-Series Server
• UCS-E140D—Double-wide E-Series Server, 4 core CPU
• UCS-E160D—Double-wide E-Series Server, 6 core CPU
• UCS-E140DP—Double-wide E-Series Server, 4 core CPU, with PCIe
• UCS-E160DP—Double-wide E-Series Server, 6 core CPU, with PCIe
Table 1 provides hardware information about E-Series Servers.
Table 1 E-Series Server Hardware at a Glance
Feature
UCS-E140S
Single-Wide E-Series Server)
UCS-E140D and UCS-E160D
Double-Wide E-Series Servers
UCS-E140DP and UCS-E160DP
Double-Wide E-Series Servers
with PCIe
Form Factor Single-wide SM Double-wide SM Double-wide SM
CPU Intel Xeon
TM
E3-1105C
Intel Xeon
TM
E5-2428L and E5-2418L
Intel Xeon
TM
E5-2428L and E5-2418L
CPU Cores 4 Core 4 Core and 6 Core 4 Core and 6 Core
DIMM Slots 2 Slots 3 Slots 3 Slots
RAM 8 GB - 16 GB
Supports DDR3 1333MHz VLP
UDIMM 1.5 V, 4 GB, and 8 GB
8 GB - 48 GB
Supports DDR3 1333 MHz
RDIMM 1.35 V, 4 GB, 8 GB and
16 GB
8 GB - 48 GB
Supports DDR3 1333 MHz
RDIMM 1.35 V, 4 GB, 8 GB, and
16 GB
RAID RAID 0 and RAID 1 RAID 0, RAID 1, and RAID 5 RAID 0 and RAID 1
Storage Type SATA, SAS, SSD, and SED SATA, SAS, SSD, and SED SATA, SAS, SSD, and SED
HDD SAS 10K RPM, SATA 7200
RPM, and SAS SSD Drives
1
Supports 2 Drives
SAS 10K RPM, SATA 7200 RPM,
and SAS SSD Drives
1
Supports 3 Drives
SAS 10K RPM, SATA 7200
RPM, and SAS SSD Drives
1
Supports 2 Drives
Storage Capacity 200 GB - 2 TB 200 GB - 3 TB 200 GB - 2 TB
Internal Network
Interface
2 Gigabit Ethernet Interfaces 2 Gigabit Ethernet Interfaces 2 Gigabit Ethernet Interfaces
External
Interfaces
1 USB Connector
1 RJ-45 Gigabit Ethernet
Connector
1 Management Port
1 KVM Port (Supports VGA,
1 USB, 1 Serial DB9)
2 USB Connectors
2 RJ-45 Gigabit Ethernet
Connectors
1 Management Port
1 VGA Port
1 Serial DB9
2 USB Connectors
2 RJ-45 Gigabit Ethernet
Connectors
1 Management Port
1 VGA Port
1 Serial DB9
