Side 1/64

WEB: corsair.com

PHONE: (888) 222-4346

SUPPORT: support.corsair.com

BLOG: corsair.com/blog

FORUM: forum.corsair.com

YOUTUBE: youtube.com/corsairhowto

are registered trademarks in the United States and/or other countries. All other

trademarks are the property of their respective owners. Product may vary slightly

from those pictured. 49-002065 AA

CORSAIR MEMORY, BV | Wormerweg 8, 1311 XB, Almere, Netherlands

CX-F RGB SERIES

RGB ATX Power Supply

CX550F CX650F CX750F

CX-F RGB SERIES

ENGLISH ....................................................... 1

FRANÇAIS ................................................... 12

DEUTSCH ................................................... 22

NEDERLANDS ............................................ 32

ITALIANO ..................................................... 42

ESPAÑOL .................................................... 52

PORTUGUÊS .............................................. 62

POLSKI ........................................................ 72

PУССКИЙ ..................................................... 82

ةيبرعلا ............................................................. 92

简体中文 .................................................... 102

繁體中文 ................................................... 112

1 2

ENGLISH ENGLISH

TABLE OF CONTENTS

SAFETY AND PROTECTION

INTRODUCTION

CX750F RGB .............................................................................................................................................................3

CX650F RGB .............................................................................................................................................................5

CX550F RGB .............................................................................................................................................................7

Installation .................................................................................................................................................................9

RGB setup and control ............................................................................................................................................ 10

Congratulations on the purchase of your new CORSAIR CX-F RGB Series ATX Power Supply!

CORSAIR CX-F RGB Series fully modular power supplies deliver reliable 80 PLUS Bronze efﬁcient power to your

system, alongside vibrant customizable lighting from a 120mm RGB fan boasting eight RGB LEDs. Easily cycle

through seven preset lighting modes, or connect to a CORSAIR iCUE RGB Lighting Controller or compatible

motherboard to unlock advanced lighting control over eight individually addressable LEDs.

> Over-voltage protection (OVP)

Over-voltage protection for the 12V, 5V, and 3.3V DC outputs is required to comply with the ATX

speciﬁcation. OVP shuts down the PSU in the event that the DC outputs exceed a set level,

determined by the PSU manufacturer.

> Over-current protection (OCP)

The CX-F RGB Series features OCP on the 3.3V, 5V, and 12V rails. OCP ensures that the output of the

DC voltage rails remains within safe operating limits.

> Over-temperature protection (OTP)

OTP ensures that the PSU will shut down when the internal temperature reaches a set point. This is

usually as a result of internal current overloading or a fan failure.

> Short-circuit protection (SCP)

A short-circuit is deﬁned as any output impedance of less than 0.1 ohms. Amongst other things, SCP

ensures that the PSU shuts down should the 3.3V, 5V, and 12V rails short to any other rail, or to

ground. It also ensures that no damage should occur to the unit, or your PC’s components in the

event of a short.

Produkspesifikasjoner

Merke:	Corsair
Kategori:	dataadapter
Modell:	CX650F
Bredde:	150 mm
Dybde:	140 mm
Høyde:	86 mm
Støynivå:	- dB
80 PLUS-sertifisering:	80 PLUS Bronze
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	47 - 63 Hz
Kabeltype:	Fullt modulær
Produktfarge:	Sort
Harmonisert system (HS)-kode:	84733020
ATX-versjon:	2.4
ATX strømtilkobling (24-pin):	Ja
Form for nedkjøling:	Aktiv
Gjennomsnittstid mellom feil (MTBF):	100000 timer
Formål:	PC
Viftediameter:	120 mm
Total strøm:	650 W
Innput-strøm:	10 - 5 A
EPS strømtilkobling (8-pin):	Ja
Strømkontakt for hovedkort:	24-pin ATX
Antall SATA-strømtilkoblinger:	1
Antall PATA-strømtilkoblinger:	1
PCI Express-strømtilkobling (8-pin):	2
PCI Express-tilkobling:	Ja
Strømforsyningsenhetens formfaktor:	ATX
