Side 1/62

SF SERIES

™

HIGH PERFORMANCE SFX POWER SUPPLY

MANUAL • MANUEL • MANUALE • MANUELLE • MANUAL DE

РУКОВОДСТВО • MANUAL • MANUELL • 用户手册 • 取扱説明書

SF600

SF450

SF750

SF SERIES

™

WEB: corsair.com

PHONE: (888) 222-4346

SUPPORT: support.corsair.com

BLOG: corsair.com/blog

FORUM: forum.corsair.com

YOUTUBE: youtube.com/corsairhowto

CORSAIR and the sails logo are registered trademarks in the United States

and/or other countries. All other trademarks are the property of their respective

owners. Product may vary slightly from those pictured. 49-001769 AA

English 1

Français 13

Deutsch 25

Italiano 37

Español 49

Россию 61

Português 73

Svenska 85

中文 97

日本語 109

1 2

SF SERIES

™

SF SERIES

™

PRODUCT SPECIFICATIONS

SF .................................................... 

SF .................................................... 

SF .................................................... 

Installation ........................................... 

ImportantSafetyInformation ......... 

Congratulations on the purchase of your

new CORSAIR Series High Performance

SFX power supply.

SF Series power supplies give you 80 PLUS Platinum eciency,

excellent electrical performance, and virtually silent operation in a SFX

form factor. With 105°C Japanese capacitors and Zero RPM fan mode,

they’re a great choice for high performance small form factor PC’s

where reliability and low noise are essential.

Safety and protection

• Over-voltage protection (OVP)

Over-voltage protection for the 12V, 5V and 3.3V DC outputs is

required to comply with the SFX speciﬁcation. OVP shuts down the

PSU in the event that the DC outputs exceed a set level, determined

by the PSU manufacturer. The minimum voltage levels required for

compliance are 13.4V for the +12V rail(s), 5.74V for the +5V rail and

3.76V for the 3.3V rail.

• Over-current protection (OCP)

The SF Series features OCP on the 3.3V, 5V and 12V rails. OCP

ensures that the output of the DC voltage rails remains within

safe operating limits.

• Over-temperature protection (OTP)

OTP ensures that the PSU will shut down when the internal

temperature reaches a set point. This is usually as a result of

internal current overloading or a fan failure.

• Short-circuit protection (SCP)

A short-circuit is deﬁned as any output impedance of less than

0.1 ohms. Amongst other things, SCP ensures that the PSU shuts

down should the 3.3V, 5V and 12V rails short to any other rail, or to

ground. It also ensures that no damage should occur to the unit, or

your PC’s components in the event of a short.

Produkspesifikasjoner

Merke:	Corsair
Kategori:	dataadapter
Modell:	Sf600
Vekt:	860 g
80 PLUS-sertifisering:	80 PLUS Platinum
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	47 - 63 Hz
Kabeltype:	Fullt modulær
EPS-versjon:	2.92
Kabler inkludert:	AC, DC
Strømbeskyttelsesfunksjoner:	Over power, Over voltage, Overheating, Short circuit, Under voltage
Av/på-bryter:	Ja
ATX-versjon:	2.4
Støttet systemdisk formfaktorer:	ATX
ATX strømtilkobling (24-pin):	Ja
Form for nedkjøling:	Aktiv
Formål:	PC
Viftediameter:	92 mm
Total strøm:	600 W
Antall vifter:	1 vifter
Strømkontakt for hovedkort:	24-pin ATX
Antall SATA-strømtilkoblinger:	4
PCI Express-tilkobling:	Ja
Strømforsyningsenhetens formfaktor:	SFX
Vifteposisjon:	Topp
Perifere (Molex) strømkontakter (4-pin):	4
PCI Express-strømtilkobling (6+2-pin):	2
Stillemodus:	Ja
Bæreteknologi:	Riller
Hovedkort strømkabellengde:	300 mm
SATA kraftledning lengde:	450 mm
Peripheral (Molex) strømkabellengde:	330 mm
EPS strømkontakt (4+4-pin):	Ja
PCI Express-strømforsyning kabellengde:	400 mm
