Side 1/10
© 2016 Corsair Components, Inc. All rights reserved. Corsair and the sails logo are registered trademarks, and Professional Series is a trademark in the United States
and/or other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured. Document Number: 49-001273 rev AB
47100 Bayside Parkway • Fremont • California • 94538 • USA
USA and CANADA: (510) 657-8747 INTERNATIONAL: 1-888-222-4346 | FAX: (510) 657-8748
corsair.com
FORUM: forum.corsair.com
TWITTER: twitter.com/corsairmemory
PSU PAGE: corsair.com/powersupplyunits
EMAIL: support@corsair.com
FACEBOOK: facebook.com/corsair
BLOG: blog.corsair.com
HIGH PERFORMANCE ATX POWER SUPPLY
MANUAL
TX750M
TX650M
TX550M
TX850M
TXM SERIES
™
TXM SERIES
™
7
corsair.com corsair.com
1 2
TXM SERIES
™
TXM SERIES
™
Product Specifications
TXM ..........................
TXM ..........................
TXM ..........................
TXM ..........................
Installation ..................
SafetyandAgency
Approvals ....................
Warranty .....................
Congratulations on the purchase of your new Corsair
TXM Series High Performance ATX power supply.
Corsair TXM Series enthusiast power supplies are optimized for silence,
with a custom fan design. 80 PLUS Gold rated eciency ensures
low-cost operation, and the modular black cables allow for fast,
neat builds. All Japanese 105°C capacitors make it a great choice for
high performance PCs where reliability is essential.
Safety and protection
• Over-voltage protection (OVP)
Over-voltage protection for the 12V, 5V and 3.3V DC outputs
is required to comply with the ATX specification. OVP shuts
down the PSU in the event that the DC outputs exceed
a set level, determined by the PSU manufacturer. The minimum
voltage levels required for compliance are 13.4V for the
+12V rail(s), 5.74V for the +5V rail and 3.76V for the 3.3V rail.
• Over-current protection (OCP)
The TXM Series features OCP on the 3.3V, 5V and 12V rails.
OCP ensures that the output of the DC voltage rails remains
within safe operating limits.
• Over-temperature protection (OTP)
OTP ensures that the PSU will shut down when the internal
temperature reaches a set point. This is usually as a result
of internal current overloading or a fan failure.
• Short-circuit protection (SCP)
A short-circuit is defined as any output impedance of less than 0.1
ohms. Amongst other things, SCP ensures that the PSU shuts down
should the 3.3V, 5V and 12V rails short to any other rail,
or to ground. It also ensures that no damage should occur to
the unit, or your PC’s components in the event of a short.
Produkspesifikasjoner
| Merke: | Corsair |
| Kategori: | dataadapter |
| Modell: | TX750M |
| Vekt: | 1780 g |
| Bredde: | 150 mm |
| Dybde: | 160 mm |
| Høyde: | 86 mm |
| Støynivå: | - dB |
| Bruksanvisning: | Ja |
| Garantikort: | Ja |
| Sertifisering: | FCC, ICES, CE, UL, cUL, RCM, TÜV, CB, CCC, BSMI, EAC, WEEE, KC |
| 80 PLUS-sertifisering: | 80 PLUS Gold |
| AC-inngangsspenning: | 100 - 240 V |
| AC-inngangsfrekvens: | 47 - 63 Hz |
| Viftehastighet: | 1212 RPM |
| Kombinert strøm (+12V): | 744 W |
| Kombinert strøm (+5V): | 130 W |
| Kombinert strøm (-12V): | 9.6 W |
| Kabeltype: | Semi-Modulær |
| EPS-versjon: | 2.92 |
| Produktfarge: | Sort |
| Pakketype: | Boks |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Bærekraftsertifikater: | RoHS |
| Strømbeskyttelsesfunksjoner: | Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Av/på-bryter: | Ja |
| Maksimal utgangsstrøm (+12V): | 62 A |
| ATX-versjon: | 2.4 |
| Diskettstasjonstilkobling: | Ja |
| Form for nedkjøling: | Aktiv |
| Gjennomsnittstid mellom feil (MTBF): | 100000 timer |
| Formål: | PC |
| Viftediameter: | 140 mm |
| Total strøm: | 750 W |
| Antall vifter: | 1 vifter |
| Innput-strøm: | 12 A |
| EPS strømtilkobling (8-pin): | Ja |
| Strømkontakt for hovedkort: | 20+4 pin ATX |
| Antall SATA-strømtilkoblinger: | 8 |
| PCI Express-tilkobling: | Ja |
| Strømforsyningsenhetens formfaktor: | ATX |
| Kombinert strøm (+3.3V): | 130 W |
| Kombinert strøm (+5Vsb): | 15 W |
| Max output current (+3.3V): | 25 A |
| Max output current (+5V): | 25 A |
| Max output current (-12V): | 0.8 A |
| Max output current (+5Vsb): | 3 A |
| Vifteposisjon: | Topp |
| Perifere (Molex) strømkontakter (4-pin): | 7 |
| Strømfaktor: | 0.99 |
| Power Factor Correction (PFC) type: | Aktiv |
| PCI Express-strømtilkobling (6+2-pin): | 4 |
| Strømkontakt til diskettstasjon: | 1 |
| Bæreteknologi: | Riller |
| Hovedkort strømkabellengde: | 610 mm |
| SATA kraftledning lengde: | 500,600,800 mm |
| Peripheral (Molex) strømkabellengde: | 450,550,650,750 mm |
| PCI Express-strømforsyning kabellengde: | 600 mm |
| Holdtid: | 16 ms |
| Farge etui: | Sort |
| Støy nivå (stille modus, <30%): | 6 dB |
| Støy nivå (rolig modus, 50%): | 21.9 dB |
| Støy nivå (full-last modus, 100%): | 30.4 dB |
| Diskettstasjon kabellengde: | 101 mm |
