FEATURES
USER MANUAL
REAL GEAR FOR REAL GAMERSREAL GEAR FOR REAL GAMERS
www.cougargaming.com
●
18 RGB-LEDS PRO LÜFTER +
TRIDIREKTIONALES BELEUCHTUNGSDESIGN
●
CORE BOX C UNTERSTÜTZEN
5-V-RGB-VERBINDUNG MIT
KOMPATIBLEN MOTHERBOARDS
●
PATENTIERTES COUGAR-LÜFTERDESIGN,
DAS DEN LUFTSTROM OPTIMIERT
DEUTSCH FRANÇAIS
●
18 LED RVB PAR VENTILATEUR + ÉCLAIRAGE
À CONCEPTION TRIDIRECTIONNELLE
●
CORE BOX C RACCORDEMENT RVB 5V SUR
LES CARTES MÈRES COMPATIBLES
●
VENTILATEUR À CONCEPTION COUGAR
BREVETÉE QUI OPTIMISE LE FLUX D'AIR
●
18 RGB-ÑÂÅÒÎÄÈÎÄÎÂ Â ÊÀÆÄÎÌ
ÂÅÍÒÈËßÒÎÐÅ + ÒÐÅÕÑÒÎÐÎÍÍÈÉ
ÄÈÇÀÉÍ ÏÎÄÑÂÅÒÊÈ
●
CORE BOX C ÏÎÄÄÅÐÆÈÂÀÅÒ 5V
ÏÎÄÊËÞ×ÅÍÈÅ RGB Ê ÑÎÂÌÅÑÒÈÌÛÌ
ÌÀÒÅÐÈÍÑÊÈÌ ÏËÀÒÀÌ
●
ÇÀÏÀÒÅÍÒÎÂÀÍÍÛÉ ÄÈÇÀÉÍ
ÂÅÍÒÈËßÒÎÐÎÂ COUGAR Ñ ÎÏÒÈÌÈÇÀÖÈÅÉ
ÂÎÇÄÓØÍÛÕ ÏÎÒÎÊÎÂ
РУССКИЙ
POLISH
●
18 DIOD RGB NA WENTYLATOR +
OŚWIETLENIE TRÓJKIERUNKOWE
●
CORE BOX C OBSŁUGUJĄ POŁĄCZENIE 5V
RGB W KOMPATYBILNYCH PŁYTACH
GŁÓWNYCH
●
OPATENTOWANA KONSTRUKCJA
WENTYLATORA COUGAR ZAPEWNIAJĄCA
OPTYMALIZACJĘ PRZEPŁYWU POWIETRZA
HUNGARIAN
●
18 RGB LED-LÁMPA MINDEN
VENTILÁTORHOZ + HÁROMIRÁNYÚ
VILÁGÍTÁS
●
CORE BOX C TÁMOGATJÁK AZ 5 V-OS
RGB-CSATLAKOZÁST A
KOMPATIBILIS ALAPLAPOKKAL
●
SZABADALMAZTATOTT COUGAR
VENTILÁTORRAL TÖRTÉNŐ KIALAKÍTÁS,
AMELY OPTIMALIZÁLJA A LÉGÁRAMLATOT
●
18 LED RGB PER OGNI VENTOLA
+ DESIGN LUMINOSO
TRIDIREZIONALE
●
CORE BOX C SUPPORTANO LA
CONNESSIONE RGB 5V SULLE SCHEDE
MADRI COMPATIBILI
●
SISTEMA BREVETTATO COUGAR PER
UN
FLUSSO D'ARIA OTTIMIZZATO
ITALIANO
한국어
●
팬당 18 개의 RGB LED + 3 방향
조명
디자인
●
호환 마더 보드에 5V RGB 연결을
지원하는
CORE BOX C
●
공기 흐름을 최적화하는
특허받은 COUGAR 팬 디자인
中 文
●
每个风扇有18颗RGB LED灯+ 3向
背光设计
●
CORE BOX C 支援5V RGB 连接
相容主机板
●
COUGAR风扇专利设计有效优化
气流运行效果
●
18 LEDS RGB POR VENTILADOR + DESIGN
DE ILUMINAÇÃO TRI-DIRECIONAL
●
SUPORTE CORE BOX C
5V RGB CONEXÃO A PLACAS MÃE
COMPATÍVEIS
●
DESIGN DE VENTILADOR COUGAR
PATENTEADO QUE OTIMIZA O FLUXO DE AR
PORTUGUÊS
日本語
●
ファンは18 個のRGB LED搭載＋
3パターンのライティング効果
●
CORE BOX C 互換性の
あるマザーボードの5V RGBコネクタとの接続
により、連動してのライティングが可能
●
エアーフローを最適化する特許取得済みの
COUGARファン設計
ENGLISH
●
18 RGB LEDS PER FAN + TRI-DIRECTIONAL
LIGHTING DESIGN
●
CORE BOX C SUPPORT 5V
ADDRESSABLE HEADER TO COMPATIBLE
MOTHERBOARDS
●
PATENTED COUGAR FAN DESIGN THAT
OPTIMIZES AIRFLOW
●
18 LEDS RGB EN CADA VENTILADOR +
DISEÑO DE ILUMINACIÓN TRIDIRECCIONAL
●
CORE BOX C SOPORTA CONEXIÓN A PUERTOS
RGB DE 5V EN PLACAS MADRE COMPATIBLES
●
VENTILADORES CON DISEÑO PATENTADO
QUE OPTIMIZA EL FLUJO DE AIRE
ESPAÑOL
CONTENTS
INSTALLATION
The included COUGAR Core Box C, which supports up to 8 fans and 4 RGB LED strips,
allows you directly control its 14 preset lighting effects with an included switch or with
your case's reset button. You can also connect it to compatible motherboards' 5V RGB
header for system-wide synchronization!
PRESET LIGHTING EFFECTS + MOTHERBOARD SYNCHRONIZATION
VORTEX RGB FCB120 x 3
FANS LED
FANSLED
Core Box C
Power Connector
VORTEX RGB
FCB120
RGB LED Strip
(Optional)
2
TRI-DIRECTIONAL LIGHTING
In, Front, Out. The VORTEX RGB FCB 120 fans’18 LEDs produce a visual spectacle in
three directions. While most other backlit fans project their light only inward and
forward, VORTEX RGB FCB 120 gives you a 180º viewing angle, covering all the area
visible from outside your PC case.
5V Addressable Header Adapter
VDG
5V Addressable
Header Adapter
Core Box C
Power Connector
Power Supply
1
POWER M-INC-SW
VDG
for Compatible
Gigabyte
Motherboards
for Compatible
Asus or MSI
Motherboards
Core Box C for up to 8 fans and 4 LED strips, with 3 VORTEX RGB FCB 120 Fans included.
Connect the COUGAR Core Box C directly to the 5V RGB connectors of compatible
ASUS, MSI or GIGABYTE motherboards for system-wide synchronization and full
customization.
* Please note : Only 5V addressable header from compatible motherboards are supported;
please do not connect the COUGAR Core Box C to a 12V Non-addressable header.
SUPPORT FOR DIRECT MOTHERBOARD CONNECTION
Core Box C for up to 8 fans and 4 LED strips, with 3 VORTEX RGB FCB 120 Fans included.
The electrical consumption of a fully installed COUGAR Core Box C with 8 COUGAR
VORTEX RGB fans and 4 COUGAR RGB LED strips is 40W (5V); please take this into
account when choosing your power supply and designing your build.
Lighting Switch Cable
Core Box C Lighting Switch (Included)
OR Your Case's Reset Button Cable
(if Available)
LET IT SHINE!
FCB 12 0
COOLING KIT
VORTEX
