Cougar Vortex RGB HPB 120 Bruksanvisning

Cougar datakjølekomponent Vortex RGB HPB 120

Les nedenfor 📖 manual på norsk for Cougar Vortex RGB HPB 120 (2 sider) i kategorien datakjølekomponent. Denne guiden var nyttig for 10 personer og ble vurdert med 4.4 stjerner i gjennomsnitt av 5.5 brukere

Last ned PDF

Side 1/2

FEATURES

USER MANUAL

REAL GEAR FOR REAL GAMERSREAL GEAR FOR REAL GAMERS

www.cougargaming.com

●

18 RGB-LEDS PRO LÜFTER +

TRIDIREKTIONALES BELEUCHTUNGSDESIGN

●

VORTEX-RGB-LÜFTER UNTERSTÜTZEN

5-V-RGB-VERBINDUNG MIT KOMPATIBLEN

MOTHERBOARDS

●

100 BELEUCHTUNGSEFFEKTE MIT

KABELLOSER STEUERUNG

●

PATENTIERTES COUGAR-LÜFTERDESIGN,

DAS DEN LUFTSTROM OPTIMIERT

DEUTSCH

●

18 RGB-ÑÂÅÒÎÄÈÎÄÎÂ Â ÊÀÆÄÎÌ

ÂÅÍÒÈËßÒÎÐÅ + ÒÐÅÕÑÒÎÐÎÍÍÈÉ

ÄÈÇÀÉÍ ÏÎÄÑÂÅÒÊÈ

●

VORTEX RGB ÂÅÍÒÈËßÒÎÐ

ÏÎÄÄÅÐÆÈÂÀÅÒ 5V ÏÎÄÊËÞ×ÅÍÈÅ RGB

Ê ÑÎÂÌÅÑÒÈÌÛÌ ÌÀÒÅÐÈÍÑÊÈÌ ÏËÀÒÀÌ

●

100 ÝÔÔÅÊÒÎÂ ÏÎÄÑÂÅÒÊÈ Ñ

ÁÅÑÏÐÎÂÎÄÍÛÌ ÓÏÐÀÂËÅÍÈÅÌ

●

ÇÀÏÀÒÅÍÒÎÂÀÍÍÛÉ ÄÈÇÀÉÍ

ÂÅÍÒÈËßÒÎÐÎÂ COUGAR Ñ ÎÏÒÈÌÈÇÀÖÈÅÉ

ÂÎÇÄÓØÍÛÕ ÏÎÒÎÊÎÂ

РУССКИЙ

FRANÇAIS

●

18 LED RVB PAR VENTILATEUR + ÉCLAIRAGE

À CONCEPTION TRIDIRECTIONNELLE

●

LES VENTILATEURS RVB VORTEX PRENNENT

EN CHARGE UN RACCORDEMENT RVB 5 V

SUR LES CARTES MÈRES COMPATIBLES

●

100 EFFETS LUMINEUX AVEC COMMANDE

SANS FIL

●

VENTILATEUR À CONCEPTION COUGAR

BREVETÉE QUI OPTIMISE LE FLUX D'AIR

HUNGARIAN

●

18 RGB LED-LÁMPA MINDEN

VENTILÁTORHOZ + HÁROMIRÁNYÚ

VILÁGÍTÁS

●

A VORTEX RGB VENTILÁTOROK TÁMOGATJÁK

AZ 5 V-OS RGB-CSATLAKOZÁST A

KOMPATIBILIS ALAPLAPOKKAL

●

100 FÉNYEFFEKTUS VEZETÉK NÉLKÜLI

VEZÉRLŐVEL

●

SZABADALMAZTATOTT COUGAR

VENTILÁTORRAL TÖRTÉNŐ KIALAKÍTÁS,

AMELY OPTIMALIZÁLJA A LÉGÁRAMLATOT

POLISH

●

18 DIOD RGB NA WENTYLATOR +

OŚWIETLENIE TRÓJKIERUNKOWE

●

WIROWE WENTYLATORY RGB OBSŁUGUJĄ

POŁĄCZENIE 5V RGB W KOMPATYBILNYCH

PŁYTACH GŁÓWNYCH

●

100 EFEKTÓW OŚWIETLENIA DZIĘKI

BEZPRZEWODOWEMU STEROWANIU

●

OPATENTOWANA KONSTRUKCJA

WENTYLATORA COUGAR ZAPEWNIAJĄCA

OPTYMALIZACJĘ PRZEPŁYWU POWIETRZA

●

18 LED RGB PER OGNI VENTOLA

+ DESIGN LUMINOSO

TRIDIREZIONALE

●

LE VENTOLE VORTEX RGB SUPPORTANO

LA CONNESSIONE RGB 5V SULLE SCHEDE

MADRI COMPATIBILI

●

100 EFFETTI LUMINOSI AZIONABILI

DAL

CONTROLLER WIRELESS

●

SISTEMA BREVETTATO COUGAR PER

FLUSSO D'ARIA OTTIMIZZATO

ITALIANO

中文

●

每个风扇有18颗RGB LED灯+ 3向

背光设计

●

Vortex RGB风扇支援5V RGB 连接

相容主机板

●

使用无线控制器可变换100种背光

效果

●

COUGAR风扇专利设计有效优化

气流运行效果

한국어

●

팬당 18 개의 RGB LED + 3 방향

조명

디자인

●

호환 마더 보드에 5V RGB 연결을

지원하는 Vortex RGB 팬

●

무선 제어를 통한 100 가지 조명 효과

●

공기 흐름을 최적화하는

특허받은 COUGAR 팬 디자인

ENGLISH

●

18 RGB LEDS PER FAN + TRI-DIRECTIONAL

LIGHTING DESIGN

●

VORTEX RGB FANS SUPPORT 5V

ADDRESSABLE HEADER TO COMPATIBLE

MOTHERBOARDS

●

100 LIGHTING EFFECTS WITH WIRELESS

CONTROL

●

PATENTED COUGAR FAN DESIGN THAT

OPTIMIZES AIRFLOW

●

18 LEDS RGB POR VENTILADOR + DESIGN

DE ILUMINAÇÃO TRI-DIRECIONAL

●

SUPORTE A VENTILADORES RGB VORTEX

5V RGB CONEXÃO A PLACAS MÃE

COMPATÍVEIS

●

100 EFEITOS DE ILUMINAÇÃO COM

CONTROLE WIRELESS

●

DESIGN DE VENTILADOR COUGAR

PATENTEADO QUE OTIMIZA O FLUXO DE AR

PORTUGUÊS

日本語

●

ファンは18 個のRGB LED搭載＋

3パターンのライティング効果

●

Vortex RGBファンは互換性の

あるマザーボードの5V RGBコネクタとの接続

により、連動してのライティングが可能

●

ワイヤレスコントローラによって100種類の

RGB カラーを変更することが可能

●

エアーフローを最適化する特許取得済みの

COUGARファン設計

●

18 LEDS RGB EN CADA VENTILADOR +

DISEÑO DE ILUMINACIÓN TRIDIRECCIONAL

●

SOPORTA CONEXIÓN A PUERTOS RGB DE

5V EN PLACAS MADRE COMPATIBLES

●

EFECTOS DE ILUMINACIÓN CON CONTROL

INALÁMBRICO

●

VENTILADORES CON DISEÑO PATENTADO

QUE OPTIMIZA EL FLUJO DE AIRE

ESPAÑOL

CONTENTS

INSTALLATION

FANS LED

FANSLED

Use the included wireless controller to choose among 100 amazing lighting effects,

all without installing any software!

100 LIGHTING EFFECTS WITH WIRELESS DRIVER-FREE CONTROL

PWM MAXIMIZE COOLING, MINIMIZE NOISE

An included adapter allows you to connect the fans directly to the 5V addressable

header of compatible ASUS or MSI motherboards.

* Please note : Only 5V addressable header from compatible motherboards are

supported; please do not connect the fan to a 12V Non-addressable header.

FAN SUPPORT FOR 5V ADDRESSABLE HEADER

VORTEX RGB HPB120 x 3

5V Addressable Header Adapter x 34 to 4 Pin Adapter x 3

Wireless

Controller

RGB Core Box

RGB Core Box Magnet

POWER

Power Connector

Power Supply

Motherboard

PWM header

VORTEX RGB

HPB120

RGB LED Strip

(Optional)

RGB Core Box for up to 8 fans and 4 LED strips, with 3 VORTEX RGB HPB120 Fans included.

The electrical consumption of a fully installed COUGAR Core Box with 8 COUGAR

VORTEX RGB fans and 4 COUGAR RGB lighting strips is 40W; please take this into

account when choosing your power supply and designing your build.

The electrical consumption

of a fully installed COUGAR

Core Box with 8 COUGAR

Vortex RGB fans and 4

COUGAR RGB lighting strips

is 40W; please take this into

account when choosing your

power supply and designing

your build.

The Pulse-width Modulation technology allows the motherboard to control the fans

through 4-pin connectors and optimize their speed (in a range that goes from 800

to 1500 RMP) while keeping a 12V operating voltage.

Produkspesifikasjoner

Merke:	Cougar
Kategori:	datakjølekomponent
Modell:	Vortex RGB HPB 120
Bredde:	120 mm
Dybde:	25 mm
Høyde:	120 mm
Luftstrøm:	73.94 m³/t
Maksimal luftstrøm:	43.54 cfm
Rotasjonshastighet (min):	600 RPM
Egnet plassering:	PC-kjølevifte
Maksimalt lufttrykk:	1.17 mmH2O
Kabellengde:	0.6 m
Produktfarge:	Sort
Pakketype:	Boks
Modell/Type:	Kjøler
Skruer inkludert:	Ja
Belysningsfarge:	Multi
Viftetilkobling:	4-pin
Viftediameter:	120 mm
Støynivå (høy hastighet):	26 dB
Antall vifter:	1 vifter
Belysningsdiode:	Ja
Rotasjonshasrighet (max):	1500 RPM
Antall LED's:	18
Pulsbreddemodulerings- støtte (PWM):	Ja
LED-spenning:	5 V
Vifte nominell spenning:	12 V
