CLW-SLVU-P

Cameo

In-Wall Remote Dimmer, 120V

crestron.com

800.237.2041

>Replaces traditional 3- or 4-way dimmers and switches

>Matches the popular Cameo

style

>Provides control to the connected dimmer or switch

(CLW-DIMEX-P, CLW-SWEX-P, and CLW-DELVEX-P)

[1, 2]

>Field-replaceable button caps

>Customizable button engraving

[3]

>Configurable with rocker or 2 large button caps

>Available in all designer colors

The CLW-SLVU-P is a Cameo

in-wall remote dimmer that provides control

to Crestron

Cameo

dimmers and switches.

[1]

Available in designer colors

and configurable with 2 buttons or in a rocker layout, the CLW-SLVU-P

uses a "universal" design, capable of controlling CLW-DIMEX-P,

CLW-SWEX-P, and CLW-DELVEX-P dimmers and switches.

Multipoint Dimming and Switching

Similar to traditional 3- or 4-way circuits, the CLW-SLVU-P lets you control

the lights from multiple locations using the “traveler” wire.

[1]

The remote

dimmer does not need to be programmed, providing instant usability upon

installation. Up to 9 CLW-SLVU-Ps can be connected to a single Cameo

dimmer.

Field-Replaceable Button Caps

Like Cameo dimmers and switches, the button caps on the CLW-SLVU-P can

be swapped in the field, making it easy to change engraving or color after

installation. Use the rocker button cap or the two large button caps to match

the look of the connected dimmer or switch.

SPECIFICATIONS

Power Requirements

Line Power: 120 Volts AC, 50//60Hz

Buttons & Indicators

Buttons: Configurable with (1) rocker or (2) large button caps to control the

connected dimmer or switch

[1]

LED Feedback: (1) White LED light pipe pinhole displays status (on/off) of

the connected dimmer or switch

Connections

Line: (1) Captive screw terminal, black, line power input

Neutral: (1) Captive screw terminal, white, line power input

Remote: (1) Captive screw terminal, blue, remote control to CLW-DIMEX-P,

CLW-SWEX-P, and CLW-DELVEX-P

Ground: (1) Captive screw terminal, green, ground

Environmental

Temperature: 32° to 104° F (0° to 40° C)

Humidity: 10% to 90% RH (non-condensing)

Construction

Keypad: Plastic; textured or smooth

Faceplate: Requires a decorator-style faceplate (FP-G Series

[1]

)

Mounting: Mounts in a 1-gang (or larger) 3-1/2 inch (89 mm) deep

electrical box (not included), gangable

Dimensions

Height: 4.13 in (105 mm)

Width: 1.75 in (45 mm)

Depth: 1.75 in (45 mm)

Note: Dimensions shown are without a faceplate.

Weight

5 oz (142 g)

CLW-SLVU-P Cameo

In-Wall Remote Dimmer, 120V

Crestron Electronics, Inc. 15 Volvo Drive

Rockleigh, NJ 07647

Tel: 800.237.2041 / 201.767.3400

Fax: 201.767.1903

www.crestron.com

All brand names, product names and trademarks are the property of their respective owners.

Specications subject to change without notice. Revised 01/04/19

MODELS & ACCESSORIES

Available Models

CLW-SLVU-P-BRN-S: Cameo

In-Wall Remote Dimmer, 120V,

Brown Smooth

CLW-SLVU-P-A-T: Cameo

In-Wall Remote Dimmer, 120V, Almond Textured

CLW-SLVU-P-B-T: Cameo

In-Wall Remote Dimmer, 120V, Black Textured

CLW-SLVU-P-DSK-T: Cameo

In-Wall Remote Dimmer, 120V,

Dusk Textured

CLW-SLVU-P-LAT-T: Cameo

In-Wall Remote Dimmer, 120V, Latte Textured

CLW-SLVU-P-W-T: Cameo

In-Wall Remote Dimmer, 120V, White Textured

CLW-SLVU-P-W-S: Cameo

In-Wall Remote Dimmer, 120V, White Smooth

CLW-SLVU-P-IVR-S: Cameo

In-Wall Remote Dimmer, 120V, Ivory Smooth

CLW-SLVU-P-GRY-S: Cameo

In-Wall Remote Dimmer, 120V, Gray Smooth

CLW-SLVU-P-DA-S: Cameo

In-Wall Remote Dimmer, 120V,

Dark Almond Smooth

CLW-SLVU-P-B-S: Cameo

In-Wall Remote Dimmer, 120V, Black Smooth

CLW-SLVU-P-A-S: Cameo

In-Wall Remote Dimmer, 120V, Almond Smooth

Notes:

1. The CLW-SLVU-P cannot be used to control a load directly. It must be used in conjunction with

a CLW-SWEX-P, CLW-DIMEX-P or CLW-DELVEX-P.

2. Item(s) sold separately.

3. Button engraving is sold separately, or may be provided by a third party.

This product may be purchased from an authorized Crestron dealer. To find a dealer, please contact

the Crestron sales representative for your area. A list of sales representatives is available online at

https://www.crestron.com/How-To-Buy/Find-a-Representative or by calling 855-263-8754.

The specific patents that cover this and other Crestron products are listed online at

https://www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, please visit

https://www.crestron.com/opensource.

Crestron, the Crestron logo, and Cameo are either trademarks or registered trademarks of

Crestron Electronics, Inc. in the United States and/or other countries. Other trademarks, registered

trademarks, and trade names may be used in this document to refer to either the entities

claiming the marks and names or their products. Crestron disclaims any proprietary interest in the

marks and names of others. Crestron is not responsible for errors in typography or photography.

1.75 in.

(45 mm)

0.39 in.

(10 mm)

1.35 in.

(35 mm)

2.65 in.

(68 mm)

4.13 in.

(105 mm)

Produkspesifikasjoner

Merke:	Crestron
Kategori:	Dimmer
Modell:	CLW-SLVU-P-A-T
Bredde:	44 mm
Dybde:	44 mm
Høyde:	105 mm
Driftstemperatur (T-T):	0 - 40 °C
Modell/Type:	Dimmer
Relativ luftfuktighet under drift (H-H):	10 - 90
