Side 1/10

Operating

Instructions

Dahle 919IS

919 IS

INDUSTRIAL SHREDDER

TABLE OF CONTENTS

SPECIFICATIONS

CONTENTS PAGE

Safety Precautions................................................................................................................................3-4

Installation .................................................................................................................................................. 4

Operation ................................................................................................................................................ 5-6

Auto Oiler ....................................................................................................................................................7

Maintenance ..............................................................................................................................................7

Output Conveyor Installation (optional) .........................................................................................7

Troubleshooting .......................................................................................................................................8

Warranty ......................................................................................................................................................8

READ CAREFULLY BEFORE USING

Proper care of your new shredder will ensure many years of trouble free operation,

with minimum of maintenance or repair.

IMPORTANT:

Please note that all packaging should be retained by the customer for (30) days from

the time of receipt. In the event that this unit needs to be sent back for replacement

or repair this packaging will be required to do so. Should the packaging have been

discarded before the (30) day requested period, packaging costs may be incurred by

the customer.

919 IS

INDUSTRIAL SHREDDER

Security Level: P3

Shred Size: 5mm X 40mm

Feed Width: 16”

Shred Capacity: 7580 sheets

Bin Capacity: 45 gal.

Warranty: 1 year

Dimensions: 52” X 47.25” X 48.5”

Weight: 1,080 lbs.

Power Supply: 220v 3 phase, 20 amp

NEMA L1520P Plug, L1520RReceptacle

Results may vary depending on power source, paper type, and proper maintenance.

Warranty includes labor but excludes wearable parts.

Your new shredder features powerful cutting mechanisms that may cause serious

injury. Please follow all safety precautions.

• Only store, transport, and operate the shredder in an upright position!

• All liquids and gases used on the shredder must comply with Dahle guidelines!

• The shredder must only be operated in enclosed spaces at temperatures of 15 °C to

32 °C(59 °F–90 °F) and non-condensed humidity of 15% to 95%!

• Do not place the shredder near a heat source!

• Ensure the shredder is rmly on the oor at a distance of 4” from the wall; activate

caster locks!

• Avoid any accumulation of heat!

• The mains socket must be grounded and easily accessible at all times!

• Use only the power cord supplied with the device by Dahle and ensure that it is not

damaged!

• Ensure that the building installation has short-circuit protection: max. 16 A (US

max. 20 A)!

• Do not use near ammable liquids and gases!

• Do not use near caustic substances!

• Do not subject to moisture!

• Do not open up the machine!

• Automatic start-up!

• Switch o the shredder at the main switch when not in use!

• Only use the shredder provided that it is in perfect working order, while observing

the operating instructions and the usual regulations, guidelines and applicable

safety and accident prevention requirements. Take the shredder out of service

immediately if faults occur!

• The device is not intended for use by persons (including children) with restricted

physical, sensory or mental capabilities or a lack of experience and knowledge, un-

less they are working under supervision or receive detailed instruction about how

to use the device from a person who is responsible for safety.

IMPORTANT SAFETY PRECAUTIONS

Produkspesifikasjoner

Merke:	Dahle
Kategori:	Papirkutter
Modell:	PowerTEC 919 IS
Bredde:	1200.15 mm
Dybde:	1231.9 mm
Høyde:	1320.8 mm
Støynivå:	65 dB
Kurvkapasitet:	90 ark
Arbeidsbredde:	406.4 mm
Makulering av kredittkort:	Ja
Oljeflaskeholder:	Ja
Produktfarge:	Grey, White
Kontrolltype:	Knapper
Overopphetingsbeskyttelse:	Ja
Svinghjul:	Nei
Papirmakulering:	Ja
Makuleringsstørrelse:	5 x 40 mm
Automatisk av/på-kontroll:	Ja
Kurvvolum:	170.34 l
Sikkerhetsnivå (papir):	P-3
Tittevindu:	Nei
Makuleringsbinders:	Ja
Makuleringsmaskintype:	Kryssmakulering
Makulering CD-er:	Ja
Makuleringsstifter:	Ja
Automatisk stopp når papir setter seg fast:	Ja
Anti-klem mekanisme:	Ja
Skjære type:	Diagonale kutt
Indikator for full beholder:	Ja
Uttakbar søppelboks:	Ja
